Summary of Contents for Yealink RoomPanel Plus
- Page 1 RoomPanel Plus Deployment and Connection RoomPanel Plus Deployment and Connection RoomPanel Plus Deployment and Connection For the installation video, please refer to Install. Package Contents Package Contents...
- Page 2 RoomPanel Plus Deployment and Connection...
- Page 3 RoomPanel Plus Deployment and Connection...
-
Page 4: Hardware Component Instructions
RoomPanel Plus Deployment and Connection Hardware Component Instructions Hardware Component Instructions... - Page 5 RoomPanel Plus Deployment and Connection Mount Wall Mount Wall TIP Take 0° mount bracket as an example for reference. 1. Glue the locating sticker to locate the installation position...
- Page 6 RoomPanel Plus Deployment and Connection 2. Install the mount bracket on the wall...
- Page 7 RoomPanel Plus Deployment and Connection 3. Connect the ethernet cable...
- Page 8 RoomPanel Plus Deployment and Connection...
- Page 9 RoomPanel Plus Deployment and Connection NOTE NOTE Method D requires connecting cable first and then installing the bracket. 4. Place the RoomPanel Plus onto the bracket. When you hear a click, tighten the screw to fasten the device in place...
- Page 10 1. Clean the glass surface before gluing the 3M tape. 2. Press the 3M tape firmly, ensuring it is securely stuck to the glass. 3. Wait 1 hour after gluing the mounting bracket and install the RoomPanel Plus next. TIP...
- Page 11 RoomPanel Plus Deployment and Connection 1. Glue the locating sticker to locate the installation position 2. Glue the mount bracket to the glass...
- Page 12 RoomPanel Plus Deployment and Connection 3. Connect the ethernet cable...
- Page 13 RoomPanel Plus Deployment and Connection 4. Place the RoomPanel Plus onto the bracket. When you hear a click, tighten the screw to fasten the device in place...
- Page 14 RoomPanel Plus Deployment and Connection 5. Glue the glass sticker on the back of the glass to maintain the aesthetics (Optional)
- Page 15 RoomPanel Plus Deployment and Connection Mount Mullion Mount Mullion TIP Take 0° mount bracket as an example for reference. 1. Locate the installation position...
- Page 16 RoomPanel Plus Deployment and Connection 2. Install the mullion mount bracket and attach the bracket...
- Page 17 RoomPanel Plus Deployment and Connection 3. Connect the ethernet cable...
- Page 18 RoomPanel Plus Deployment and Connection NOTE NOTE You can route the cable through this hole. 4. Place the RoomPanel Plus onto the bracket. When you hear a click, tighten the screw to fasten the device in place...
- Page 19 RoomPanel Plus Deployment and Connection Connect RoomPanel Plus Connect RoomPanel Plus...
- Page 20 RoomPanel Plus Deployment and Connection NOTE NOTE The device supports the wireless network. You can also connect the power cable and network cable to supply power and internet. After the deployment is complete, you can refer to the Quick Setup chapter to configure the device first;...
