IGM LAGUNA CFlux 3 Manual

Cyclone dust collector 400v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IGM LAGUNA CFlux 3 mod.2022
Cyclone Dust Collector 400V
Manual
Producer
Laguna Tools Inc.
744 Refuge Way, Suite 200 Grand Prairie, Texas 75050
USA
Phone: +1 800-234-1976
Website:
www.lagunatools.com
Distributor
IGM nástroje a stroje s.r.o.
Ke Kopanině 560, 252 67, Tuchoměřice
Czech Republic, EU
Phone: +420 220 950 910
E-mail:
sales@igmtools.com
Website:
www.igmtools.com
2024-06-24
151-CFlux3Tv2 LAGUNA Cyclone Dust Collector Manual EN v5.01.00 A4ob
VZOR_Návod k obsluze STROJ EN v1.00.00
151-CFlux3Tv2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAGUNA CFlux 3 and is the answer not in the manual?

Questions and answers

Related Manuals for IGM LAGUNA CFlux 3

Summary of Contents for IGM LAGUNA CFlux 3

  • Page 1 151-CFlux3Tv2 IGM LAGUNA CFlux 3 mod.2022 Cyclone Dust Collector 400V Manual Producer Laguna Tools Inc. 744 Refuge Way, Suite 200 Grand Prairie, Texas 75050 Phone: +1 800-234-1976 Website: www.lagunatools.com Distributor IGM nástroje a stroje s.r.o. Ke Kopanině 560, 252 67, Tuchoměřice...

  • Page 2: Table Of Contents

    To obtain maximum service life and performance, use the machine according to these instructions and safety guidelines. Observe work safety. We wish you a lot of work satisfaction and joy when working with the IGM LAGUNA CFlux 3 mod.2022 Cyclone Dust Collector 400V.

  • Page 3: Declaration Of Conformity

    Machinery Directive. The person who compile technical file established within the EU: Name: IGM nastroje a stroje s.r.o. Address: Ke Kopanine 560, Tuchomerice, CZ-252 67 Tel.: +420 220 950 910 Email: sales@igmtools.com...

  • Page 4: Warranty

    1.1 Warranty IGM always strives to deliver a high-quality and efficient product. The warranty is governed by the valid terms and conditions of IGM. 2. Product Specifications Machine Dimensions (LxWxH): 1168 x 686 x 2286 mm Machine Weight: 169 kg...

  • Page 5: Symbols

    Keep children and other persons from moving freely around the workplace. Keep the machine out of reach of children and unqualified persons. Do not allow anyone unfamiliar with the machine and this manual to operate the machine. Never leave a running machine unattended. After you finish your work, turn off the machine and disconnect it from the power supply.

  • Page 6: Environment

    Grounding and Plug Requirements Caution! Improper grounding and connection of the machine to the power supply may result in an electric shock, damage or fire. This machine is equipped with a grounded power cord. Insert the plug only into a matching outlet that is properly installed and grounded in accordance with all local regulations.

  • Page 7: Parts Description

    X. Manual Y. Waste bags 4.2 Parts Description Control panel A. On board circuit breaker Pops out if the machine is overloaded. Allow the machine to cool down for a few minutes. Then press the reset button. B. Power cord C.

  • Page 8: Setup

    Pairing more remote controls You can pair up to 5 remotes to one machine. Each remote must be paired separately. If you pair a sixth remote to the machine, the first paired remote will be disconnected and replaced by the sixth remote. This also applies to the next remotes.
  • Page 9 Step 3: Prepare (16x) 5/16 "x3/4" bolts and (16x) 5/16" washers. Install two casters with brakes (B) to the part of the base with the drum opening and the other two casters (A) on the opposite side of the base. Step 4: Turn the base over with it standing on the casters.
  • Page 10 Step 6: Attach the intake cylinder to the dust chute with (4x) 5/16"x5/8" bolts and (4x) 5/16" washers. Then attach the cyclone barrel to the dust chute using (12x) 5/16"x3/4" bolts and (12x) 5/16" washers. Next, attach the cyclone funnel to the dust chute using (12x) 5/16"x3/4"...
  • Page 11 Step 9: With the help of another person, turn the collector over with it standing on the casters. Step 10: Apply foam tape to the edge of the plate (between the edge and screw holes). Attach the filter cover to the dust chute using (12x) 3/16“x1/2“...
  • Page 12 Step 12: Insert the rotation shaft assembly into the filter. It will be easier to insert while holding it at an angle. Insert the bottom end of the shaft into the hole in the bottom of the filter. Step 13: With the help of another person holding the filter, take the rotation shaft and push through the hole in the middle of the filter cover.
  • Page 13 Step 16: Attach and secure the rotation crank to the rotation shaft using (1x) 5/16”x3/4” bolt and (1x) 5/16” washer. Step 17: Tighten the (1x) 5/16”x3/4” screw and (1x) 5/16” washer on the bottom of the rotation shaft. Step 18: Secure the lower triangular support plate to the base using (2x) 5/16”x3/4” bolts and (2x) 5/16” washers. Follow the same steps for the opposite side.
  • Page 14 Step 20: Find the left (A) and right (B) bar for lifting mechanism. To identify the correct side, look for the protruding nut. It should be facing upwards when you place the bars on the floor. Step 21: Slide the bar into the opening on the lower upright support. Follow the same steps for the opposite side. Step 22: Make sure the bar is pushed all the way into the opening on the lower upright support.
  • Page 15 Step 24: Attach both ends of the handle for lifting drum to the nut of the lifting mechanism. Step 25: Secure with cover. Cover is attached using (1x) M8x30 mm bolt. Follow this step on the opposite side. Step 26: Secure the bar to the handle using (2x) 3/8”x21mm bolts and 3/8” nuts. Make sure the bolt head is on the inside of the handle (A).
  • Page 16 Step 27: Attach the drum lid to the cyclone funnel with applied foam tape using (6x) 5/16”x3/4” bolts, (12x) 5/16” washers and (6x) 5/16” nuts. On the funnel you will find the following label: ATTENTION! Do not tighten the (8x) bolts that mount the cyclone funnel to the drum lid. First, perfectly align the drum lid parallel to the upright supports.
  • Page 17 Step 30: Attach the handles to the top and bottom end on the front drum panel using (4x) 5/16”x3/4” bolts, (4x) 5/16” washers and (4x) 5/16” nuts. Note that the head of the bolt must be inserted from the handle with the nut and washer on the inside of the drum.
  • Page 18 Step 33: Lay the drum on its side. With the help of another person, align the drum with the base with attached casters. Using (22x) M5 sheet metal screws fasten tightly. Step 34: Cover all (22x) screws with (22x) plastic caps. Step 35: Once assembly is complete, apply silicone (not included) to the top and bottom rim inside the drum.
  • Page 19 Step 37: Insert waste bag in the drum. Spread the bag all over the drum. Step 38: Use (24x) 3/16”x1/2” bolts and (24x) 3/16” nuts to assemble the drum insert. Place the drum insert inside over the plastic bag. Step 39: Lift the bar. Push the drum in and align. Lower the bar to seal the drum tight for normal machine operation. www.igmtools.com...
  • Page 20 Step 40: Make sure when aligning the drum that both the left and right side plates are seated in the lifting mechanism (A). When aligned incorrectly (B), the drum will not be fully sealed and will interfere with the airflow. Step 41: Mount the control panel to the switch base plate using (4x) M4x6mm bolts.

  • Page 21: Operation

    Step 43: Install the inlet adaptor with 3 openings using (3x) M4x12mm sheet metal screws. Attach the rubber caps to each opening. Assembly is now completed. 5.3 Operation 1. Remove the rubber cap from the connected opening. Check all parts of a dust collection system to ensure sufficient airflow.

  • Page 22: Replacing The Filter

    2000 hours of operation (8 hours/day x 250 days = 2000 hours). Please contact your supplier for filter replacement. 7. Accessories Recommended accessories is listed on the IGM website. Caution! Installing unapproved accessories may cause damage to the machine and serious injury. Use only accessories recommended for this machine by IGM.
  • Page 23 Loud or repetitive noise, excessive vibration coming Possible Solution: from machine. Possible Cause: 1) Stabilize on a flat surface. 1) Machine is on uneven surface. 2) Inspect fan for dents, bends, or other damage. 2) Damaged/Unbalanced fan. 3) Check and re-tighten all fasteners. 3) Loose connections.

  • Page 24: Wiring

    9. Wiring Control panel www.igmtools.com...
  • Page 25 Secondary control box www.igmtools.com...

  • Page 26: Parts List

    10. Parts List www.igmtools.com...
  • Page 27 Fan, motor and switch www.igmtools.com...
  • Page 28 Cyclone and filter www.igmtools.com...
  • Page 29 Lifting mechanism Drum www.igmtools.com...
  • Page 30 Parts List CFLUX3 No 0BPart Number Part Name & Description Q’TY No 0BPart Number Part Name & Description Q’TY PDCCF32201-1 MOTOR 3HP 10B PDCCF32201-10B HEX BOLT 5/16” x 3/4” 1A PDCCF32201-1A MOTOR GASKET 10C PDCCF32201-10C FLAT WASHER 5/16”x18x2t PDCCF32201-2 MOTOR SUPPORT BASE 10E PDCCF32201-10E HEX BOLT 5/16”...
  • Page 31 14 PDCCF32201-14V2 PLASTIC BAG Ø610 x 1200mm 16N PDCCF32201-16N FLAT WASHER 1/4”x19x2mm No Part Name Description Q’TY No Part Name Description Q’TY 15 PDCCF32201-15 BASE 16O PDCCF32201-16O HEX NUT 1/4” OCTAGON DRUM BASE 15A PDCCF32201-15A HEX BOLT 3/8” x 3/4” 16P PDCCF32201-16PV2 PANEL V2.2021 15B PDCCF32201-15B...
  • Page 32 22D PDCCF32201-22D HEX BOLT 1/4” x 3/4” 33 PDCCF32201-33 FLAT HEAD BOLT M4 x 6mm 22E PDCCF32201-22E FLAT WASHER 1/4” x 19 x 2mm 34 PDCCF32201-34 RIVET 3-2 No Part Name Description Q’TY No Part Name Description Q’TY 22F PDCCF32201-22F BEARING 34C PDCCF32201-34C RIVET NUT 1/4”...
