Product description (Fig. 1-16)

1. On/off switch
2. Locking switch
3. Handle
4. Saw head
5. Moving saw blade guard
5a. Fixing screw
6. Saw blade
7. Locking screw for rotary table
8. Stop rail
8a. Moveable stop rail
8b. Locking screw
9. Fixed saw table
10. Table inlay
11. Scale
12. Pointer
13. Rotary table
14. Locking screw for workpiece support
15. Clamping device (workpiece clamp)
16. Locking screw
17. Dust bag
18. Workpiece support
19. Locking screw for clamping device
20. Locking screw for tilt protection
21. Stand bracket
22. Adjustment screw (45°)
22a. Adjustment screw locknut (45°)
23. Locking screw
24. Clamping handle
25. Locking pin
26. Adjustment screw (90°)
26a. Adjustment screw locknut (90°)
27. Scale
28. Pointer
29. Flange screw
30. Outer flange
31. Guide bar
32. Sawing shaft lock
33. Laser ON/OFF switch
34. Battery cover
35. Laser
36. Screw (laser)
37. Transport handle
A. 90° engineers square
(not included in the scope of delivery)
B. 45° engineers square
(not included in the scope of delivery)
C. Allen key, 6 mm
D. Allen key, 3 mm
E. Philips screw (table inlay)
3

Scope of delivery

Item Quantity Designation
15. 1 x
17. 1 x
18. 2 x
21. 1 x
C. 1 x
D. 1 x
1 x
2 x
2 x
1 x
4

Proper use

The cross-cut mitre saw is used for the cutting of wood
and plastic, according to the machine size. The saw is not
suitable for the cutting of firewood.
WARNING
Do not use the product to cut materials other than those
described in the operating manual.
WARNING
The supplied saw blade is only intended for the sawing
of wood! Do not use this blade for sawing firewood!
The product may only be used in the intended manner.
Any use beyond this is improper. The user/operator, not
the manufacturer, is responsible for damages or injuries
of any type resulting from this.
Only suitable saw blades may be used for the product.
The use of any type of cutting wheels is prohibited.
An element of the intended use is also the observance of
the safety instructions, as well as the assembly instruc-
tions and operating information in the operating manual.
Persons who operate and maintain the product must be
familiar with the manual and must be informed about po-
tential dangers.
The liability of the manufacturer and resulting damages
are excluded in the event of modifications of the product.
Despite use as intended, specific risk factors cannot be
entirely eliminated. Due to the design and layout of the
product, the following risks remain:
• Contact with the saw blade in the exposed sawing ar-
ea.
• Reaching into the running saw blade (cutting injury).
• Kick-back of workpieces and workpiece parts.
• Saw blade breakage.
• Ejection of faulty carbide parts of the saw blade.
• Hearing damage when the necessary hearing protec-
tion is not used.
• Harmful emissions of wood dusts during use in en-
closed areas.
Please note that our products were not designed with the
intention of use for commercial or industrial purposes. We
assume no guarantee if the product is used in commercial
or industrial applications, or for equivalent work.
