LED SINGLE LENS LUMINAIRE
115W LED SINGLE LENS LUMINAIRE
Type
Standard
North American
Fresnel
305LF
305CLF
Pebble Convex
305LPB
305CLPB
Version V1
VALIDATION : 09/06/21
DN41202100 (EN)
Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - fax : +33 (0)3 44 26 90 79 - info@robertjuliat.fr
www.robertjuliat.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Robert Juliat SULLY 305LF
Summary of Contents for Robert Juliat SULLY 305LF
- Page 1 305LPB 305CLPB Version V1 VALIDATION : 09/06/21 DN41202100 (EN) Robert Juliat S.A.S. 32, rue de Beaumont, F 60530 Fresnoy-en-Thelle - phone : +33 (0)3 44 26 51 89 - fax : +33 (0)3 44 26 90 79 - info@robertjuliat.fr www.robertjuliat.com...
-
Page 2: Table Of Contents
6.4 Firmware update ..............................................24 6.5 Factory defaults ............................................... 24 6.5.1 Modes ......................................................24 6.5.2 Control ......................................................24 Robert Juliat reserve the right to change or alter any of the items detailed on this page, to increase or improve manufacturing techniques without prior notice. -
Page 3: User's Instructions
1 User’s instructions GENERAL INSTRUCTIONS Not for residential use. These fixtures must only be serviced by a qualified technician. In addition to the instructions indicated on this page, relevant health and safety requirements of the appropriate EU Directives must be adhered to at all times. This fixture is in compliance with section 17 - Lighting appliance for theatre stages, television, cinema and photograph studios. -
Page 4: Presentation
2 Presentation 2.1 Functions Description Identification plates 11. Lens (Fresnel or Pebble) Data connector (IN and OUT) 12. Accessories and colour filter holders Power connector (IN and OUT) 13. Accessories and colour filter holders locking RJ45 network connector system Handle 14. -
Page 5: Identification Label
2.2 Identification label Description 1. MOD. : Model 18 15 16 2. VERS. : Version 3. U : Nominal voltage input (V) 4. I : Nominal intensity (A) 5. P : Maximum power input (W) 6. IP : Ingress Protection (IP) rating 7. -
Page 6: Accessories
2.4 Accessories Parts list ref. Parts number Description Ø150mm Fresnel lens with double slot front cassette for 180x180mm accessories PD00000031 L150 F/2 - weight: 0.8 Kg Ø150mm Pebble convex lens with double slot front cassette for 180x180mm accessories PD00000032 L150 PB/2 - weight: 1.25 Kg FJUC000059 PCP1716A... -
Page 7: Set-Up
3 Set-up 3.1 Mechanics 3.1.1 Operating positions 90° 90° 3.1.2 Minimum distance between a flammable material and the lighting unit 0,2 m / 0.7 ft 5°C 40°C 3.1.3 Instructions for use Minimum : Maximum : 40°F 104°F IP20 - Indoor use only 3.1.4 Hanging •... -
Page 8: Safety Cable
3.1.5 Safety cable • When hung or flown the fixture must be secured by an additional hanging accessory (such as a safety bond or cable) of suitable length. • The combined weight of both the fixture and the accessories must be considered when choosing the load-bearing capability of safety cable or bond. -
Page 9: Data
Power cable Power cable Connector Mains plug Cable type Cable length Wiring Live: Brown Standard 3G1.5 CEE7/7 Neutral: Blue version H07RNF 9.8 ft ® Neutrik powerCON Ground: Yellow/Green TRUE1 TOP North 14AWG Live: Black NAC3FX-W-TOP 1.5 m American SJ TYPE Neutral: White 4.9 ft version... -
Page 10: Art-Net Sacn
3.3.2 Art-Net / sACN • With external switch Protocol Input connector Output connector Art-Net RJ45 sACN Daisy chain: Art-Net sACN Network switch* (*) A 1000 base-T switch that supports IGMP (Internet Group Management Protocol) is necessary if the unit is connected to a network switch to control multiple devices. -
Page 11: Barndoors
3.4.2 Barndoors Front accessories safety cable attachment point Filter frame slot Barndoors slot 3.4.3 Changing lens L150 F/2 L150 PB/2 EN - 9 -... -
Page 12: Operations
4 Operations 4.1 Light intensity 4.1.1 Range 100% 4.1.2 Control compatible device DMX512-A interface Remotely with DMX512-A / Art-Net / sACN protocols. Locally with DMX 512-A/Art-Net/sACN protocols. T Set through RDM protocol or web interface 4.1.3 Parameters 4.1.3.1 Dimming resolution - DMX only T Set through RDM protocol or web interface Resolution DMX mode... -
Page 13: Set Maximum Position
4.1.3.3 Set maximum position T Set through RDM protocol or web interface 100% ----> Maximum (80%) 100% 4.1.3.4 Dimming mode T Set through RDM protocol or web interface Mode Result Without PWM Flicker-Free, perfect for filming PWM 17 kHz Good dimming quality (Default Value) PWM 3,2 kHz Very good dimming EN - 11 -... -
Page 14: Strobe
4.2 Strobe 4.2.1 Range Strobe duration 255 = 20ms 0 = OFF 1 = 1ms Strobe speed 0 = 0.1Hz 255 = 10Hz 4.2.2 Control T Remotely with DMX512-A / Art-Net / sACN protocols Mode 3 – 4 DMX512-A 4.3 Response time 4.3.1 Range X ms DMX 0 = 0 ms... -
Page 15: Beam Size Adjustment
4.4 Beam size adjustment 4.4.1 Range Minimum: Beam angle 8° Field angle 16° 305LF Maximum: Beam angle 60° Field angle 90° Minimum: Beam angle 18° Field angle 29° 305LPB Maximum: Beam angle 67° Field angle 100° 4.4.2 Control Focus 4.5 Orientation 4.5.1 Range Function Range... -
Page 16: Control
4.5.2 Control Index 4.6 Colour Fixed colour: Location Front filter holder Type Standard coloured gel filter Dimensions Installation See 3.4.1 EN - 14 -... -
Page 17: Beam Shaping
4.7 Beam shaping 4.7.1 Range 4.7.2 Control EN - 15 -... -
Page 18: Controls And Parameters
5 Controls and parameters 5.1 Web interface 5.1.1 Control Ethernet connection The fixture must be connected to a compatible network or directly to a computer using an ethernet cable. 5.1.2 Default IP address By defaut : DHCP = OFF Address = 2.XXX.XXX.XXX Mask = 255.0.0.0 T If IP address unknown (due to a previous modification), a hard reset must be done (see 6.5 Factory defaults). -
Page 19: Leds Feedback
5.2 LEDs Feedback 5.2.1 Trouble shooting: • During unit initialisation (power up) – up to 5 seconds: Description DMX OUT DMX IN Network Unit OFF • After initialisation: Unit error DMX OUT DMX IN Network Unit has been reset Display auto-off successfully No ethernet RDM protocol activated... -
Page 20: Dmx512 - A Remote Control
5.3 DMX512 - A remote control 5.3.1 Protocol: E1.11 – 2008, USITT DMX512-A 5.3.2 Configuration: Set mode through web interface Set mode through RDM protocol compatible device 1 - Set DMX address 2 - Set personality mode (see 5.3.4. DMX chart) 5.3.3 Parameters: 5.3.3.1 DMX Hold T Set through RDM protocol or web interface... -
Page 21: Dmx Chart
5.3.4 DMX chart: Mode 1: Mode 2: Mode 3: Mode 4: DMX address Dimmer8B Dimmer16B Profile8B Profile16b Dimmer Dimmer Dimmer Dimmer Dimmer fine Strobe duration Dimmer fine Strobe speed Strobe duration Response time Strobe speed Control mode Response time Control mode 5.3.5 DMX ranges: 5.3.5.1 Strobe duration Range min... -
Page 22: Rdm Remote Control
5.4 RDM remote control ANSI E1.20 – 2010 / ANSI E1.37 - 1 5.4.1 Protocol: For more information about RDM protocol: http://www.rdmprotocol.org/ 115W LED PROFILE Function description V2.20 Queued Message Network Management DISCOVERY_UNIQUE_BRANCH DISCOVERY_MUTE DISCOVERY_UNMUTE COMMUNICATION_STATUS Status Collection QUEUED_MESSAGE STATUS_MESSAGES STATUS_ID_DESCRIPTION CLEAR_STATUS_ID RDM Information... - Page 23 115W LED PROFILE Function description V2.20 Queued Message Control IDENTIFY_DEVICE RESET_DEVICE PERFORM_SELFTEST SELF_TEST_DESCRIPTION RDMnet Management LIST_INTERFACES INTERFACE_LABEL INTERFACE_HARDWARE_ADRESS_TYPE1 IPV4_DHCP_MODE IPV4_CURRENT_ADDRESS IPV4_STATIC_ADDRESS INTERFACE_RELEASE_DHCP INTERFACE_APPLY_CONFIGURATION IPV4_DEFAULT_ROUTE DNS_IPV4_NAME_SERVER DNS_HOSTNAME PID Manufacturer SELFTEST_RESULT CURRENT_IP_ADDRESS CURRENT_NETMASK CURRENT_DRIVER_STATUS CUSTOM_RESPONSE_TIME_DESCRIPTION CUSTOM_RESPONSE_TIME_VALUE DATA_MODE_DESCRIPTION DATA_MODE_VALUE STANDALONE_VALUE_DESCRIPTION STANDALONE_VALUE SACN_UNIVERSE_VALUE_DESCRIPTION SACN_UNIVERSE_VALUE ARTNET_UNIVERSE_VALUE_DESCRIPTION ARTNET_UNIVERSE_VALUE SERIAL_DESCRIPTION...
-
Page 24: Art-Net Remote Control
5.5 Art-Net remote control Artistic Licence Art-Net v3. 5.5.1 Protocol: For more information about Art-Net protocol: http://art-net.org.uk/ 5.5.2 Configuration: Set mode through web interface (see 5.1 Web interface) 1 - If necessary, change IP settings 2 - Set Art-Net Universe 3 - Set DMX address 2 - Set personality mode (see 5.3.4. -
Page 25: Service
6 Service 6.1 Preventive maintenance 6.1.1 Frequency General maintenance should be performed at least once a year or more frequently if the equipment is operated in adverse conditions (smoke, heat, humidity, touring, etc.). 6.1.2 General cleaning Remove dust from the unit. Front glasses can be cleaned with solutions containing alcohol. -
Page 26: Electronic Thermal Management System
6.3 Electronic thermal management system In case of overheating, light intensity will be reduced by the system. Power reduction and temperature values are available by using a RDM protocol compatible device. 6.4 Firmware update 1. Firmware available on www.robertjuliat.com/singlelenslum/SULLY_305L 2. Download and unzip the file 3.
