Electrical Parts List (120V) - Infinity Beta SW Series Service Manual

SW-12
SW-12 120v Electrical parts list
Part number Qty
MAIN PCB
Resistors
021-100401-020 1 MOF resistor
021-470305-021 1 MOF resistor
021-560305-020 1 MOF resistor
022-005105-020 1 Resistor
024-000098-120 2 SMD Resistor
024-100498-120 1 SMD Resistor
024-100598-120 15 SMD Resistor
024-100698-120 2 SMD Resistor
024-110598-120 4 SMD Resistor
024-120498-120 2 SMD Resistor
024-130498-100 1 SMD Resistor
024-150598-120 2 SMD Resistor
024-160598-100 2 SMD Resistor
024-220298-120 2 SMD Resistor
024-220498-121 2 SMD Resistor
024-220598-120 1 SMD Resistor
024-330498-120 4 SMD Resistor
024-330598-120 5 SMD Resistor
024-412498-100 1 SMD Resistor
024-470298-120 4 SMD Resistor
024-470398-120 4 SMD Resistor
024-470598-120 2 SMD Resistor
024-510498-120 5 SMD Resistor
024-560498-120 1 SMD Resistor
024-680498-120 1 SMD Resistor
Capacitors
031-100184-100 2 SMD Capacitor
031-100244-100 2 SMD Ceramic Capacitor
031-100344-100 6 SMD Capacitor
031-100384-100R 2 SMD Capacitor
031-220344-300 1 SMD Capacitor
031-470144-101 1 SMD Capacitor
032-100484-200 3 END Mylar Capacitor
033-330444-270 2 NPE Capacitor
033-680464-270 2 NPE Capacitor
034-100614-300 1 Eletrolytic Capacitor
034-100625-300 1 Eletrolytic Capacitor
034-100695-300 1 Eletrolytic Capacitor
034-100895-204 2 Eletrolytic Capacitor
034-220525-300 2 Electrolytic Capacitor
034-330625-300 2 Electrolytic Capacitor
034-470415-300 1 Electrolytic Capacitor
Semiconductors
051-000600-100 1 Transistor PNP
Description
1K 1W J FK TYPE
470R 5W J
560R 5WS J 8x25 KINK
PN:SQM 0R05 5W J 25x13
0R 1/8W J 0805
1K 1/8W J 0805
10K 1/8W J 0805
100K 1/8W J 0805
11K 1/8W J 0805
1K2 1/8W J 0805
1K3 1/8W F 0805
15K 1/8W J 0805
16K 1/8W F 0805
22R 1/8W J 0805
2K2 1/8W J 0805
22K 1/8W J 0805
3K3 1/8W J 0805
33K 1/8W J 0805
4K12 1/8W F 0805
47R 1/8W J 0805
470R 1/8W J 0805
47K 1/8W J 0805
5K1 1/8W J 0805
5K6 1/8W J 0805
6K8 1/8W J 0805
0u01/250V K 0805 X7R
0u01/50V K 0805 X7R
0u1/50V K 0805 X7R
0u1/250V K 1206 X7R
220pF/50V K 0805 NPO
0u0047/50V K 0805 X7R
1uF/250V K P:15
3u3/50V K10 (R)8x13 SBE
6u8/100V K10 (R)1020 GNE
100uF/16V M (R)0611 P:2.5
100uF/25V M (R)6.3x11 P:5
100uF/63V M (R)1012 P:5
10000uF/63V M (R)30x51
22uF/25V M (R)5x11 P:2.5 TAPIN
330uF/25V M (R)1013 P:5
4u7/50V M (R)0511 P:2.0
PN:MPSW06RLRA TO-92 (ON)
11
Reference Designator
R173
R78
R76
R2
R8,193
R110
R5,7,16,118,121,122,125,1,
R15,120
R187,188,190,191
R189,192
R119
R20,21
R13,13B
R28,29
R17,31
R127
R77,79,22,169
R4,6,14,60,60B
R63
R24-27
R145,155,177,186
R3,171
R48A,48B,48C,48D,48E
R30
R23
C104,119
C27,28
C10,69,112,115,135,138
C5,6
C40
C1G1
C37,39,30
C114,137
C113,136
C8
C62
C142
C1,4
C25,26
C11,100
C7
Q6
