Infinity Beta SW Series Service Manual page 16

SW-12
Part number Qty
INPUT PCB ASS'Y (4 PCB's)
031-470444-101 1 SMD Capacitor
031-680444-100 1 SMD Capacitor
034-100515-300G 1 Electrolytic Capacitor
034-100615-301 1 Electrolytic Capacitor
034-220516-301 2 Electrolytic Capacitor
034-220525-300 4 Electrolytic Capacitor
035-100363-300 3 PE Capacitor
035-220243-100 1 PECapacitor FE-M
035-330293-300 2 PE Capacitor
035-330393-300 2 ESKMylar Capacitor
035-680253-300 4 PE Capacitor FE-M
Semiconductors
050-505200-001 1 LED
054-007200-100L 7 SMD IC; DUAL OP-AMP
054-007400-100 1 SMD IC;(OP) QUAD OP-AMP
054-011400-100 1 SMD Transistor
054-033904-100 2 SMD Transistor
054-414803-100 12 SMD DIODE
Miscellaneous
072-010058-000 1 RCA JACK 2P
072-040007-000 2 7P Terminal housing SWA101
072-040008-110 1 8P Terminal housing
072-040253-000 1 HEADER Right Angle
072-040337-000 1 HEADER Right Angle
072-040338-000 1 HEADER Right Angle
072-060219-000 1 BINDING POST (gold plated)
073-010021-000 3 Screw base
074-030002-000 3 TOGGLE SW
FUSE SET PCB
039-220180-100 1 X2 Safety Capacitor 0.22uF/250V
043-324300-000 1 INDUCTOR
072-040064-000 1 Terminal (PCB TYPE)
072-040096-000 3 TerminalT187MA(PCB TYPE)
073-050001-000 2 FUSE CLIP
091-000128-000 1 FUSE
MISC/MECHANICAL
061-001021-000 2 Knob
061-001052-000 2 Knob
061-100016-000 Partition Post
061-314002-000 Strain Relief
061-700044-000 Mylar
061-700090-900 Washer
063-010010-000 Bracket for Power Transistor
063-332101-000 Bucket
Description
4700pF/50V K X7R 1206
6800pF/50V K X7R 1206
10uF/16V M (R)0511 P:2
100uF/16V M (R)0611 P:5
22uF/16V M (R)0511 P:2
22uF/25V M (R)5x11 P:2.5 TAPIN
0u1/100V J P:5m/m
0u022/63V J P:5m/m
0u033/63V J P:5
0u33/63V J P:5
0u068/63V J P:5m/m
PN:LT-2402-21
PN:M072M-TE1 DMP8 (JRC)
PN:TL074CDR (TI)
PN:DTC114TKA SMT3 (ROHM
PN:MMBT3904LT1 SOT23
PN:LL4148 (Wishay)
PN:0502000W1G (Red,White)
JS-1001-07
JS-1001-08
PN:211-103-000-400 3PIN
PN:211-110-000-400 10PIN
PN:211-105-000-400 5PIN
PN:A807A-RB 8PIN
PN:PCB-2(M3) 4PIN
PN:L101-T2B4QE
18x16.5x8.5mm PN:XG275M224VHS2
324uH YT-10778
PC250(t=0.8),T250MA
(t=0.8mm) PC187(0.8)
P/N:CFFH1206
T4A/250V φ5x20m/m
PN49001-WD7 φ16x14
PN:49001-W D=15.1 H=14.5
PN:BCMS-8 L=8mm Nylon 66(UL)
P/N SB4F-2
13x18mm TO-220
16x21mm t=2mm
P/N:TRK-2
12.83"x8.33"x3.93" ABS 94V0
15
Reference Designator
C2G1
C212
C220
C221
C223,225
C303,304,14,15
C322,323,328
C202
C209,218
C207,208
C201,213,380,381
LED1
U200-205,301
U300
Q202
Q203,204
D200-205,207,209,212,216,
J201
P3,4
P2
M3
M4
M3
J200
T1,2,3
SW200-202
CXAC1
L13
TER2
TER1,3,4
F1B1
F1
for VR301-303
for R233,216
PANEL,COVER
for Q13,17
for Q11,15
for Q11,13,15,17,TH1
