Infinity Beta SW Series Service Manual page 21

SW-12
Part number
INPUT PCB ASS'Y (4 PCB's)
Capacitors
031-100244-101 SMD Capacitor
031-100344-102L SMD Capacitor
031-100344-104 SMD Capacitor
031-100345-300 SMD Capacitor
031-220344-103 SMD Capacitor
031-330445-100 SMD Capacitor
031-470444-101 SMD Capacitor
031-680444-100 SMD Capacitor
034-100515-300G Electrolytic capacitor
034-100615-301 Electrolytic Capacitor
034-220516-301 Electrolytic capacitor
034-220525-300 Electrolytic capacitor
035-100363-300 PE Capacitor
035-220243-100 PE Capacitor FE-M
035-330293-300 PE Capacitor PN:ESK063S33JT
035-330393-300 ESK Mylar Capacitor
035-680253-300 PE Cap FE-M PN:ESK063S68JT
Semiconductors
050-505200-001 LED
054-007200-100L SMD IC; DUAL OP-AMP
054-007400-100 SMD IC;(OP) QUAD OP-AMP
054-011400-100 SMD Transistor
054-033904-100 SMD Transistor
054-414803-100 SMD DIODE
Miscellaneous
072-010058-000 RCA JACK 2P
072-040007-000 7P Terminal housing SWA101
072-040008-110 8P Terminal Housing
072-040253-000 HEADER Right Angle
072-040337-000 HEADER Right Angle
072-040338-000 HEADER Right Angle
072-060219-000 BINDING POST (gold plated)
073-010021-000 Screw base
074-030002-000 TOGGLE SW
FUSE PCB
039-220180-100 X2 Safety capacitor 0u22/250V
043-324300-000 INDUCTOR
072-040064-000 Terminal (PCB TYPE)
072-040096-000 Terminal T187MA(PCB TYPE)
073-050001-000 FUSE CLIP
091-000096-000 FUSE
MISCELLANEOUS
008-060302-000 MODEL 88 GASKET(UL)
008-060302-072 GASKET (UL) PORON
008-061215-000 GASKET C4305
008-062001-000 GASKET CR C4305
008-063001-000 GASKET CR C4305
042-014109-000 Transformer 230V/50Hz
061-001021-000 Knob SPL600 (black)
061-001052-000 Knob w/white indicator
062-332101-000 Bucket
063-010010-000 Bracket for Transistor
063-332109-900 PANEL (SW-12 230V)
073-014044-000 Bracket
074-020018-000 ROCKER SW (POWER)
086-021818-030 VDE Power cord LF2-75
Description
0u01/50V K 1206 X7R
0u1/50V K 1206 X7R
100pF/50V K NPO 1206
0u1/50V M 1206 X7R
220pF/50V K NPO 1206
3300pF/50V M 1206 X7R
4700pF/50V K X7R 1206
6800pF/50V K X7R 1206
10uF/16V M (R)0511 P:2
100uF/16V M (R)0611 P:5
22uF/16V M (R)0511 P:2
22uF/25V M (R)5x11 P:2.5 TAPIN
0u1/100V J P:5m/m
0u022/63V J P:5m/m
0u033/63V J P:5
0u33/63V J P:5
0u068/63V J P:5mm
PN:LT-2402-21
PN:M072M-TE1 DMP8 (JRC)
PN:TL074CDR (TI)
PN:DTC114TKA SMT3 (ROHM
PN:MMBT3904LT1 SOT23 (ON
PN:LL4148 (Vishay)
PN:0502000W1G (Red,White)
JS-1001-07
JS-1001-08
PN:211-103-000-400 3PIN
PN:211-110-000-400 10PIN
PN:211-105-000-400 5PIN
PN:A807A-RB 8PIN
PN:PCB-2(M3) 4PIN
PN:L101-T2B4QE
18x16.5x8.5mm PN:XG275M224VHS2
324uH YT-10778
PC250(t=0.8),T250MA
(t=0.8mm) PC187(0.8)
P/N:CFFH1206
P/N:S506 T2A/250V 5x20mm
C4305 25x22x1m/mPSA BLK
PN:MO-48C 25x18 t=5mm PSA
12x15 t=5mm CR PSA
196x10mm t=1mm PSA
320x10mm t=1mm PSA
EI-125 YT-10145
PN49001-WD7(46077φ16x14
PN:49001-W (18teeth)D=15.1 H=14.5
12.83x8.33x3.93"ABS 94V0
P/N:TRK-2
12.83x8.33" t=.984" SPCC
6.64"x3.50"x3.20" SPCC
PN:RF1003-BB4-0
6ft 2PIN black
20
Qty Reference Designator
4 C12,13,224,280
7 C227,229,230,232-235
2 C204,222
2 C305,306
4 C200,210,215,216
1 C281
1 C2G1
1 C212
1 C220
1 C221
2 C223,225
4 C14,15,303,304
3 C322,323,328
1 C202
2 C209,218
2 C207,208
4 C201,213,380,381
1 LED1
7 U200-205,301
1 U300
1 Q202
2 Q203,204
12 D200-205,207,209,212,216-218
1 J201
2 P3,4
1 P2
1 M3
1 M4
1 M3
1 J200
3 T1,2,3
3 SW200-202
1
1 CXAC1
1 L13
1 TER2
3 TER1,3,4
2 F1,B1
1 F1
1 R233(VR)
4 X'FORMER
1 Thermister
4
4
1
3 for VR301-303
2 for R233,216
1
5 for Q11,13,15,17,TH1
1
1
1
1
