Summary of Contents for StarTech.com PM1115U

  • Page 1: Print Server

    Print Server Quick Installation Guide...

  • Page 2: Product Introduction

    Product Introduction Thank you for purchasing and using our print server. This print server allows your printer to become a shared device on the network. It offers printing flexibility and manageability on your Wired or Wireless Local Area Network with an absolute minimum setup and maintenance required.

  • Page 3: Product Package

    1. Unpack the print server package and verify that all the items listed in the previous section are provided. 2. Connect the print server to the printer you want to share on the network. 3. Connect the print server to your network by attached the...

  • Page 4: Administrator Installation And Setup

    4. Connect the power adapter to the print server. The print server will perform the Power-On-Self-Test (POST) after it is powered on. During the POST, the Status LED will be blinking. When the Status LED is unlighted, the print server is ready.
  • Page 5 1. Insert the CD shipped along with the print server into your CD-ROM drive. The Autorun.exe program should be executed automatically. If not, run Autorun.exe manually from CD-ROM drive’s root directory. 2. The “Installation Manager” will be displayed on the screen as following.
  • Page 6 4. Click “Next” to install the utilities in the default folder or click “Browse” to specify the destination folder where you would like to install the utilities. 5. Select the components you want to install. It is highly recommended to install all provided components. Click “Next”...
  • Page 7 6. Specify the program folder where the program icons will be added to, click “Next”. 7. The system will start to install the utilities automatically.
  • Page 8 Print Servers within the network. Select the Print Server you would like to configure and click “Next”. NOTE 1: If this is the first time you configure the Print Server, the “Print Server Name” is the last 6-digit of MAC ID with prefix “PS”.
  • Page 9 9. Specify a recognizable name for the Print Server and click “Next”. 10. Specify the IP Address for the Print Server manually or click “Next” to keep default IP Address, i.e. 192.168.2.2.
  • Page 10 11. The configuration summary is displayed in the window. Now, you have completed the “Print Server Setup”. Click “Finish” and your system will add network port of the Print Server to your PC automatically. 12. The Administrator Installation procedure is totally...

  • Page 11: Client Installation And Setup

    Please follow the steps below to start installation. 1. Insert the CD shipped along with the print server into your CD-ROM drive. The Autorun.exe program should be executed automatically. If not, run Autorun.exe manually...
  • Page 12 2. The "Installation Manager" will be displayed on the screen as follows. Click “Client Installation”. 3. The “Utilities Setup” window will be displayed. Click “Next”.
  • Page 13 4. Click “Next” to install the utilities in the default folder or click “Browse” to specify the destination folder where you would like to install the utilities. 5. Specify the program folder where the program icons will be added to, click “Next”.
  • Page 14 6. The system will start to install the utilities automatically. 7. Now, the installation procedure is completed, you are ready to set up the client’s computer. All network ports of the Print Servers detected on the network will be added to your PC automatically, click “Continue”.

  • Page 15: Windows Add Printer Procedure

    8. The Client Installation procedure is completed. Click “Finish”. Windows Add Printer Procedure After adding a “Network Port” of the print server to your PC by Administrator or Client Installation Program, you can follow the procedure described below to add printer to the Windows.
  • Page 16 Step3. The “Add Printer Wizard” is displayed. Click “Next”. Step4. Select “Local printer attached to this computer” and make sure that “Automatically detect and install my Plug and Play printer” is not selected. Click “Next”.
  • Page 17 Step5. Choose the suitable “Print Server Network Port” which was created by the Administrator Installation or Client Installation process and click “Next”. Step6. Select a suitable printer manufacturer and the printer model and click “Next”. If your printer is not in the list, click “Have Disk…”...
  • Page 18 Step7. Name your printer and setup the default printer, click “Next”. Step8. Choose to print the test page or not. It is recommended to print a test page. Click “Next”.
  • Page 19 Step9. You have added the printer to the PC successfully. The information of the printer is displayed in the windows. Click “Finish”. Now you can start to print from your PC to the print server.
