dji RONIN 4D Faq

FAQ
How many versions does DJI Ronin 4D have? What are the differences between
them?
DJI Ronin 4D has two versions 6K and 8K. The 6K version comes with an X9-6K Gimbal Camera that
supports up to 6K/60fps and 4K/120fps video recording, while the 8K version includes an X9-8K Gimbal
Camera that supports up to 8K/75fps and 4K/120fps video recording. The 8K combo additionally
includes a RAW License Key, DJI DL PZ 17-28 mm T3.0 ASPH Lens, PROSSD 1TB, PROSSD mount, and a
USB-C to USB-C High-Speed Data Cable to meet higher creative requirements. Check the In the Box of
DJI Ronin 4D for a detailed list of included items.
How can users who have already purchased a DJI Ronin 4D-6K combo use the
Zenmuse X9-8K Gimbal Camera?
If you already own the DJI Ronin 4D-6K combo, you can purchase the Zenmuse X9-8K Gimbal Camera
separately and replace the X9-6K Gimbal Camera with it. Mount the Zenmuse X9-8K Gimbal Camera
onto the Ronin 4D main body and upgrade the firmware to the latest version.
In what specifications can I record ProRes RAW and ProRes RAW HQ video?
Zenmuse X9-8K Gimbal Camera
Apple ProRes RAW is used when recording RAW video in the following specifications.
8K: 29.97/30/48/50/59.94/60/72/75fps
5.5K: 59.94/60fps
4K: 120fps
Apple ProRes RAW HQ is used when recording RAW video in the following specifications.
8K: 23.976/24/25fps
5.5K: 23.976/24/25/29.97/30/48/50fps
4K: 23.976/24/25/29.97/30/48/50/59.94/60/72/96/100fps
Zenmuse X9-6K Gimbal Camera
Apple ProRes RAW HQ is used when recording RAW video in the following specifications.
6K: 23.976/24/25/29.97/30/48/50/59.94/60fps
4K: 23.976/24/25/29.97/30/48/50/59.94/60/72/96/100/120fps
What is DJI Ronin 4D's main body made of?
The main body of DJI Ronin 4D is crafted with aluminum magnesium alloy and the Z-axis arm with
carbon fiber.
