Megmeet MCCD Series Quick Start Manual

MCCD Series Quick Start
User Manual
Thank you for using MCCD series PLC. Before using the
product, please carefully read this manual so as to better
understand it, fully use it, and ensure safety. This quick start
manual is to offer you a quick guide to the design, installation,
connection and maintenance of MCCD for the convenience of
users to access the required information on site, and provide a
brief introduction to relevant accessories, FAQs, etc.
This manual is suitable for the following MCCD series
members:
MCCD-1208BRC
MCCD-1208BRC1
MCCD-1208BRC3
Version V1.1
Revision date July 14, 2010
BOM R33010006
Product Model
Model
Text type programmable
MCCD-1208BRC
integrated controller
Air compressor integrated
MCCD-1208BRC1
controller(with three
phase detection)
Air compressor integrated
MCCD-1208BRC3
1 Product Panel
MCCD-1208BRC 1 / MCCD-1208BRC3 panels are shown below.
Interface
Definition
editing
Yes
No
No
controller
The pressed key explained that sees the table below.
Key Name
UP
DOWN
ENTER
K1、K2、K3
、 、
RUN
STOP
MCCD-1208BRC panel is shown below.
The pressed key explained that sees the table below.
Key Name
UP
DOWN
ENTER
、 、 FUNCTION
、 、 OPERATION
Function
Turn up or increase the
value
Turn down or decrease
the value
According to the screen
prompt, into the selected
menu
General key, different
states have different
functions
Press this button
controller is executed
Press this button
controller stops running
Function
Turn up or increase the
value
Turn down or decrease the
value
According to the screen
prompt, enter the selected
menu
Screen jump and operation
MENU/ESC ： RETURN OR
CANCEL ； SET ： SET KEY,
enter the input state；ENT：
Confirm Key
