STR-K7100
Pin No.
Pin Name
100
HD IN
101
HD CLK
FLASH2/C LINK
102
UART RX(MICLO)
FLASH1/C LINK
103
UART TX(MOCLI)
104
C LINK DET
105
DA1
106
DA0
107
DAVS
108
DAVC
109
AVCC
110
AVRH
111
AVSS/AVRL
112
VSS
113
DCAC IN
114
AD KEY1
115
AD KEY2
116
VERSION
117
TUNER SD
118
MODEL
119
VACS CTRL
120
NO USE
52
I/O
O
HD signal output from digital signal processor
O
HD serial clock signal output from digital signal processor
I
Flash signal input
O
Flash signal output
I
DMPORT link detect signal input
I
Not used in this set. (Open)
I
Not used in this set. (Open)
—
Ground pin
I
Power supply pin (+3.3 V) for D/A converter
I
Analog power supply pin (+3.3 V) for A/D converter
I
Standard power supply pin (+3.3 V) for A/D converter
—
Analog ground pin for A/D converter
—
Ground pin
I
DCAC IN signal input
I
AD key signal input 1
I
AD key signal input 2
I
Not used in this set. (Connect to GND.)
I
Tuner SD signal input
I
Model select signal input (Connect to GND in this set.)
I
VACS control signal input
I
Not used.
Pin Description
