Delta RS5103 Assembly Instructions

Delta RS5103 Assembly Instructions

Two bike wall mount rack w/ shelf
Hide thumbs
1
2

Advertisement

Quick Links

Download this manual
Two Bike
Wall Mount
Rack w/ shelf
Assembly instructions
Parts
A
x1 — Rack Shelf
B
x1 — Shelf Support
C
x1 — Wall Bracket
D
x3 — Screws
Tool(s) Required
Phillips Head
Screwdriver
WARNING
NEVER EXCEED MAXIMUM TOTAL WEIGHT LIMIT OF 65 LBS (30 Kgs)
INCORRECT WALL MOUNTING COULD RESULT IN ITEMS FALLING AND INJURY TO PERSONS.
IMPROPER INSTALLATION OR USE CAN RESULT IN PERSONAL INJURY AND/OR DAMAGE TO
PROPERTY
RS5103
B
Drill
A
C
