STR-K7100

2-4. DIGITAL BOARD

3 CNP512 (3P)
1 CNP505 (7P)
2 CNP503 (8P)
5 DIGITAL board
4 screw
(+BVTP 3 × 8)

2-5. MAIN BOARD SECTION

3 CNP912 (2P)
4 CN915 (6P)
1 CNP801 (5P)
2 CNP802 (5P)
5 screw
(+BV3 (3 -CR) )
7 two screws
(+BV3 (3 -CR) )
6 two screws
(+BV3 (3 -CR) )
8 MAIN board section
10
