STR-K7100
MAIN
Ref. No. Part No. Description
C657 1-162-927-11 CERAMIC CHIP
C660 1-126-947-11 ELECT
C661 1-136-157-00 FILM
C666 1-162-815-11 CERAMIC
C669 1-162-815-11 CERAMIC
C670 1-162-960-11 CERAMIC CHIP
C680 1-126-964-11 ELECT
C681 1-162-970-11 CERAMIC CHIP
C691 1-164-156-11 CERAMIC CHIP
C701 1-126-963-11 ELECT
C702 1-126-964-11 ELECT
C703 1-165-722-11 ELECT
C704 1-107-583-11 CERAMIC
C705 1-102-233-00 CERAMIC
C706 1-162-927-11 CERAMIC CHIP
C707 1-162-927-11 CERAMIC CHIP
C710 1-126-947-11 ELECT
C711 1-136-157-00 FILM
C716 1-162-815-11 CERAMIC
C717 1-162-815-11 CERAMIC
C720 1-162-960-11 CERAMIC CHIP
C721 1-126-923-11 ELECT
C722 1-126-964-11 ELECT
C729 1-162-970-11 CERAMIC CHIP
C732 1-128-582-11 ELECT
C733 1-128-582-11 ELECT
C740 1-126-964-11 ELECT
C741 1-128-579-11 ELECT
C742 1-162-970-11 CERAMIC CHIP
C743 1-128-579-11 ELECT
C744 1-128-579-11 ELECT
C749 1-162-970-11 CERAMIC CHIP
C750 1-126-964-11 ELECT
C751 1-126-963-11 ELECT
C752 1-162-970-11 CERAMIC CHIP
C753 1-165-722-11 ELECT
C754 1-107-583-11 CERAMIC
C755 1-102-233-00 CERAMIC
C756 1-162-927-11 CERAMIC CHIP
C757 1-162-927-11 CERAMIC CHIP
C760 1-126-947-11 ELECT
C761 1-136-157-00 FILM
C762 1-126-964-11 ELECT
C766 1-162-815-11 CERAMIC
C767 1-162-815-11 CERAMIC
C770 1-162-960-11 CERAMIC CHIP
C791 1-126-923-11 ELECT
C801 1-126-947-11 ELECT
C802 1-126-947-11 ELECT
C803 1-165-960-11 ELECT(BLOCK)
C804 1-165-960-11 ELECT(BLOCK)
C805 1-135-851-21 MYLAR
C806 1-135-851-21 MYLAR
C807 1-126-947-11 ELECT
C808 1-126-947-11 ELECT
C809 1-100-623-11 CERAMIC CHIP
C810 1-137-980-11 CERAMIC CHIP
C811 1-137-980-11 CERAMIC CHIP
66
Remark Ref. No.
100PF 5% 50V
47uF 20% 35V
0.022uF 5% 50V
47PF 5% 500V
47PF 5% 500V
220PF 10% 50V
10uF 20% 50V
0.01uF 10% 25V
0.1uF 25V
4.7uF 20% 50V
10uF 20% 50V
100uF 20% 10V
3PF 0.25PF 500V
33PF 10% 500V
100PF 5% 50V
100PF 5% 50V
47uF 20% 35V
0.022uF 5% 50V
47PF 5% 500V
47PF 5% 500V * CNP503 1-564-506-11 PLUG, CONNECTOR 3P
220PF 10% 50V * CNP507 1-564-507-11 PLUG, CONNECTOR 4P
220uF 20% 10V * CNP801 1-564-242-00 PIN, CONNECTOR (3.96mm PITCH) 5P
10uF 20% 50V * CNP802 1-564-509-11 PLUG, CONNECTOR 6P
0.01uF 10% 25V * CNP912 1-564-506-11 PLUG, CONNECTOR 3P
10uF 20% 100V
10uF 20% 100V
10uF 20% 50V
2.2uF 20% 100V
0.01uF 10% 25V
2.2uF 20% 100V
2.2uF 20% 100V
0.01uF 10% 25V
10uF 20% 50V
4.7uF 20% 50V
0.01uF 10% 25V
100uF 20% 10V
3PF 0.25PF 500V
33PF 10% 500V
100PF 5% 50V
100PF 5% 50V
47uF 20% 35V
0.022uF 5% 50V
10uF 20% 50V
47PF 5% 500V
47PF 5% 500V
220PF 10% 50V
220uF 20% 10V
47uF 20% 35V
47uF 20% 35V
6800uF 20% 71V
6800uF 20% 71V
0.22uF 100V
0.22uF 100V
47uF 20% 35V
47uF 20% 35V
0.1uF 10% 100V
0.47uF 10% 50V
0.47uF 10% 50V
Part No. Description
C822 1-126-947-11 ELECT
C830 1-137-980-11 CERAMIC CHIP
C831 1-137-980-11 CERAMIC CHIP
C832 1-126-936-11 ELECT
C842 1-165-732-31 ELECT
C3022 1-165-908-11 CERAMIC CHIP
C3024 1-126-963-11 ELECT
C3025 1-164-156-11 CERAMIC CHIP
C3026 1-164-156-11 CERAMIC CHIP
C3027 1-165-908-11 CERAMIC CHIP
C3032 1-165-908-11 CERAMIC CHIP
C3034 1-126-963-11 ELECT
C3037 1-165-908-11 CERAMIC CHIP
< CONNECTOR >
CN500 1-573-843-11 CONNECTOR, BOARD TO BOARD 11P
CN504 1-784-766-11 CONNECTOR, FFC 5P
CN506 1-779-978-11 PIN, CONNECTOR 3P
CNP501 1-573-847-11 CONNECTOR, BOARD TO BOARD 15P
< DIODE >
D505 6-501-193-01 DIODE 1SS355WTE-17
D529 6-501-193-01 DIODE 1SS355WTE-17
D540 6-501-193-01 DIODE 1SS355WTE-17
D560 6-501-193-01 DIODE 1SS355WTE-17
D605 6-501-193-01 DIODE 1SS355WTE-17
D610 6-501-193-01 DIODE 1SS355WTE-17
D611 6-501-193-01 DIODE 1SS355WTE-17
D640 6-501-193-01 DIODE 1SS355WTE-17
D665 6-501-193-01 DIODE 1SS355WTE-17
D680 6-501-193-01 DIODE 1SS355WTE-17
D690 8-719-083-71 DIODE UDZSTE-1730B
D691 6-501-193-01 DIODE 1SS355WTE-17
D701 6-501-193-01 DIODE 1SS355WTE-17
D705 6-501-193-01 DIODE 1SS355WTE-17
D710 6-501-193-01 DIODE 1SS355WTE-17
D721 6-501-193-01 DIODE 1SS355WTE-17
D722 6-501-193-01 DIODE 1SS355WTE-17
D729 6-501-193-01 DIODE 1SS355WTE-17
D732 6-501-193-01 DIODE 1SS355WTE-17
D733 6-501-193-01 DIODE 1SS355WTE-17
D740 6-501-193-01 DIODE 1SS355WTE-17
D749 6-501-193-01 DIODE 1SS355WTE-17
D750 6-501-193-01 DIODE 1SS355WTE-17
D765 6-501-193-01 DIODE 1SS355WTE-17
D791 6-501-193-01 DIODE 1SS355WTE-17
D801 8-719-083-85 DIODE UDZSTE-1722B
D802 6-501-003-21 DIODE D6SBN20-7003
D804 6-500-295-01 DIODE PTZ-TE25-5.6B
D805 8-719-053-18 DIODE 1SR154-400TE-25
D806 8-719-053-18 DIODE 1SR154-400TE-25
D807 8-719-053-18 DIODE 1SR154-400TE-25
D808 8-719-053-18 DIODE 1SR154-400TE-25
Remark
47uF 20% 35V
0.47uF 10% 50V
0.47uF 10% 50V
3300uF 20% 16V
47uF 20% 25V
1uF 10% 10V
4.7uF 20% 50V
0.1uF 25V
0.1uF 25V
1uF 10% 10V
1uF 10% 10V
4.7uF 20% 50V
1uF 10% 10V
