Delta RS6002 Assembly Instructions Manual
Delta RS6002 Assembly Instructions Manual

Delta RS6002 Assembly Instructions Manual

Two bike gravity stand

Advertisement

Quick Links

Two Bike
Gravity Stand
Assembly instructions
Parts
A
x1 — H Piece
B
x2 — Straight poles
C
x1 — U piece
D
x2 — Legs
E
x4 — Arms
F
x6 — Bolts
Tool Required
Phillips Head
Screwdriver
WARNING
DO NOT EXCEED MAXIMUM TOTAL WEIGHT LIMIT OF 100 LBS (45.4 Kgs) - HDRS6002 / 80 LBS (36 Kgs) - RS6002
MAX LOAD PER HOOK: 25 LBS (11.4 kgs) / MAX WEIGHT PER BIKE: 50LBS (22.7 kgs)
RS6002 / HDRS6002
Assembly video
Visit designbydelta.com/downloads
