StarTech.com PM1115P3 Quick Start Manual

10/100Mbps Ethernet to Parallel Network Print Server
Product ID
PM1115P3
Front View
1
Rear View
4
To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support
2 3
5
*Product may vary from image
Components
• Used to power the Print Server with the included 5V
1 DC Power Port
1A Power Adapter
• Used to connect the Print Server to a Network
• Left LED illuminates Yellow when connected at
2 10Mbps
RJ45 Port
• Right LED illuminates Green when connected at
100Mbps
• Flashes Yellow when power is supplied
3
Status LED • Turns Solid Yellow when a network link has been
established
• Press once to Restart the Print Server
• Press and Hold for 5 Seconds to send a Test Page
to the connected Parallel Printer
• To restore the Factory Default settings, Press and
4 Reset Button
Hold for 10 Seconds, then Release
Note: The Reset Button is recessed. Use a fine object to
press it
• Centronics 36-Pin Parallel Port used to connect to a
5 Parallel Port
Parallel Printer
Requirements
For the latest manuals, product information, technical specifications, and declarations of
conformance, please visit: www.StarTech.com/PM1115P3
Package Contents
• Parallel Print Server x 1
• Power Adapter x 1
• Quick-Start Guide x 1
Default Network Settings
DHCP client: Off
IP Address: 192.168.0.10
Subnet Mask: 255.255.255.0
Quick-Start Guide
Function
Manual Revision: March 22, 2024
