- Page 1 ETAS ES584.2 CAN FD and LIN Bus Interface USB Module User Guide...
- Page 2 Copyright The data in this document may not be altered or amended without special notification from ETAS GmbH. ETAS GmbH undertakes no further obligation in relation to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
-
Page 3: Table Of Contents
Verifying the Installation of the USB Driver ......... . 20 ETAS ES584.2 | User Guide... - Page 4 Index ................43 ETAS ES584.2 | User Guide...
-
Page 5: Safety Notices
Program codes or program control sequences that are created or changed via ETAS products, as well as all types of data obtained through the use of ETAS prod- ucts, must be checked for their reliability and suitability prior to use or distribution. -
Page 6: Intended Use
The product is designed in accordance with state-of-the-art technology. Only operate the product and its accessories if they are in perfect working order. Shut down a damaged product immediately. Do not open or alter the product. Only ETAS may make changes to the product. -
Page 7: Assembly
Install the product on a smooth, level and firm surface. WARNING The following product is a Class A piece of equipment: ES584.2 This piece of equipment may cause radio interference in living areas. In this case, the user may be required to take appropriate measures. -
Page 8: Operation
If the firmware update is not completed successfully, try it again. If a new firmware update is not possible and the product is not functional, send the product to ETAS. WARNING Risk due to undefined vehicle behavior during an ECU reset If you operate the product in combination with ETKs, the ECU must not be reset in an uncontrolled manner. -
Page 9: Cables And Accessories
- Make sure that no moisture enters the product. Repairs If repairs are required, send the product to ETAS. 1.10 Shipment and Packaging You can find the return form and information about this process on the ETAS web- site: www.etas.com/en/support/hw_return_form.php. ETAS ES584.2 | User Guide... - Page 10 • Updating the Firmware ........... 16 Overview The ES584.2 CAN FD and LIN Bus Interface USB Module is part of the range of com- pact ETAS bus interface modules. It is equipped with a CAN/CAN FD interface and with a LIN interface for connection to vehicle buses or ECUs, as well as a USB port for connection to a PC or a drive recorder.
-
Page 11: Hardware Description
- Integration of the module into the BUSMASTER open source software or via EBI-IP into application software from third-party manufacturers Properties The most important properties of the ES584.2 CAN FD and LIN Bus Interface USB Module at a glance: - 1 CAN/CAN FD interface •... -
Page 12: Function Groups
FD nodes can easily be integrated into the existing CAN infrastructure. The ES584.2 CAN FD and LIN Bus Interface USB Module has a CAN interface CAN on its nine-pin DSUB socket. The CAN interface is an independent CAN channel with its own CAN controller. -
Page 13: Feature
13 | Hardware Description 2.5.3 Feature The CAN applications supported by the ES584.2 are located in an overview in chapter 5.10.2 on page 30. 2.5.4 Bus Terminating Resistor The CAN interface requires the use of bus terminating resistors in both operating modes. -
Page 14: Voltage Supply On The Lin Bus
Voltage supply on the LIN bus (pin assignment on the CBCF100 cable) 12 V LIN systems In 12 V LIN systems, the LIN node of the ES584.2 module can either be supplied externally by the LIN bus or internally by the module with the LIN reference voltage 24 V LIN systems In 24 V LIN systems, the LIN node of the ES584.2 module can only be supplied... -
Page 15: Usb Port
Power Supply The ES584.2 module is powered via the USB port of a PC or a drive recorder. The module does not require an external power supply. Information on the require- ments for the PC's USB port can be found in chapter 5.10.1 on page 29. -
Page 16: Multi-Client Support
2.12 Updating the Firmware The firmware of the ES584.2 can be updated by the user so that future versions of the module can also be used. The firmware update is performed using the ETAS service software "Hardware Service Pack" (HSP) from the connected PC. -
Page 17: Commissioning
Preparing to Install NOTE The latest USB driver must be installed on the PC in order to operate the ES584.2 module. The ES584.2 can be installed on plug & play-compatible operating systems (min. Windows 10). Following installation of the driver, you can use/remove the ES584.2 module at any time. -
Page 18: Installation Procedure
3.2.3 Installation Procedure Commissioning of the ES584.2 must be performed in the following sequence: 1. Installation of the USB drivers (ES584.2 not connected to the PC) 2. Establishing the USB connection 3. Establishing the CAN connection ETAS ES584.2 | User Guide... -
Page 19: Verifying The Installation Of The Usb Driver
For compatibility reasons, the ES584.2 is displayed in the device manager as "ES584.1". Verifying the installation of the USB driver: 1. Connect the ES584.2 module to the USB port on the PC or drive recorder. 2. Select Start Control Panel ... -
Page 20: Updating The Usb Driver
20 | Commissioning Updating the USB Driver The ES584.2 update must be performed in the following sequence: 1. Ensure that the client software applications are closed. 2. Start the installation program and uninstall the old driver. 3. Install the new driver. -
Page 21: Troubleshooting Problems
23 | Troubleshooting Problems Troubleshooting Problems This chapter provides information on what you can do when problems arise with the ES584.2 and when general problems arise that are not specific to an individual software or hardware product. Displays of the LEDs When assessing the operating state and rectifying faults on the ES584.2, note the... - Page 22 Check whether the "ER" LED is flashing: In certain circum- stances, the baud rate may not be supported by the mod- ule. You can find information on the supported baud rates in chapter 5.10.2 on page 32. ETAS ES584.2 | User Guide...
-
Page 23: Technical Data
350 mA Current consumption, max. ES584.2 Product designation Manufacturer's address Marking for China RoHS, see chapter on page 27 Marking for RoHS, see chapter on page 27 Marking for CE conformity (Chapter 5.3 on page 27) ETAS ES584.2 | User Guide... -
Page 24: Standards
-40 °C to +85 °C (without packaging) -40 °F to +185 °F Max. relative humidity (non-condensing) Max. altitude 5000 m / 16400 ft Degree of contamination (IEC 60664-1, IEC 61010-1) Protection rating IP52 (when closed) ETAS ES584.2 | User Guide... -
Page 25: Rohs Conformity
Methods for Controlling Pollution Caused by Electronic Information Products Reg- ulation) applicable in the People's Republic of China. CE conformity With the CE mark attached to the product or its packaging, ETAS confirms that the product corresponds to the product-specific, applicable directives of the Euro- pean Union. -
Page 26: Open Source Software
The user is obligated to separately collect old devices and hand them over to the WEEE return system for recycling. The WEEE Directive applies to all ETAS devices, but not to external cables or bat- teries. Additional information about the recycling program of ETAS GmbH is available from the ETAS sales and service locations (see chapter 5 on page 25). -
Page 27: System Requirements
The module must be operated directly at the USB port of a PC, a drive recorder or an active hub, whose USB interface meets the requirements stated in the table. The use of USB cables to extend the connection between ES584.2 and the PC or drive recorder is not permitted. -
Page 28: Software
Supported software interfaces ETAS offers the "ECU and Bus Interfaces – Integration Package" (EBI-IP) software development kit for integration of the ES584.2 module and the J2534 interface into application software from third-party manufacturers. The software development kit can be downloaded free-of-charge from the down- load center on the ETAS website. -
Page 29: Electrical Data
Max. 1 MBaud for 20 m bus length CAN FD SIC (data): Max. 5 Mbit/s (oper- ating temperature range) CAN FD SIC (data): Max. 8 Mbit/s (room temperature) CAN interface clients Max. 2 Controller ARM Cortex MCU Transceiver (physical layer) TJA1462BT ETAS ES584.2 | User Guide... -
Page 30: Lin Interface
Compatible with the LIN standard used by Client 1 Electrical isolation Interface separated from the other interfaces : Selection of internal LIN V by INCA currently in preparation : Support for master operating mode by INCA currently in preparation ETAS ES584.2 | User Guide... -
Page 31: Terminal Assignment
Terminal Assignment NOTE All connections are shown with view of the module interfaces. The CAN bus is connected to the ES584.2 CAN FD and LIN Bus Interface USB Mod- ule via the nine-pin DSUB connector (see Fig. 5-3). Fig. 5-3 ES584.2 DSUB connector... -
Page 32: Cables And Accessories
Assigning DSUB connectors "1" and "2" of the CBCF100 cable to the ES584.2 If a CBCF100 cable is used at the CAN/LIN interface of the ES584.2 module, the interfaces are assigned to DSUB connectors "1" and "2" of the cable as follows: ES584.2... - Page 33 Signal (LIN) CAN 1, high Not connected Not connected Not Used LIN V Order name Short name Order number CAN and FlexRay interface Y-cable, CBCF100.1- F 00K 107 939 DSUB – 2 x DSUB (9fc-9mc+9mc), 0m3 ETAS ES584.2 | User Guide...
-
Page 34: Cbac180 Cable
37 | Cables and Accessories CBAC180 Cable Fig. 6-3 CBAC180-2 cable OBDII (J1962) adapter cable for the CAN interface of the ES584.2 DSUB connec- OBD2 connec- Signal Note tion tion CAN High CAN High and CAN Low in a shielded twisted pair... -
Page 35: Cbh500 Cable
MMh NMP TUQ Fig. 6-5 CBCX130 cable NOTE The CBH500 cable only supports one CAN channel. Order designation Short name Order number CAN interface cable, DSUB – DSUB (9fc- CBCX130-2 F 00K 103 784 9mc), 2 m ETAS ES584.2 | User Guide... -
Page 36: Cbcx131.1-0 Adapter
39 | Cables and Accessories CBCX131.1-0 Adapter 120 Ohm Fig. 6-6 CBCX131.1-0 terminating resistor CAN 120 ohm terminating resistor, 2xDSUB (9fc+9mc) Order designation Short name Order number CAN 120 ohm terminating resistor, 2xDSUB CBCX131-0 F 00K 103 786 (9fc+9mc) ETAS ES584.2 | User Guide... -
Page 37: Order Information
40 | Order Information Order Information ES584.2 CAN FD and LIN Bus Interface USB Module Order name Short name Order number ES584.2 CAN FD and LIN Bus Interface USB ES584.2 F 00K 115 627 Module Scope of supply - ES584.2 CAN FD and LIN Bus Interface USB Module, - CBCF100.1 cable,... -
Page 38: Contact Information
41 | Contact Information Contact Information Technical Support For details of your local sales office as well as your local technical support team and product hotlines, take a look at the ETAS website: www.etas.com/en/hotlines.php ETAS Headquarters ETAS GmbH Borsigstraße 24... -
Page 39: Figures
CBCX131.1-0 terminating resistor ..........39 ETAS ES584.2 | User Guide... -
Page 40: Index
CAN FD ......12 Operating Modes CAN Interface ....12 ETAS ES584.2 | User Guide...
