LED SINGLE LENS LUMINAIRE
115 W LED
Type
Standard
North American
Fresnel
305LF
305CLF
Pebble Convex
305LPB
305CLPB
V1
- FIRMWARE: V4.0
- RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is
available for download at robertjuliat.com/LED/PDF_PAGE
VALIDATION : 12/06/24
DN41202101 (EN)
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr
www.robertjuliat.com
Advertisement
Table of Contents
Related Manuals for Robert Juliat SULLY 305L
Summary of Contents for Robert Juliat SULLY 305L
- Page 1 - RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at robertjuliat.com/LED/PDF_PAGE VALIDATION : 12/06/24 DN41202101 (EN) Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - info@robertjuliat.fr www.robertjuliat.com...
-
Page 2: Table Of Contents
5.1 Local display and controls ............... 18 5.1.1 Display ......................18 5.1.2 Menu .......................19 5.1.3 Parameters ....................20 Robert Juliat reserve the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice. -
Page 3: User's Instructions
305LF: 305LF: prolonged staring into luminaire at a distance closer 0,53m 10,6m ( 1,74 ft ) (34,78 ft ) than 12.3m for the 305LPB and 10.6m for the 305LF is not expected. EN - 1 - Manual Sully 305L DN41202101... -
Page 4: Presentation
RJ45 network connector 14. Front accessories safety cable attachment point Handle 15. Focus index Safety cable attachment point 16. Local display and controls (option) Hanging yoke Tilt index Tilt locking handle 10. Focus adjustment EN - 2 - Manual Sully 305L DN41202101... -
Page 5: Identification Label
3 meter power cable ( 3G1,5 HO7RNF) with Neutrik PowerCon© True1 TOP CAL03 and CEE 7/7 (2P+T NF/SCHUKO) connectors (standard version) 1,50m power cable UL/CSA with Neutrik PowerCon© True1 TOP connector CAL04 (North American version) EN - 3 - Manual Sully 305L DN41202101... -
Page 6: Accessories
Safety cable Ø1,5 mm (length = 300 mm) for front accessory with karabiner and quick link DMXcat Bluetooth DMX/RDM Multifunction test tool - City Theatrical DMXcat® ROPT1 Narrow beam extender for 305LPB EN - 4 - Manual Sully 305L DN41202101... -
Page 7: Set-Up
Maximum : 40°F 104°F IP20 - Indoor use only 3.1.4 Hanging • Ensure fixture is correctly mounted on an appropriate support Net weight: Fresnel: 8.5 kg (18.7 lbs) Pebble: 8.8 kg (19.4 lbs) EN - 5 - Manual Sully 305L DN41202101... -
Page 8: Safety Cable
• Must be connected directly to AC power. Do not connect to dimmer power. • Automatic mains voltage detection. Daisy chain: Maximum : 22 units @ 230V Power 11 units @ 120V EN - 6 - Manual Sully 305L DN41202101... -
Page 9: Data
1 twisted pair Not used conductor of 2 twisted pair Not used conductor of 2 twisted pair DMX OUT DMX IN Daisy chain: DMX Console Maximum : 31 units total EN - 7 - Manual Sully 305L DN41202101... -
Page 10: Art-Net / Sacn
(see Web Interface section of the manual). - Web interface is always available regardless of the protocol (Art-Net / sACN) selected. RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is available for download at robertjuliat.com/LED/PDF_PAGE EN - 8 - Manual Sully 305L DN41202101... -
Page 11: Accessories
For filter dimensions, see section 4.6 The filter holder includes perforations designed for stapling to keep the gel in position. 3.4.2 Barndoors Front accessories safety cable attachment point Filter frame slot Barndoors slot EN - 9 - Manual Sully 305L DN41202101... -
Page 12: Changing Lens
3.4.3 Changing lens L150 F/2 L150 PB/2 EN - 10 - Manual Sully 305L DN41202101... -
Page 13: Narrow Beam Extender For 305Lpb
3.4.4 Narrow beam extender for 305LPB Do not fully tighten the screw 2 mm ROPT1 Rotation : 5° Lock into position Alignment with mounting holes and tighten the screws EN - 11 - Manual Sully 305L DN41202101... -
Page 14: Operations
DMX mode 8 bits – 255 steps 1 - 3 16 bits – 65 535 steps 2 - 4 4.1.3.2 Dimming curve T Set through RDM protocol, web interface or local control (option) EN - 12 - Manual Sully 305L DN41202101... -
Page 15: Set Maximum Position
T Set through RDM protocol, web interface or local control (option) Mode Result Without PWM Flicker-Free, perfect for filming PWM 17 kHz Good dimming quality (Default Value) PWM 3,2 kHz Very good dimming EN - 13 - Manual Sully 305L DN41202101... -
Page 16: Strobe
Mode Speed NONE NONE SLOW 700 ms SLOW 700 ms MEDIUM 470 ms MEDIUM 470 ms FAST 350 ms FAST 350 ms CUSTOM 0 - 4000 ms CUSTOM 0 - 4000 ms EN - 14 - Manual Sully 305L DN41202101... -
Page 17: Beam Size Adjustment
Field angle 29° 305LPB Maximum: Beam angle 67° Field angle 100° 4.4.2 Control Focus 4.5 Orientation 4.5.1 Range Function Range 0 T 360° TILT TU = 0 T 90° TD = 0 T 90° EN - 15 - Manual Sully 305L DN41202101... -
Page 18: Control
4.5.2 Control Index 4.6 Colour Fixed colour Location Front filter holder Type Standard coloured gel filter Dimensions Installation See 3.4.1 EN - 16 - Manual Sully 305L DN41202101... -
Page 19: Beam Shaping
4.7 Beam shaping 4.7.1 Range 4.7.2 Control EN - 17 - Manual Sully 305L DN41202101... -
Page 20: Controls And Parameters
Enter the current menu option and/or valid Scroll through menus and/or Increase data value Scroll through menus and/or Decrease data value Menu down and/or Increase data value Menu up and/or Decrease data value (*) If option available EN - 18 - Manual Sully 305L DN41202101... -
Page 21: Menu
(**) This function is available only when the fixture has acces to this setup mode. LOCAL POTENTIOMETER • VALUE SERVICE MESSAGE • MESSAGE (*) The number of fans may vary depending on the fixture. EN - 19 - Manual Sully 305L DN41202101... -
Page 22: Parameters
Adjust the intensity of the screen Intensity : 4 Intensity To change value, press buttons : press OK Intensity Auto-Off to validate SETUP DISPLAY AUTO OFF Always ON Auto-OFF Main display OFF after 20 seconds Intensity Auto-Off EN - 20 - Manual Sully 305L DN41202101... -
Page 23: Dmx512 - A Remote Control
16bit press OK Start address: 001 to validate DMX address of the unit from 1 to 512 DATA MODE Personality Press OK PROTOCOL PERSONALITY DMX ADDI to validate Press OK to validate EN - 21 - Manual Sully 305L DN41202101... -
Page 24: Parameters
5.2.3 Parameters 5.2.3.1 DMX Hold T Set through RDM protocol, Web interface or local control DMX512-A If data not detected Hold last values Reset DMX values Default value (Standalone value) EN - 22 - Manual Sully 305L DN41202101... -
Page 25: Dmx Chart
Cooling mode: Normal Cooling mode: Full power Front Ext disable Front Ext enable not used (*) Function activated after 5 seconds - need to go back to zero to activate second function. EN - 23 - Manual Sully 305L DN41202101... -
Page 26: Rdm Remote Control
✔ ✔ ✔ ✔ 04 00 04 01 LAMP_HOURS E1.20 ✔ ✔ ✔ ✔ ✔ ✔ Display Settings 05 01 DISPLAY_LEVEL E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ EN - 24 - Manual Sully 305L DN41202101... - Page 27 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ 85 74 DMX_ERROR_COUNTER_DESCRIPTION E1.20 ✔ ✔ ✔ ✔ 85 75 DMX_ERROR_COUNTER E1.20 ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ ✔ EN - 25 - Manual Sully 305L DN41202101...
-
Page 28: Art-Net Remote Control
(see 5.7 Web interface) Ethernet connection 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 26 - Manual Sully 305L DN41202101... -
Page 29: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG 192.168.000.013 Address Press OK DHCP ADDRESS MASK Press OK to validate to validate EN - 27 - Manual Sully 305L DN41202101... -
Page 30: Sacn Remote Control
(see 5.7 Web interface) Ethernet connection 1 - If necessary, change IP settings 2 - Set sACN universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 28 - Manual Sully 305L DN41202101... -
Page 31: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG 192.168.000.013 Address Press OK DHCP ADDRESS MASK Press OK to validate to validate EN - 29 - Manual Sully 305L DN41202101... -
Page 32: Dual Remote Control
(see 5.7 Web interface) Ethernet connection 1 - If necessary, change IP settings 2 - Set DUAL universe 3 - Set DMX address 4 - Set personality mode (see 5.2.4. DMX chart) EN - 30 - Manual Sully 305L DN41202101... -
Page 33: Local Set-Up
DHCP: ON or OFF to validate IP address of the unit DATA MODE IP CONFIG IP-ADDRESS DATA MODE IP CONFIG 192.168.000.013 Address Press OK DHCP ADDRESS MASK Press OK to validate to validate EN - 31 - Manual Sully 305L DN41202101... -
Page 34: Web Interface
5.7.4 Connect to web interface 1 - Open a web browser (Microsoft Edge, Firefox, Apple Safari...) 2 - Enter the URL address of the Sully fixture: http://2.XXX.XXX.XXX 3 - All parameters can be now modified EN - 32 - Manual Sully 305L DN41202101... -
Page 35: Cct Selection
• If the source type has to be changed or in case of typing error, it will be always possible to change the source type in the Expert mode which is protected by a password. EN - 33 - Manual Sully 305L DN41202101... -
Page 36: Leds Feedback
T Set through RDM protocol, web interface or local control (option) Mode Description Always ON Feedback LED, always ON Timer Feedback LED OFF after 20 seconds without warning Timer Feedback LED OFF after 20 seconds, ON, if warning information occurs with warning EN - 34 - Manual Sully 305L DN41202101... -
Page 37: Service
In case of problem, contact RJ distributor with the following information: • Model, version and serial number of the product. • From the menu status: - Software version - LED board IDs - Device hours • Description of the problem. EN - 35 - Manual Sully 305L DN41202101... -
Page 38: Electronic Thermal Management System
5. Open a web browser (Internet Explorer, Firefox, Chrome…) 6. Enter the URL address to connect to the web interface (see 5.7) 7. Upload your firmware file (.upd2) in the "Update firmware" section and then click on 'Submit firmware" EN - 36 - Manual Sully 305L DN41202101... -
Page 39: Factory Defaults
While holding down the reset button with a paper clip, connect the unit to power and continue to hold the reset button until the 3 status light turn green. The system is then ready for setup. Reset EN - 37 - Manual Sully 305L DN41202101... -
Page 40: Selftest
Main Power Stress PASS Dimmer Potentiometer Test POTENTIOMETER Follow the instructions. Turn potentionmeter to maximum then press OK Press OK POTENTIOMETER Side / Top ctrl => press UP Top ctrl inv => press DOWN EN - 38 - Manual Sully 305L DN41202101... - Page 41 DMX OUT fail or NO DMX Signal Leds Test LEDS green LEDS blue LEDS Test Report test report: Fail P=Pass F=Fail To be communicated to RJ Service if requested : fans P temp dmxi service@robertjuliat.fr dmxo EN - 39 - Manual Sully 305L DN41202101...
