Mi-Light MiBOXER T1 Quick Start Manual

1. Features
We adopt a high precision capacitive touch screen IC. Touch
screen is very stable; 2.4GHz high RF wireless control with long
distance controlling, low power consumption and high speed
transmitting rate.
Subordinate New Brand
This product has T series and B series, and the difference is the
method of power supplying. Both series have 4 kinds: T1/B1
4-zone dimmable panel remote; T2/B2 CCT 4-zone panel remote;
T3/B3 4-zone RGB/RGBW panel remote; T4/B4 4-zone RGB+CCT
panel remote. This product widely work on our smart LED
Lighting, LED controller and smart panel controller, etc.
2. Parameters
B Series: Powered by 3V(2*AAA Battery)
Working Voltage: 3V(2*AAA Battery)
Transmitting Power: 6dBm
Standby Power Consumption: 20uA
Transmission Frequency: 2.4GHz
Panel Remote
Model No.: T1 / T2 / T3 / T4 & B1 / B2 / B3 / B4
T Series: Powered by AC100~240V
Working Voltage: AC100~240V
Standby Power: 0.15W
Transmitting Power: 6dBm
Transmission Frequency: 2.4GHz
48mm
86mm
Working Temp.: -10~40℃
Control Distance: 30m
Size: 86*86*16mm
3. Function of keys
Working Temp.: -10~40℃
Remark: When touching the button, LED indicating lamp will
Control Distance: 30m
flash once with different sound (Touch slider with no sound).
Size: 86*86*31mm
B1 & T1
4-Zone Panel Remote ( Brightness )
60S Delay OFF
ALL ON
Zone ON
Zone OFF
22mm 9mm
Touch dimming slider to change the brightness from 1~100%.
Touch master ON, turn on all linked lights.
Long press 5 seconds to turn ON the indicating sound.
When the light is ON, press "60S Delay OFF", the light will be OFF
Automatically after 60 seconds.
Touch master OFF, turn off all linked lights.
Long press 5 seconds to turn OFF the indicating sound.
Touch Zone ON, turn on zone-linked lights.
Touch Zone OFF, turn off zone-linked lights.
B2 & T2
4-Zone Panel Remote ( Color Temp. )
CCT Slider
60S Delay OFF
ALL ON
Zone ON
Dimming Slider
Zone OFF
ALL OFF
4x(un) Link Light
Touch the slider to change color temperature.
Touch dimming slider to change the brightness from 1~100%.
Touch master ON, turn on all linked lights.
Long press 5 seconds to turn ON the indicating sound.
When the light is ON, press "60S Delay OFF", the light will be OFF
Automatically after 60 seconds.
Touch master OFF, turn off all linked lights.
Long press 5 seconds to turn OFF the indicating sound.
Touch Zone ON, turn on zone-linked lights.
Touch Zone OFF, turn off zone-linked lights.
Dimming Slider
ALL OFF
4x(un) Link Light
