  • Page 1 Assembly Instructions Bruksanvisning Montageanleitung discobed.de AI30001BODE-NW...
  • Page 2 IMPORTANT INFORMATION CONCERNING THIS PRODUCT TO PREVENT SERIOUS OR FATAL INJURIES Keep these instructions for future reference Read carefully and fully understand the manufacturer’s assembly. Care and special attention should be used where a warning is indicated. Never allow a child under 6 years of age on the top bed. Only one person allowed on each level. Use the bunk as it is intended –...
  • Page 3 PARTS DELER TEILE 2x Sleeping Mats 2x Matter 2x Matten 4x Stack Adapters 4x Tilleggsstykker 4x Zusatzstücke 2x Straight End Frames 2x Rette rammer 2x gerader Rahmen 2x Locking Straps 2x Sikkerhetsreimer 2x Sicherheitsriemen 8x Discs 8x Plater 8x Discs 2x Rounded End Frames 2x Runde rammer 2x Runder Rahmen...
  • Page 5 Rounded Frame Assembly Instructions Bruksanvisning for seng med runde rammer Montageanleitung für das Bett mit rundem Rahmen discobed.de...
  • Page 6 STEP 1. SECURING DISC TO SWAGED SIDE RAIL SKRITT 1. KLIKK PÅ PLASS PLATEN PÅ DEN KOMPRIMERTE SIDESTANGEN SCHRITT 1. EINRASTEN DER DISC AN DER GESTAUCHTEN SEITENSTANGE 1.1. Holding swaged rail, press pin (A) down and hold. 1.1. Hold den komprimerte sidestangen trykk på pin (A) og hold den trykket inn. 1.1.
  • Page 7 STEP 2. CONNECTING SWAGED SIDE RAIL TO STRAIGHT SIDE RAIL SKRITT 2. SAMMENFØYING AV DE KOMPRIMERTE OG RETTE SIDESTENGENE SCHRITT 2. VERBINDEN DER GESTAUCHTEN UND GERADEN SEITENSTANGEN 2.1. Attach a swaged side rail (completed in step 1) to a straight rail. 2.1.
  • Page 8 STEP 4. SECURING EACH DISC INTO THE END FRAME SKRITT 4. SIKRE PLATEN I RAMMEN SCHRITT 4. DIE DISC IN DEN RAHMEN SICHERN 4.1. Make sure pin (A) is visible, is not covered by the sleeping mat and is facing inwards. Check all four bed posts (see diag.
  • Page 9 THE ASSEMBLY OF YOUR DISC-O-BED® L/XL ROUND FRAME SINGLE COT IS NOW COMPLETE. MONTERING AV DISC-O-BED® L/XL MED RUNDE RAMMER ER NÅ KOMPLETT. DIE MONTAGE DES DISC-O-BED® L/XL MIT RUNDEM RAHMEN IST NUN KOMPLETT. STEP 5. STRAIGHT FRAME ASSEMBLY SKRITT 5. MONTERING AV SENG MED RETTE RAMMER SCHRITT 5.
  • Page 11 Bunk Assembly Instructions Monteringsanvisning av køyesenga Montageanleitung für das Etagenbett discobed.de...
  • Page 12 STEP 1. REMOVE FOOT PLUGS SKRITT 1. FJERN FOTPROPPENE SCHRITT 1. FUßPFROPFEN ENTFERNEN 1.1. Remove the 4 foot plugs from the straight bed end frame. 1.1. Fjern de re fotproppene fra den rette ramma. 1.1. Entfernen Sie die vier Fußpfropfen vom geraden Rahmen. STEP 2.
  • Page 13 STEP 3. STACK STRAIGHT END FRAME ONTO ROUNDED END FRAME SKRITT 3. Å SETTE DEN RETTE RAMMA OPPÅ DEN RUNDE RAMMA SCHRITT 3. DEN GERADEN RAHMEN AUF DEN RUNDEN RAHMEN SETZEN 3.1. Place straight end frame ( tted with stack adapters completed in step 2) onto rounded end frame. 3.1.
  • Page 14 YOU HAVE NOW SUCCESSFULLY COMPLETED THE ASSEMBLY OF YOUR DISC-O-BED® L/XL BUNK. NÅ HAR DU FULLFØRT MOTNERINGEN AV DIN DISC-O-BED® L/XL. SIE HABEN NUN DIE MONTAGE IHRES DISC-O-BED® L/XL FERTIGGESTELLT. We hope that you are completely happy with our product and it is exactly what you expected.
  • Page 15 Bench Setup Monteringsanvisning for ombygging til benk Montageanleitung für den Umbau zur Sitzbank discobed.de...
  • Page 16 STEP 1. SETTING UP BACK REST SKRITT 1. SETT OPP RYGGLENET SCHRITT 1. RÜCKENLEHNE EINRICHTEN 1.1. Lift discs 1 and 2 out of bed end frame of top cot. 1.1. Hev plate 1 og 2 ut av den øvre sengeramma 1.1.
  • Page 17 1.3. Platzieren Sie Disc 1 und 2 an der Querstange und den vertikalen Zusatzstücken. Disc 1 und 2 sollen nicht mehr vorrollen können. YOU HAVE NOW SUCCESSFULLY COMPLETED THE ASSEMBLY OF YOUR DISC-O-BED® L/XL BENCH. NÅ HAR DU FERDIG MONTERT DIN DISC-O-BED® L/XL BENK. SIE HABEN DEN ZUSAMMENBAU IHRER DISC-O-BED® L/XL SITZBANK FERTIGGESTELLT.
  • Page 18 L/XL BENCH BACK TO A BUNK CONFIGURATION Make sure pin (A) is facing inwards and not covered by sleeping mat. VIKTIGE TIPS FOR Å MONTERE DIN DISC-O-BED® L/XL BENK TILBAKE TIL KØYESENGE. Vær sikker på at pin A peker innover og ikke er tildekket av matta.
  • Page 19 Side Organizer Assembly Instructions (Optional accessory - may not come standard with your Disc-O-Bed® L/XL) Fest sidelommene Valgfritt tilbehør – er evt. Ikke en del av leveringsomfanget Anbringen der Seitentaschen optionales Zubehör – ist evtl. im Lieferumfang nicht enthalten discobed.de...
  • Page 20 STEP 1. SETTING UP SIDE-ORGANIZER SKRITT 1: FEST SIDELOMMENE SCHRITT 1: BRINGEN SIE DIE SEITENTASCHEN AN...
  • Page 21 Package Instructions Forpakningsvedlegg Verpackungsanleitung L Rounded and straight frame / Med runde og rettte rammer / mit rundem und geradem Rahmen XL Rounded and straight frame / Med runde og rettte rammer / mit rundem und geradem Rahmen...
  • Page 22 La tekstilene lufttørke. 5 PUNKTE CHECKLISTE Vergewissern Sie sich vor jedem Gebrauch, dass Sie diese Punkte befolgen bevor Sie das Disc-O-Bed® L/XL nutzen. 1. Pin (B) ist sicher in jeder Disc eingerastet. Schritt 1, Seite 5 2.
  • Page 23 WARRANTY CONDITIONS Our products are subject to strict quality controls. If a DISC-O-BED® product purchased from us does not work properly, we regret this very much and ask you to contact us at the contact address below at www.discobed.de. In addition to the statutory warranty, we grant you a guarantee on all DISC-O-BED products purchased from us, in accordance with the following provisions: YOUR LEGAL RIGHTS ARE NOT RESTRICTED BY THIS.
  • Page 24 Disc-O-Bed EU GmbH Lustgartenstraße 103 79576 Weil am Rhein PATENT AND DESIGN PROTECTED – SEE DISCOBED.COM/PATENTS © 2021 Disc-O-Bed EU GmbH. All rights reserved © 2021 Disc-O-Bed EU GmbH. Alle rettigheter forbeholdt © 2021 Disc-O-Bed EU GmbH. Alle Rechte vorbehalten discobed.de...

  • Page 25: Important Safety Warning

    If you have any questions, comments or concerns, please don’t hesitate to contact us: Disc-O-Bed EU GmbH, Lustgartenstraße 103, 79576 Weil am Rhein, Germany Tel: +49 (0)7621 1630260 Monday – Friday 8:30 to 5:00pm info@discobed.de...
