IGM LAGUNA CFlux 1 Cyclone Dust Collector 230V
Manual
Producer
Laguna Tools Inc.
744 Refuge Way, Suite 200 Grand Prairie, Texas 75050
USA
Phone: +1 800-234-1976
Website:
www.lagunatools.com
Distributor
IGM nástroje a stroje s.r.o.
Ke Kopanině 560, 252 67, Tuchoměřice
Czech Republic, EU
Phone: +420 220 950 910
E-mail:
sales@igmtools.com
Website:
www.igmtools.com
2024-06-26
151-CFlux1 LAGUNA Cyclone Dust Collector Manual EN v3.01.00 A4ob
VZOR_Návod k obsluze STROJ EN v3.01.00
151-CFlux1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAGUNA CFlux 1 and is the answer not in the manual?

Questions and answers

Related Manuals for IGM LAGUNA CFlux 1

Summary of Contents for IGM LAGUNA CFlux 1

  • Page 1 151-CFlux1 IGM LAGUNA CFlux 1 Cyclone Dust Collector 230V Manual Producer Laguna Tools Inc. 744 Refuge Way, Suite 200 Grand Prairie, Texas 75050 Phone: +1 800-234-1976 Website: www.lagunatools.com Distributor IGM nástroje a stroje s.r.o. Ke Kopanině 560, 252 67, Tuchoměřice...

  • Page 2: Table Of Contents

    To obtain maximum service life and performance, use the machine according to these instructions and safety guidelines. Observe work safety. We wish you a lot of work satisfaction and joy when working with the IGM LAGUNA CFlux 1 Cyclone Dust Collector 230V.

  • Page 3: Declaration Of Conformity

    Machinery Directive. The person who compile technical file established within the EU: Name: IGM nastroje a stroje s.r.o. Address: Ke Kopanine 560, Tuchomerice, CZ-252 67 Tel.: +420 220 950 910 Email: sales@igmtools.com...

  • Page 4: Warranty

    1.1 Warranty IGM always strives to deliver a high-quality and efficient product. The warranty is governed by the valid terms and conditions of IGM. 2. Product Specifications Machine Dimensions (LxWxH): 1092 x 610 x 1753 mm Machine Weight: 125 kg...

  • Page 5: Symbols

    Never leave a running machine unattended. After you finish your work, turn off the machine and disconnect it from the power supply. Do not leave the machine in a damp environment and do not expose it to rain. Do not overload the machine. Do not operate the machine near flammable liquids or gases.

  • Page 6: Environment

    This machine is equipped with a grounded power cord. Insert the plug only into a matching outlet that is properly installed and grounded in accordance with all local regulations. Do not modify the provided plug! Do not use the machine if the power cord or plug is damaged. All repairs may be carried out only by a qualified electrician! 3.6 Environment Do not dispose of the appliance in the municipal waste.

  • Page 7: Setup

    D. Motor power cord E. Control panel pair button Used to pair remote control with the machine. Remote control The remote control requires a 12V battery type 27A. A. ON button B. OFF button C. CLEAN button (PFlux only) D. Remote control pair button Pairing remote control 1.

  • Page 8: Assembly

    The dust collector is supplied in a single box. Two persons are required to remove the machine from the box! The collector is heavy, be careful when lifting and moving. 1. Carefully cut the banding straps. 2. Cut along the tape line at the top of the box. 3.
  • Page 9 Step 4: Turn the base over with it standing on the casters. Mount the (3x) lower upright supports (top of triangles pointing inside) to the base using (6x) 3/8"x3/4" bolts and (6x) 3/8"x7/8" flat washers. A - mount the support with one triangle on the filter side. B - mount the support with two triangles on the front side.
  • Page 10 Step 7: With the help of another person, turn the collector over with it standing on the casters. Step 8: Secure the lower triangular support plate to the base using (2x) 5/16”x3/4” bolts and (2x) 5/16” washers. Follow the same steps for the opposite side. Step 9: Secure the lifting mechanism support to the lower upright support using (2x) 5/16”x1/2”...
  • Page 11 Step 11: Slide the bar into the opening on the lower upright support. Ensure that the bottom end is inserted in the lower triangular support plate. Follow the same steps for the opposite side. Step 12: Make sure the bar is pushed all the way into the opening on the lower upright support. Secure the bar using (4x) 5/16”x1-3/4”...
  • Page 12 Step 14: Attach both ends of the handle for lifting drum to the nut of the lifting mechanism. Step 15: Secure with cover. Cover is attached using (1x) M8x30 mm bolt. Follow this step on the opposite side. Step 16: Secure the bar to the handle using (2x) 3/8”x21mm bolts and 3/8” nuts . Make sure the bolt head is on the inside of the handle (A).
  • Page 13 Step 17: Attach the drum lid to the cyclone funnel with applied foam tape using (6x) 5/16”x3/4” bolts, (12x) 5/16” washers and (6x) 5/16” nuts. On the funnel you will find the following label: ATTENTION! Do not tighten the (8x) bolts that mount the cyclone funnel to the drum lid. First, perfectly align the drum lid parallel to the upright supports.
  • Page 14 Step 20: Attach the handles to the top and bottom end on the front drum panel using (4x) 5/16”x3/4” bolts, (4x) 5/16” washers and (4x) 5/16” nuts. Note that the head of the bolt must be inserted from the handle with the nut and washer on the inside of the drum.
  • Page 15 Step 23: Lay the drum on its side. With the help of another person, align the drum with the base with attached casters. Using (22x) M5 sheet metal screws fasten tightly. Step 24: Cover all (22x) screws with (22x) plastic caps. Step 25: Once assembly is complete, apply silicone (not included) to the top and bottom rim inside the drum.
  • Page 16 Step 27: Insert waste bag in the drum. Spread the bag all over the drum. Step 28: Use (24x) 3/16”x1/2” bolts and (24x) 3/16” nuts to assemble the drum insert. Place the drum insert inside over the plastic bag. Step 29: Lift the bar. Push the drum in and align. Lower the bar to seal the drum tight for normal machine operation. www.igmtools.com...
  • Page 17 Step 30: Make sure when aligning the drum that both the left and right side plates are seated in the lifting mechanism (A). When aligned incorrectly (B), the drum will not be fully sealed and will interfere with the airflow. Step 31: Mount the control panel to the switch base plate using (4x) M4x6mm bolts.

  • Page 18: Operation

    Step 33: Install the inlet adaptor with 3 openings using (3x) M4x12mm sheet metal screws. Attach the rubber caps to each opening. Assembly is now completed. 5.3 Operation 1. Remove the rubber cap from the connected opening. Check all parts of a dust collection system to ensure sufficient airflow.

  • Page 19: Replacing The Filter

    2000 hours of operation (8 hours/day x 250 days = 2000 hours). Please contact your supplier for filter replacement. 7. Accessories Recommended accessories is listed on the IGM website. Caution! Installing unapproved accessories may cause damage to the machine and serious injury. Use only accessories recommended for this machine by IGM.

  • Page 20: Wiring

    Loud or repetitive noise, excessive vibration coming Possible Solution: from machine. Possible Cause: 1) Stabilize on a flat surface. 1) Machine is on uneven surface. 2) Inspect fan for dents, bends, or other damage. 2) Damaged/Unbalanced fan. 3) Check and re-tighten all fasteners. 3) Loose connections.
  • Page 21 Control panel www.igmtools.com...

  • Page 22: Parts List

    10. Parts List www.igmtools.com...
  • Page 23 Fan, motor and switch www.igmtools.com...
  • Page 24 Cyclone and filter www.igmtools.com...
  • Page 25 Lifting mechanism Drum www.igmtools.com...
  • Page 26 www.igmtools.com...
  • Page 27 www.igmtools.com...

This manual is also suitable for:

151-cflux1

Table of Contents
