IGM LAGUNA PFlux 1 Manual

Cyclone dust collector 230v
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
IGM LAGUNA PFlux 1 Cyclone Dust Collector 230V
Manual
Producer
Laguna Tools Inc.
744 Refuge Way, Suite 200 Grand Prairie, Texas 75050
USA
Phone: +1 800-234-1976
Website:
www.lagunatools.com
Distributor
IGM nástroje a stroje s.r.o.
Ke Kopanině 560, 252 67, Tuchoměřice
Czech Republic, EU
Phone: +420 220 950 910
E-mail:
sales@igmtools.com
Website:
www.igmtools.com
2024-06-27
151-PFlux1 LAGUNA Cyclone Dust Collector Manual EN v3.01.00 A4ob
VZOR_Návod k obsluze STROJ EN v3.01.00
151-PFlux1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LAGUNA PFlux 1 and is the answer not in the manual?

Questions and answers

Related Manuals for IGM LAGUNA PFlux 1

Summary of Contents for IGM LAGUNA PFlux 1

  • Page 1 151-PFlux1 IGM LAGUNA PFlux 1 Cyclone Dust Collector 230V Manual Producer Laguna Tools Inc. 744 Refuge Way, Suite 200 Grand Prairie, Texas 75050 Phone: +1 800-234-1976 Website: www.lagunatools.com Distributor IGM nástroje a stroje s.r.o. Ke Kopanině 560, 252 67, Tuchoměřice...

  • Page 2: Table Of Contents

    To obtain maximum service life and performance, use the machine according to these instructions and safety guidelines. Observe work safety. We wish you a lot of work satisfaction and joy when working with the IGM LAGUNA PFlux 1 Cyclone Dust Collector 230V.

  • Page 3: Declaration Of Conformity

    Machinery Directive. The person who compile technical file established within the EU: Name: IGM nastroje a stroje s.r.o. Address: Ke Kopanine 560, Tuchomerice, CZ-252 67 Tel.: +420 220 950 910 Email: sales@igmtools.com...

  • Page 4: Warranty

    1.1 Warranty IGM always strives to deliver a high-quality and efficient product. The warranty is governed by the valid terms and conditions of IGM. 2. Product Specifications Machine Dimensions (LxWxH): 1168 x 610 x 1753 mm Machine Weight: 122 kg...

  • Page 5: Symbols

    Never leave a running machine unattended. After you finish your work, turn off the machine and disconnect it from the power supply. Do not leave the machine in a damp environment and do not expose it to rain. Do not overload the machine. Do not operate the machine near flammable liquids or gases.

  • Page 6: Environment

    This machine is equipped with a grounded power cord. Insert the plug only into a matching outlet that is properly installed and grounded in accordance with all local regulations. Do not modify the provided plug! Do not use the machine if the power cord or plug is damaged. All repairs may be carried out only by a qualified electrician! 3.6 Environment Do not dispose of the appliance in the municipal waste.
  • Page 7 B. Drum illumination switch Controls the LED light on the drum lid to illuminate inside the drum for visuals of the dust level. C. Control panel pair button Used to pair remote control with the machine. D. Full drum detection When the drum is full, the machine beeps continuously and the indicator light illuminates.

  • Page 8: Setup

    Pairing more remote controls You can pair up to 5 remotes to one machine. Each remote must be paired separately. If you pair a sixth remote to the machine, the first paired remote will be disconnected and replaced by the sixth remote. This also applies to the next remotes.
  • Page 9 Step 3: Turn the base frame upside down. Prepare (16x) 5/16 "x3/4" bolts and (16x) 5/16" washers. Install two casters with brakes (B) to the part of the base with the drum opening and the other two casters (A) on the opposite side of the base.
  • Page 10 Step 6: Secure (3x) upright support reinforcement plates where the top and lower upright supports meet using (12x) 5/16 "x3/4" bolts and (12x) 5/16" washers. Step 7: With the help of another person, turn the collector over with it standing on the casters. Step 8: Attach the filter end cap to the HEPA filter using the (4x) latches.
  • Page 11 Step 9: Secure the lower triangular support plate to the base using (2x) 5/16”x3/4” bolts and (2x) 5/16” washers. Follow the same steps for the opposite side. Step 10: Secure the lifting mechanism support to the lower upright support using (2x) 5/16”x1/2” bolts, (2x) 5/16” washers and (2x) 5/16”...
  • Page 12 Step 13: Make sure the bar is pushed all the way into the opening on the lower upright support. Secure the bar using (4x) 5/16”x1-3/4” bolts, (8x) 5/16” washers and (4x) 5/16” nuts. Follow the same steps for the opposite side. Step 14: Secure the bar to the triangular support plate using (2x) 5/16”x1-3/4”...
  • Page 13 Step 17: Secure with cover. Cover is attached using (1x) M8x30 mm bolt. Follow this step on the opposite side. Step 18: Secure the bar to the handle using (2x) 3/8”x21mm bolts and 3/8” nuts. Make sure the bolt head is on the inside of the handle (A).
  • Page 14 Step 20: Attach the full drum detection sensor to the opening on the drum lid located behind the cyclone funnel. When securing the sensor make sure the end of the sensor (A) is not longer then the drum lid rim (B). If it extends past the rim, the detection will not function correctly.
  • Page 15 Step 24: Attach the handles to the top and bottom end on the front drum panel using (4x) 5/16”x3/4” bolts, (4x) 5/16” washers and (4x) 5/16” nuts. Note that the head of the bolt must be inserted from the handle with the nut and washer on the inside of the drum.
  • Page 16 Step 28: (22x) Cover all (22x) screws with (22x) plastic caps. Step 29: Once assembly is complete, apply silicone (not included) to the top and bottom rim inside the drum. This will seal the drum and prevent any leaks. Step 30: Attach the rubber gasket to the top rim of the drum. Remove excess rubber gasket. Step 31: Insert waste bag in the drum.
  • Page 17 Step 32: Use (24x) 3/16”x1/2” bolts and (24x) 3/16” nuts to assemble the drum insert. Place the drum insert inside over the plastic bag. Step 33 Lift the bar. Push the drum in and align. Lower the bar to seal the drum tight for normal machine operation. Step 34: Make sure when aligning the drum that both the left and right side plates are seated in the lifting mechanism (A).

  • Page 18: Operation

    Step 35: With the white plastic pin, you can adjust the detection rate of a full drum. Insert the tip of the pin into the top end of the sensor. Turn clockwise to lower the full detection rate (less waste in the drum). Turn counterclockwise to increase the full detection rate (more waste in the drum).

  • Page 19: Cleaning The Hepa Filter

    6. After replacing HEPA filter, press the remote control pair button five times. The LED indicator is now reset to zero. 7. Accessories Recommended accessories is listed on the IGM website. Caution! Installing unapproved accessories may cause damage to the machine and serious injury. Use only accessories recommended for this machine by IGM.

  • Page 20: Wiring

    Cyclone collector does not adequately collect dust or Possible Solution: chips; poor performance. Possible Cause: 1) Empty drum and filter end cap. Clean filter. 1) Drum or filter end cap are full. Filter is dirty. 2) Clean inlet adaptor. 2) Clogged dust collection. 3) Move the machine closer to the point of collection.
  • Page 21 Control panel www.igmtools.com...

  • Page 22: Parts List

    10. Parts List www.igmtools.com...
  • Page 23 Fan, motor and switch www.igmtools.com...
  • Page 24 Cyclone and filter www.igmtools.com...
  • Page 25 Lifting mechanism Odpadní nádoba www.igmtools.com...
  • Page 26 www.igmtools.com...
  • Page 27 www.igmtools.com...
