Infinity Beta SW Series Service Manual page 6

SW-12
C
ONNECTIONS
If you have a Dolby* Digital or DTS
with a low-frequency-effects (LFE) output:
SUBWOOFER OR
LFE OUTPUT
B A S S O P T I M I Z A T I O N S Y S T E M
FREQUENCY LEVEL WIDTH
180 Normal ON
PHASE GREEN: ON
RED: STANDBY
0 LFE OFF POWER
50 150 MIN MAX
CROSSOVER LEVEL
LINE LEVEL IN
R L
R
HIGH
LEVEL
IN
L
R
HIGH
LEVEL
OUT
L
_
+
• Set Normal/LFE Switch to LFE.
NOTE: In this case, you do not need to use a Y connector. Simply
connect the LFE output on your receiver/processor to either the left
or right input on the subwoofer.
If your receiver/processor has subwoofer
outputs for the left and right channels:
RECEIVER/PROCESSOR
B A S S O P T I M I Z A T I O N S Y S T E M
FREQUENCY LEVEL WIDTH
180 Normal ON
PHASE GREEN: ON
RED: STANDBY
0 LFE OFF POWER
50 150 MIN MAX
CROSSOVER LEVEL
LINE LEVEL IN
R L
R
HIGH
LEVEL
IN
L
R
HIGH
LEVEL
OUT
L
_
+
• Set Normal/LFE Switch to Normal.
NOTE: Some receivers have a single subwoofer output (do not confuse
this with a single LFE output as described below). In that case, it is
recommended that you use a Y connector (not included) to maximize
performance.
SW-12
® receiver/processor
®
SW-12
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: POWER
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
ON
AVERTISSEMENT:
POUR PRÉVENIR LES RISQUES D'INCENDIE OU
DE CHOC ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA
PLUIE OU A L'HUMIDITÉ.
OFF
P/N:352153-001
Infinity Systems
Northridge, CA USA
AC
120V ~ 60HZ
500W
®
SW-12
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, POWER
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
ON
AVERTISSEMENT: POUR PRÉVENIR LES RISQUES D'INCENDIE OU
DE CHOC ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA
PLUIE OU A L'HUMIDITÉ.
OFF
P/N:351153-001
Infinity Systems
Northridge, CA USA
AC
120V ~ 60HZ
500W
If your receiver/amplifier does not have subwoofer
outputs for the left and right channels or an LFE
output:
RECEIVER/AMPLIFIER
Front Speaker Output
B A S S O P T I M I Z A T I O N S Y S T E M
FREQUENCY LEVEL WIDTH
180 Normal ON
PHASE GREEN: ON
0
RED: STANDBY
0 LFE OFF POWER
50 150 MIN MAX
CROSSOVER LEVEL
LINE LEVEL IN
R L
R
HIGH
LEVEL
IN
L
R
HIGH
LEVEL
OUT
L
_
+
• Set Normal/LFE Switch to Normal.
–
BLACK =
1. LOOSEN TERMINALS
2.
INSERT BARE END;
TIGHTEN TERMINALS
STRIPE =
5
®
SW-12
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING: POWER
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK,
DO NOT EXPOSE THIS APPLIANCE TO RAIN OR MOISTURE.
ON
AVERTISSEMENT: POUR PRÉVENIR LES RISQUES D'INCENDIE OU
DE CHOC ÉLECTRIQUE, ÉVITER D'EXPOSER CET APPAREIL A LA
PLUIE OU A L'HUMIDITÉ.
OFF
P/N:352153-001
Infinity Systems
Northridge, CA USA
AC
120V ~ 60HZ
500W
+
RED =
– +
NO STRIPE =
