- Page 1 Dangbei N2 Smart Projector User Manual...
-
Page 2: Table Of Contents
Language Contents English ·············································································· 01-19 Read before Use ·····································································01 Deutsch ············································································· 20-38 Packing List·············································································02 Français ············································································ 39-57 Projector Overview··································································03 Remote Control Overview························································04 Italiano ·············································································· 58-76 Español ·············································································· 77-95 Getting Started········································································05 日本語 ·············································································· 96-113 Network Settings ·····································································08 Focus Settings·········································································08 Image Correction Settings ······················································09 Bluetooth Speaker Mode·························································10 Screen Mirroring &... -
Page 3: Read Before Use
We shall not be liable for any personal injury, property damage, or other damages caused by the failure of the user to comply with the Product Instructions or precautions. * Dangbei reserves the right to interpret and modify the Product Instructions. -
Page 4: Packing List
Packing List Before using this product, please check that all items are included in the box. Projector Remote Control AAA batteries DangbeiN2 SmartProjector User Manual Power Adapter User Manual Power Cable... -
Page 5: Projector Overview
Projector Overview Overview and interface description. Ventilation holes (Do not block) Adjustable kickstand PTZ bracket Lens socket Camera DC IN 3.5mm Audio Power button HDMI USB2.0 USB2.0 Front view Rear view Top View Bottom View... -
Page 6: Remote Control Overview
Remote Control Overview ǁOpen the battery compartment cover of the remote control. ǁInstall 2 AAA batteries *. ǁPut back the battery compartment cover. Power Mute Turn ON/OFF projector Temporally cuts off the sound Navigation Press to confirm a selection or entry Pause/Resume play Return Home... -
Page 7: Getting Started
Getting Started 3.23m 120 inches 1.Placement Position the projector on a stable, flat surface in front of the projection surface. A flat and white projection surface is recommended. 2.74m 100 inches Please follow the instructions below to determine the distance between the projector and the projection surface, and the corresponding projection size: 2.21m... - Page 8 2.Power on ① Connect the projector to the power outlet. ② Press the power button on either the projector or the remote control to turn on the projector.
- Page 9 3.Remote Control Pairing ǁPlace the remote control within 10 cm of the projector. ǁFor first-time use, follow the on-screen projector instructions: Simultaneously press and hold the [Volume Down] and [Right] buttons until the indicator light begins to flash. (This means that the remote control is entering pairing mode.) ǁThe connection is successful when the indicator light stops flashing.
-
Page 10: Network Settings
Network Settings Focus Settings Go to [Settings] -- [Network]. ǁGo to [Settings] -- [Focus]. ǁTo use Auto focus, select [Auto], and the screen will automatically become clear. ǁTo use Manual focus, select [Manual], and use the up/down buttons on the navigation keys of the remote control to adjust the focus based on what is displayed. -
Page 11: Image Correction Settings
Image Correction Settings 1.Keystone Correction ǁGo to [Settings] -- [Keystone]. ǁTo use Auto keystone correction, select [Auto], and the screen will automatically be corrected. ǁTo use Manual keystone correction, select [Manual] to adjust the four points and the image shape. 2.Intelligent Screen Fit ǁGo to [Settings] -- [Keystone] , and turn on [Fit to Screen]. -
Page 12: Bluetooth Speaker Mode
Bluetooth Speaker Mode Screen Mirroring & Casting ǁOpen the BluetoothSpeaker application on the device. 1.Mirrorcast ǁTurn on the Bluetooth of your mobile phone/tablet/laptop, To mirror the screen of an Android/Windows device to the select the device of [Dangbei_N2], and connect to it. projector, open the app Mirrorcast, and follow the on-screen ǁUse the projector to play audio from the devices mentioned instructions. -
Page 13: Inputs
Inputs More Settings ǁ Go to [Inputs] -- HDMI/HOME/USB. 1.Picture Mode ǁ Watch the content from the different signal sources. Go to [Settings] -- [Picture Mode] to choose a picture mode from *This product's HDMI interface is HDMI 1.4 and does not [Standard/Custom/Cinema/Sport/Vivid]. -
Page 14: Specifications
Specifications 1920 x 1080 Dual Frequency 2.4/5.0 GHz 197 × 130 × 207 mm 1.26:1 7.76 × 5.12 × 8.15 inches 2 x 6 W 2.2kg / 4.85lb... -
Page 15: Troubleshooting
Troubleshooting 1.No audio output a. Check if the remote control "Mute" button is pressed. b. Check if the projector interface "3.5mm Audio", "HDMI" or Bluetooth is connected to an external audio device. 2. No image output a. Press the power button on the top cover. The power button indicator light will turn off if the projector is powered on successfully. b. - Page 16 Ensure that there are no interferences or obstructions between the projector and remote control. d. Check the battery and installation polarity. 9. Connect the Bluetooth devices Enter settings, open the Bluetooth option to check the Bluetooth device list, and connect the device. 10. Others Please feel free to contact us at support@Dangbei.com.
-
Page 17: Important Precautions
Important Precautions ㆍAs with any bright source, do not stare into the direct beam, RG2 IEC 62471-5:2015 ㆍDo not block or cover the heat dissipation holes of the device to avoid affecting the heat dissipation of internal parts and damaging the device. -
Page 18: Statement
Statement This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. - Page 19 CAN ICES-3 (B)/NMB-3 (B) This Class B digital apparatus complies with Canadian ICES-003. Cet appareil numérique de classe B est conforme à la norme canadienne ICES-003. This device contains licence-exempt transmitter(s)/receiver(s) that comply with Innovation, Science and Economic Development Canada’s licence-exempt RSS(s).
- Page 20 EU DECLARATION OF CONFORMITY Product : Smart Projector Trademark : Dangbei Model Designation : N2 Manufacturer’s Name : Shenzhen Dangs Science and Technology Co., Ltd. Manufacturer’s Address : 901, GDCBuilding, Gaoxin Mid 3nd Road,Maling Community, Yuehai Sub-district, Nanshan District, Shenzhen,China.
- Page 21 UKCA DECLARATION OF CONFORMITY Product : Smart Projector Trademark : Dangbei Model Designation : N2 Manufacturer’s Name : Shenzhen Dangs Science and Technology Co., Ltd. Manufacturer’s Address : 901, GDCBuilding, Gaoxin Mid 3nd Road,Maling Community, Yuehai Sub-district, Nanshan District, Shenzhen,China.
