Sony STR-K7100 - Multi Channel Av Receiver Service Manual page 54

STR-K7100
Pin No. Pin Name
54 B33
55 A33
56 VCC
57 B34
58 A34
59 GND
60 NC
61 VCC
62 HPD2
63 SDA2
64 SCL2
65, 66 GND
67 B21
68 A21
69 VCC
70 B22
71 A22
72 GND
73 B23
74 A23
75 VCC
76 B24
77 A24
78 GND
79 VCC
80 HPD1
54
I/O
I TMDS data (negative) input (Not used in this set.)
I TMDS data (positive) input (Not used in this set.)
— Power supply pin (+3.3 V)
I TMDS data (negative) input (Not used in this set.)
I TMDS data (positive) input (Not used in this set.)
— Ground pin
— Not used. (Open)
— Power supply pin (+3.3 V)
O Hot plug detection signal output for HDMI DVD IN connector
I/O I2C two-way data bus with HDMI DVD IN connector
I I2C clock signal input from HDMI DVD IN connector
— Ground pin
I TMDS clock signal (negative) input from HDMI DVD IN connector
I TMDS clock signal (positive) input from HDMI DVD IN connector
— Power supply pin (+3.3 V)
I TMDS data (negative) input from HDMI DVD IN connector
I TMDS data (positive) input from HDMI DVD IN connector
— Ground pin
I TMDS data (negative) input from HDMI DVD IN connector
I TMDS data (positive) input from HDMI DVD IN connector
— Power supply pin (+3.3 V)
I TMDS data (negative) input from HDMI DVD IN connector
I TMDS data (positive) input from HDMI DVD IN connector
— Ground pin
— Power supply pin (+3.3 V)
O Hot plug detection signal output for HDMI VIDEO 2/BD IN connector
Pin Description
