- Page 1 Liam Tall Cabinet FOLLOW US: CONTACT INFO: ITEM NO. 014-HG-4200 The instruction booklet contains IMPORTANT support@belleze.com @bellezefurniture safety information. Please read it in full and 1-800-682-6376 keep it for future reference. www.belleze.com...
- Page 2 Scan this QR Code to view our online tutorial Estimated time for assembly: 0 mins Weight limitations are as follows: Maximum Load 70 lbs Maximum Load 30 lbs...
- Page 3 Assemble the furniture on an empty carton, carpet, or rug to prevent scratches or damage. For safety, please keep pets and children away from the assembly area. Ensure the product is fully assembled before use. If you are missing any hardware or products, do not use it until you have restored the missing parts.
-
Page 4: Package Contents
PACKAGE CONTENTS... - Page 5 PACKAGE CONTENTS CODE DESCRIPTION Top Panel Bottom Panel Left Cabinet Panel Right Cabinet Panel Back Support Panel Back Panel Metal leg Base Metal Crossbar Crossbar Panel Left Cabinet Door Right Cabinet Door Adjustable Storage Shelf Panel...
- Page 6 PACKAGE CONTENTS 16x+1x 16x+1x 20x + 2x 48x + 4x 48x + 4x 16x+1x 16x+1x 16x+1x Install all hardware perpendicular to the opening.
- Page 7 Required tools for assembly (Not included) Attach cam bolts to the underside of the top panel (1). Assemble 2 cabinets in total.
- Page 8 Attach the door catch and wall pins to the underside of the top panel (1). Insert wood dowels to the underside of the top panel (1).
- Page 9 Assemble the crossbar panel (9) to the underside of the top panel (1). Assemble the left and right cabinet panels (3,4) to the underside of the top panel (1).
- Page 10 Assemble the back support panel (5) to underside of the top panel (1). Slide in the back panels (6) to the back support panel (5) and insert wood dowels to the cabinet panels (3,4)
- Page 11 Attach cam bolts to the top of the bottom panel (2). Assemble the bottom panel (2) on the assembly.
- Page 12 Attach the base metal crossbars (8) between the left and right metal legs (7). Assemble the base on underside of the bottom panel (2) .
- Page 13 Attach hinges to the cabinet doors (10,11). Attach door catch plates to the cabinet doors (10,11).
- Page 14 Assemble the cabinet doors (10,11) on the assembly. Adjust the position of the cabinet doors. Up and down In and out Side to side adjustment by adjustment by adjustment using loosening the screws loosening the screws the front adjustment on the mounting on the hinge arm.
- Page 15 Insert shelf supports to the cabinet panels (3,4) and put on the adjustable storage shelf panel (12) . Attach handles to the cabinet doors (10,11).
- Page 16 Secure the back panels in place.
- Page 17 Furniture must permanently fixed to the wall stud with included anti-tipping device to prevent the furniture from tipping over. • Mark the drill position on the wall with a pencil. • Drill a small hole on the marked position. • Insert a wall anchor into the drilled hole.
- Page 18 Warning Only place items on top of the product if they meet the recommended size and weight limits. Climbing on, stepping on, or placing overweighted objects on the product may cause property damage and/or injuries. Items placed onto this product must be resting on a support surface without hanging over the edges.
- Page 19 © All copyright of this document belongs to BELLEZE . This document may not be printed, translated, reproduced, or distributed in whole or in part without written permission from BELLEZE.
-
Page 20: Warranty
WARRANTY BELLEZE products come with a 1-year warranty from the date of delivery. Register your product on our website to enjoy our limited lifetime warranty! AFTER-SALE SERVICE Contact us at 1-800-682-6376 or email us at support@belleze.com We will send you replacement.
