LED SINGLE LENS LUMINAIRE
115 W LED
Type
Standard
North American
Fresnel
305LF
305CLF
Pebble Convex
305LPB
305CLPB
V1
- FIRMWARE: V3.0
- RJ-LED2 FIRMWARE PLATFORM (Node Mode) full manual is
available for download at robertjuliat.com/LED/PDF_PAGE
VALIDATION : 24/03/22
DN41202100-A (EN)
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - fax : +33 (0)3 44 26 90 79 - info@robertjuliat.fr
www.robertjuliat.com
Advertisement
Table of Contents
Related Manuals for Robert Juliat SULLY 305L
Summary of Contents for Robert Juliat SULLY 305L
- Page 1 VALIDATION : 24/03/22 DN41202100-A (EN) Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - fax : +33 (0)3 44 26 90 79 - info@robertjuliat.fr www.robertjuliat.com...
-
Page 2: Table Of Contents
6.4 Firmware update ..................................................33 6.5 Factory defaults .................................................... 34 6.5.1 Modes ............................................................34 6.5.2 Control ...........................................................34 Robert Juliat reserve the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice. -
Page 3: User's Instructions
1 User’s instructions GENERAL INSTRUCTIONS Not for residential use. These fixtures must only be serviced by a qualified technician. In addition to the instructions indicated on this page, relevant health and safety requirements of the appropriate EU Directives must be adhered to at all times. This fixture is in compliance with section 17 - Lighting appliance for theatre stages, television, cinema and photograph studios. -
Page 4: Presentation
2 Presentation 2.1 Functions Description Identification plates 11. Lens (Fresnel or Pebble) Data connector (IN and OUT) 12. Accessories and colour filter holders Power connector (IN and OUT) 13. Accessories and colour filter holders locking system RJ45 network connector 14. Front accessories safety cable attachment point Handle 15. -
Page 5: Identification Label
2.2 Identification label Description 1. MOD. : Model 18 15 16 2. VERS. : Version 3. U : Nominal voltage input (V) 4. I : Nominal intensity (A) 5. P : Maximum power input (W) 6. IP : International Protection Rating 7. -
Page 6: Accessories
2.4 Accessories Reference Description Ø150mm Fresnel lens with double slot front cassette for 180x180mm accessories - L150 F/2 weight: 0.8 Kg Ø150mm Pebble convex lens with double slot front cassette for 180x180mm accessories - L150 PB/2 weight: 1.25 Kg PCP1716A 16A blue 2P+E 6h IEC60309 power connector PF500M2 180 x 180 mm metal filter holder... -
Page 7: Set-Up
3 Set-up 3.1 Mechanics 3.1.1 Operating positions 90° 90° 3.1.2 Minimum distance between a flammable material and the lighting unit 0,2 m / 0.7 ft 5°C 40°C 3.1.3 Instructions for use Minimum : Maximum : 40°F 104°F IP20 - Indoor use only 3.1.4 Hanging •... -
Page 8: Safety Cable
3.1.5 Safety cable • When hung or flown the fixture must be secured by an additional hanging accessory (such as a safety bond or cable) of suitable length. • The combined weight of both the fixture and the accessories must be considered when choosing the load-bearing capability of safety cable or bond. -
Page 9: Data
Power cable Power cable Connector Mains plug Cable type Cable length Wiring Live: Brown Standard 3G1.5 CEE7/7 Neutral: Blue version H07RNF 9.8 ft ® Neutrik powerCON Ground: Yellow/Green TRUE1 TOP North 14AWG Live: Black NAC3FX-W-TOP 1.5 m American SJ TYPE Neutral: White 4.9 ft version... -
Page 10: Art-Net / Sacn
3.3.2 Art-Net / sACN Protocol Input connector Output connector Art-Net RJ45 sACN Daisy chain: Fixture Fixture Fixture Art-Net sACN Network switch* Lighting desk interface (*) A 1000 base-T switch that supports IGMP (Internet Group Management Protocol) is necessary if the unit is connected to a network switch to control multiple devices. -
Page 11: Accessories
3.4 Accessories 3.4.1 Front filter holder For filter dimensions, see section 4.6 The filter holder includes perforations designed for stapling to keep the gel in position. 3.4.2 Barndoors Front accessories safety cable attachment point Filter frame slot Barndoors slot EN - 9 -... -
Page 12: Changing Lens
3.4.3 Changing lens L150 F/2 L150 PB/2 EN - 10 -... -
Page 13: Operations
4 Operations 4.1 Light intensity 4.1.1 Range 100% 4.1.2 Control compatible DMX512-A device interface Remotely with DMX512-A / T Set through RDM protocol or Locally, when equipped with Art-Net / sACN protocols. web interface this option HTP mode (Highest Takes Precedence): Light output is the highest value of DMX512 command or local control Focus mode: when standby screen displayed, Push Exit for 3 secs →... -
Page 14: Set Maximum Position
4.1.3.3 Set maximum position T Set through RDM protocol, web interface or local control (option) 100% ----> Maximum (80%) 100% 4.1.3.4 Dimming mode T Set through RDM protocol, web interface or local control (option) Mode Result Without PWM Flicker-Free, perfect for filming PWM 17 kHz Good dimming quality (Default Value) PWM 3,2 kHz... -
Page 15: Strobe
4.2 Strobe 4.2.1 Range Strobe duration 255 = 20ms 0 = OFF 1 = 1ms Strobe speed 0 = 0.1Hz 255 = 10Hz 4.2.2 Control T Remotely with DMX512-A / Art-Net / sACN protocols / local control (option) Mode 3 – 4 DMX512-A 4.3 Response time 4.3.1 Range... -
Page 16: Beam Size Adjustment
4.4 Beam size adjustment 4.4.1 Range Minimum: Beam angle 8° Field angle 16° 305LF Maximum: Beam angle 60° Field angle 90° Minimum: Beam angle 18° Field angle 29° 305LPB Maximum: Beam angle 67° Field angle 100° 4.4.2 Control Focus 4.5 Orientation 4.5.1 Range Function Range... -
Page 17: Control
4.5.2 Control Index 4.6 Colour Fixed colour Location Front filter holder Type Standard coloured gel filter Dimensions Installation See 3.4.1 EN - 15 -... -
Page 18: Beam Shaping
4.7 Beam shaping 4.7.1 Range 4.7.2 Control EN - 16 -... -
Page 19: Controls And Parameters
5 Controls and parameters 5.1 Web interface 5.1.1 Control Ethernet connection The fixture must be connected to a compatible network or directly to a computer using an ethernet cable. 5.1.2 Default IP address By defaut : DHCP = OFF Address = 2.XXX.XXX.XXX Mask = 255.0.0.0 T If address unknown (due to previous modification) you can retrieve the current IP address with an RDM Controller or RDM Test Tool. - Page 20 After updating your device with firmware V3.0, we strongly recommend that you update the source type (CCT) either to CW (Cold White) or WW (Warm White) by following the procedure described in the section below: 5.1.5 CCT selection 5.1.5 CCT selection Until now, the CCT of the LED source was not taken into account.
-
Page 21: Leds Feedback
5.2 LEDs Feedback 5.2.1 Trouble shooting • During unit initialisation (power up) – up to 5 seconds: Description DMX OUT DMX IN Network Unit OFF Unit error Unit has been reset successfully RDM protocol activated • After initialisation - Node mode "OFF": DMX OUT DMX IN Network... -
Page 22: Dmx512 - A Remote Control
5.3 DMX512 - A remote control 5.3.1 Protocol E1.11 – 2008, USITT DMX512-A 5.3.2 Configuration Set mode through web interface Set mode through RDM protocol Locally, when equipped with this option compatible device 1 - Set DMX address 2 - Set personality mode (see 5.3.4. DMX chart) Data Mode Protocol DATA MODE... -
Page 23: Parameters
5.3.3 Parameters 5.3.3.1 DMX Hold T Set through RDM protocol or web interface or local control (option) DMX512-A If data not detected Hold last values Reset DMX values Default value (Standalone value) EN - 21 -... -
Page 24: Dmx Chart
5.3.4 DMX chart Mode 1: Mode 2: Mode 3: Mode 4: DMX Channel Dimmer8B Dimmer16B Profile8B Profile16b Dimmer Dimmer Dimmer Dimmer Dimmer fine Strobe duration Dimmer fine Strobe speed Strobe duration Response time Strobe speed Control mode Response time Control mode 5.3.5 DMX ranges 5.3.5.1 Strobe duration Range min... -
Page 25: Rdm Remote Control
5.4 RDM remote control 5.4.1 Protocol ANSI E1.20 – 2010 / ANSI E1.37 - 1 For more information about RDM protocol: http://www.rdmprotocol.org/ 5.4.2 Functions 115W LED PROFILE Function description Queued Message Network Management DISCOVERY_UNIQUE_BRANCH DISCOVERY_MUTE DISCOVERY_UNMUTE COMMUNICATION_STATUS Status Collection QUEUED_MESSAGE STATUS_MESSAGES STATUS_ID_DESCRIPTION CLEAR_STATUS_ID... - Page 26 115W LED PROFILE Function description Queued Message Control IDENTIFY_DEVICE RESET_DEVICE PERFORM_SELFTEST SELF_TEST_DESCRIPTION RDMnet Management LIST_INTERFACES INTERFACE_LABEL INTERFACE_HARDWARE_ADRESS_TYPE1 IPV4_DHCP_MODE IPV4_CURRENT_ADDRESS IPV4_STATIC_ADDRESS INTERFACE_RELEASE_DHCP INTERFACE_APPLY_CONFIGURATION IPV4_DEFAULT_ROUTE DNS_IPV4_NAME_SERVER DNS_HOSTNAME PID Manufacturer SELFTEST_RESULT CURRENT_IP_ADDRESS CURRENT_NETMASK CURRENT_DRIVER_STATUS CUSTOM_RESPONSE_TIME_DESCRIPTION CUSTOM_RESPONSE_TIME_VALUE DATA_MODE_DESCRIPTION DATA_MODE_VALUE STANDALONE_VALUE_DESCRIPTION STANDALONE_VALUE SACN_UNIVERSE_VALUE_DESCRIPTION SACN_UNIVERSE_VALUE ARTNET_UNIVERSE_VALUE_DESCRIPTION ARTNET_UNIVERSE_VALUE SERIAL_DESCRIPTION SERIAL...
-
Page 27: Art-Net Remote Control
5.5 Art-Net remote control 5.5.1 Protocol Artistic Licence Art-Net v3 For more information about Art-Net protocol: http://art-net.org.uk/ 5.5.2 Configuration Set mode through web interface Locally, when equipped with this option (see 5.1 Web interface) 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 2 - Set personality mode (see 5.3.4. -
Page 28: Local Set-Up
5.5.3 Local set-up Caution: (*) Activate Art-Net in protocol mode beforehand. step 1 DATA MODE Data Mode step 2 Protocol press OK press OK DATA MODE STATUS SETUP FAC PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate to enter step 2 step 1 DATA MODE... -
Page 29: Sacn Remote Control
5.6 sACN remote control 5.6.1 Protocol ANSI E1.31 – 2009 sACN (Streaming-ACN) 5.6.2 Configuration Set mode through web interface Locally, when equipped with this option (see 5.1 Web interface) 1 - If necessary, change IP settings 2 - Set sACN universe 3 - Set DMX address 2 - Set personality mode (see 5.3.4. -
Page 30: Local Set-Up
5.6.3 Local set-up Caution: (*) Activate sACN in protocol mode beforehand. step 1 DATA MODE Data Mode step 2 Protocol press OK press OK DATA MODE STATUS SETUP FAC PROTOCOL PERSONALITY DMX ADDI Press OK to validate to validate to enter step 2 step 1 DATA MODE... -
Page 31: Local Display And Controls (Option)
5.7 Local display and controls (option) 5.7.1 Display Function Exit the current menu option and/or go back Press for 3 secs to enter Focus mode Enter the current menu option and/or valid Scroll through menus and/or Increase data value Scroll through menus and/or Decrease data value Scroll through menus and/or Increase data value Scroll through menus and/or Decrease data value EN - 29 -... -
Page 32: Menus
5.7.2 Menus DATA FACTORY STATUS SETUP BOOT MODE DEFAULT Reset to factory settings. PROTOCOL DISPLAY • DMX • INTENSITY SELFTEST • RDM • AUTO OFF • ARTNET • SACN • STANDALONE SYSTEM ID DATA SETUP • SERIAL NUMBER • DMX HOLD PERSONALITY •... -
Page 33: Parameters
5.7.3 Parameters Selection in SETUP/DISPLAY MODE menu → Display Mode Description 000% Always ON Main display (home screen) always ON NODE MASTER SETUP DISPLAY INTENSITY Adjust the intensity of the screen Intensity Intensity : 4 To change value, press buttons : press OK Intensity Auto-Off... -
Page 34: Service
6 Service 6.1 Preventive maintenance 6.1.1 Frequency General maintenance should be performed at least once a year or more frequently if the equipment is operated in adverse conditions (smoke, heat, humidity, touring, etc.). 6.1.2 General cleaning Remove dust from the unit. Front glasses can be cleaned with solutions containing alcohol. -
Page 35: Electronic Thermal Management System
6.3 Electronic thermal management system In case of overheating, light intensity will be reduced by the system. Power reduction and temperature values are available by using a RDM protocol compatible device. 6.4 Firmware update After updating your device with firmware V3.0, we strongly recommend that you update the source type (CCT) either to CW (Cold White) or WW (Warm White) by following the procedure described in the section below: CCT selection CCT selection... -
Page 36: Factory Defaults
6.5 Factory defaults 6.5.1 Modes Mode Description Restart Software reset – all user parameters are kept Factory defaults Set all user parameters to factory default value 6.5.2 Control Set to factory defaults / Set to factory defaults / Set to factory defaults / reset through web interface reset through RDM protocol reset through local control,...
