ETAS GETK-P4.0A User Manual

Measurement interface for microprocessors and microcontroller using pci express
Table of Contents

Advertisement

Quick Links

ETAS GETK-P4.0A
Measurement Interface for Micro-
processors and Microcontroller
using PCI Express
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GETK-P4.0A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for ETAS GETK-P4.0A

  • Page 1 ETAS GETK-P4.0A Measurement Interface for Micro- processors and Microcontroller using PCI Express User Guide...
  • Page 2 Copyright The data in this document may not be altered or amended without special notification from ETAS GmbH. ETAS GmbH undertakes no further obligation in relation to this document. The software described in it can only be used if the customer is in possession of a general license agreement or single license.
  • Page 3: Table Of Contents

    Interfaces Overview ..............18 ETAS GETK-P4.0A | User Guide...
  • Page 4 Web Subpages ............33 ETAS GETK-P4.0A | User Guide...
  • Page 5 GETK-P4.0A ........
  • Page 6: Basic Safety Notices

    Safety Information Refer to the following safety instructions and the technical documentation avail- able to download from the ETAS website www.etas.com. Keep the information pro- vided in a safe place. ETAS GETK-P4.0A | User Guide...
  • Page 7: Intended Use

    Program codes or program control sequences that are created or changed via ETAS products, as well as all types of data obtained through the use of ETAS prod- ucts, must be checked for their reliability and suitability prior to use or distribution.
  • Page 8: Technical Condition

    The product is designed in accordance with state-of-the-art technology. Only operate the product and its accessories if they are in perfect working order. Shut down a damaged product immediately. Do not open or alter the product. Only ETAS may make changes to the product.
  • Page 9: Operation

    If the firmware update is not completed successfully, try it again. If a new firmware update is not possible and the product is not functional, send the product to ETAS. WARNING Undefined vehicle behavior due to critical system error in the ECU...
  • Page 10: Connection To The Power Supply

    2. Remove all cables from the product. Cables and Accessories 1.7.1 Cables - Only use ETAS cables, cables recommended by ETAS or other cables certi- fied for the application. - Route the cables such that they are protected against abrasion, dam-age, deformation and kinking.
  • Page 11: Maintenance

    If repairs are required, send the product to ETAS. 1.7.7 Shipment and Packaging You will find the hardware return form and the procedure at the ETAS-Website: www.etas.com/en/support/hw_return_form.php. Identifications on the Product The following symbols are used for identification of the product:...
  • Page 12: Fulfilled Standards And Norms

    1.11.1 CE Declaration of Conformity (European Union) With the CE mark attached to the product or its packaging, ETAS confirms that the product corresponds to the applicable product-specific European Directives. The CE Declaration of Conformity for the product is available upon request.
  • Page 13: Ukca Declaration Of Conformity (Great Britain)

    1.11.2 UKCA Declaration of Conformity (Great Britain) With the UKCA mark attached to the product or its packaging, ETAS confirms that the product corresponds to the product-specific, applicable standards and direc- tives of Great Britain. The UKCA declaration of conformity for the product is avail- able on request.
  • Page 14: Introduction

    ECUs and to storing the data on a High-Performance PC. 2.1.2 System Interfaces To process the ECU data, the GETK-P4.0A connects the ECU microprocessors via PCIe interface. A GETK-P4.0A ECU Driver must be installed on the ECU as part of the middleware. 2.1.3 Data Transfer The measurement data from the ECU will be transferred via Ethernet to one or more Recorder PCs and/or to one or more Visualization PCs.
  • Page 15: Cascading

    The above functionality can be split onto different PCs. 2.1.5 Cascading Multiple GETK-P4.0A devices or MDH devices can be added to the measurement setup as well as connected by the cascading interface. MHD is a Measurement Interface for capturing Video raw signals.
  • Page 16: Product Features

    - Additional control signals for Wakeup and cascading - 40/100GE high-speed Ethernet connection to the Recorder PC - 10 GE Interface - 1 GE Interface For more technical data on the GETK-P4.0A refer to “Technical Data” on page 34. ETAS GETK-P4.0A | User Guide...
  • Page 17: Hardware Description

    • Configuration ............26 Architecture The key functionality of the GETK-P4.0A (Gigabit Emulator Test Probe PCIe) is the fast acquisition of measurement data from an ECU via PCIe and writing it to a local harddrive.
  • Page 18: Interfaces Overview

    18 | Hardware Description The GETK-P4.0A is supplied by the ETAS Power cable CBP510 or the Powercable CBP5105-2. Interfaces Overview The interfaces are listed below: Fig. 3-2 GETK-P4.0A Interfaces Fig. 3-3 GETK-P4.0A Interfaces Label Interface Connection Connector type USB 3.0 (Host) connec- Reserved for ETAS internal use.
  • Page 19: 40/100Ge Ethernet Interface To Recorder Pc

    The four PCIe interfaces are connected to the ECU. Mini-SAS HD cables for PCIe Gen4 can be used to connect the GETK-P4.0A with the ECU. All necessary signals between GETK-P4.0A and ECU interfaces are routed via the Mini-SAS HD adapter.
  • Page 20: Cas-Out Interface

    3.2.4 CAS-OUT The CAS-OUT interface connects control signals like Wakeup, Present, and Ready to the next connected GETK-P4.0A. LED Display of the System Fig. 3-4 on page 20 shows the location of the LEDs on the front plate. . Fig. 3-4 GETK-P4.0A Status LEDs...
  • Page 21: Power Supply

    “Power Supply PWR Interface Pinning” on page 36. 3.4.2 Reverse Polarity Protection To avoid short circuits in the supply voltage, the GETK-P4.0A is equipped with a reverse polarity protection circuit and an overcurrent protection. Temperature Control and Restart In case the GETK-P4.0A temperature control has detected a critical temperature, the temperature alarm is active and the GETK-P4.0A changes the operating state...
  • Page 22: Operation State

    22 | Hardware Description 3.6.2 Operation State The GETK-P4.0A is activated and in operation state. The PCIe links are established and the Ethernet Data Links are available. Configuration, measurement, or firmware updates are possible. Change to the Standby state, if following is detected: - No Wakeup signal from the ECU and - No Ethernet activity at any of the Ethernet interfaces.
  • Page 23: Wakeup (Gpio_Wake)

    3.7.3 Ready (GPIO_CASC_RDY) A high Ready signal at CAS-IN signals to the ECU, that the GETK-P4.0A is ready and the measurement can be started. If an additional GETK-P4.0A is connected at CAS-OUT, then the Ready signal is only active, if the connected GETK-P4.0A has as well an activated Ready signal.
  • Page 24: Precision Time Protocol (Ptp)

    GETKs, to extract them and to provide them to the cus- tomer tool for online visualization. The data flow between GETK-P4.0A and RALO Recorder PC and RALO OCRE is con- trolled by the RALO Manager. It provides interfaces enabling the user to configure, to operate and to monitor the RALO Recorder as well as multiple GETKs.
  • Page 25: Application Hints

    Acquiring Relation between different Clock Domains The GETK-P4.0A is connected to the ECU via PCIe, also it is connected via Ethernet to the RALO systems. The GETK-P4.0A devices are time-synchronized via PTP to the other systems on the Ethernet based measurement network.
  • Page 26: Configuration

    26 | Hardware Description Solution Regarding the ECU architecture, make sure that the ECU’s memory bandwidth is dimensioned sufficiently, so that the additional read access of the GETK-P4.0A does not significantly increase the memory bandwidth. Restriction If the ECU architecture cannot be dimensioned accordingly, it is recommended to limit the measurement data rate, so that the memory bandwidth is less.
  • Page 27: Installation

    Take account of different electric potentials in your test setup and take appro- priate measures to prevent equalizing currents. The connectors should be carefully and firmly inserted. ETAS GETK-P4.0A | User Guide...
  • Page 28 If the PCIe1-5, the 40/100 GE, the 10 GE, and the Power connector are inserted in the correct orientation, they snap in and remain locked. Check, that the connectors remain locked. NOTE The PCIe1-4 connectors are rotated 180° compared to the PCIe5 connector. ETAS GETK-P4.0A | User Guide...
  • Page 29: Configuration

    5.1.1 Fixed IP Addresses The GETK-P4.0A has fixed IP address for every ethernet port ending with x.13. This IP address cannot be changed and cannot be used with other devices in the same network. With this address, the Web Interface can be started and the configura- tion can be changed.
  • Page 30: Tcp/Ip6 Configuration

    The same Python commands are used for Linux and Windows. In the following steps, the procedure for Windows 10 is described. Linux: The same procedure can be adapted for Linux. Please contact ETAS about details: - ETAS contact partners by region: www.etas.com/contact...
  • Page 31: Extract Both Packages Into The Same Directory

    3. Install missing component aiohttp, if python was installed new: pip install aiohttp 5.2.6 getkupdate command options 1. Display of command options: python getkupdate -h 2. Display of subcommand options: python getkupdate discover -h python getkupdate show -h python getkupdate install-h ETAS GETK-P4.0A | User Guide...
  • Page 32: Check Communication

    - Prefer the fixed IP addresses for the web browser, see “IP Adresses” on page 29. - The setup of the network card must fit to the IP address. - If you use the fixed IP address, make sure, only one GETK-P4.0A is con- nected in this network. ETAS GETK-P4.0A | User Guide...
  • Page 33: Web Subpages

    • Display and access to the directories and packages of the used GETK- P4.0A software - OSS Licenses • Display of the open source licenses. - Safety Advice • Display of the Safety Information - Logfiles • Possible to save the Logfile to the PC. ETAS GETK-P4.0A | User Guide...
  • Page 34: Technical Data

    System Requirements for the ECU The GETK-P4.0A requires special functionalities at the ECU: In order to measure ECU data with a GETK-P4.0A over PCIe, the following memory areas on the ECU must be reachable via DMA: - any memory used for measurement data, if additional copying of the data is not desired - an additional 128MB for the GETK-P4.0A adapter itself...
  • Page 35: Environmental Conditions

    88 x 241 x 262 mm / 3.5 x 9.5 x 10.3 in (H2 x W2 x D2) without frontplate 88 x 205 x 224 mm / 3.5 x 8.1 x 8.8 in Weight 4.20 kg / 9.26 lb ETAS GETK-P4.0A | User Guide...
  • Page 36: Power Supply Pwr

    Reverse polarity protection Available for Power Supply. Overvoltage category (AC mains supply) *) Only copper cables are connected to the GETK-P4.0A. If optical cables are con- nected, then the standby current is correspondingly higher. 6.4.2 Power Supply PWR Interface Pinning Neutrik: NC3MD-LX-M3 Fig.
  • Page 37: Mini-Sas Hd Pcie Pin Assignment

    - If a cable bridges the CMI Pins (SCL, SDA) between both sides, the ECU must not drive these pins - they are driven by the GETK-P4.0A. Disregarding this might result in an unreliable connection. - Please refer to chapter “PCIe Gen4 Mini-SAS HD Cable” on page 43 for cables recommended by ETAS..
  • Page 38: Cas-In Interface

    3.3V, 30 mA max PCIE_T1_P PCIE_T1_N PCIE_T2_P PCIE_T2_N CADDR: ECU side requires a PullUp to HIGH (3.3V). GETK-P4.0A side is set to LOW. CAS-IN Interface 6.6.1 CAS-IN Interface Characteristics A female Lemo 0B 9 pins with "A" key is used. All signals with maximum voltage level of 15V DC.
  • Page 39: Cas-In Interface Pinning

    ECU looped through a previous GETK-P4.0A. /Present.P output GETK-P4.0A is connected (/GPIO_CASC _PRST_P) /Present.V looped through (/GPIO _PRST _P) Ready output GETK-P4.0A is ready (GPIO_CASC _RDY) Replay.V looped through (GPIO_RPLY) Reserved Reserved Reserved Reference ECU ground ECU GND (GND_GPIO) ETAS GETK-P4.0A | User Guide...
  • Page 40: Cas-Out Interface

    All signals according to open drain standard and are galvanically isolated. Maxi- mum voltage level: 15V DC. This interface is used to connect to an additional GETK-P4.0A or a MHD for Wakeup, Ready and other signals. Pin 1,3, 5, and 9 are connected with CAS-IN.
  • Page 41: 10Ge Interface

    Electrical data and Pinning are according to the standard. 6.10 1GE Interface To Laptop/PC for service operations. This is a standard Ethernet RJ45 interface. Electrical data and Pinning are according to the standard. 6.11 USB Interface Reserved for ETAS internal use. ETAS GETK-P4.0A | User Guide...
  • Page 42: Cables And Accessories

    This chapter contains information about the following cables and accessories: Requirements for failsafe Operation NOTE We recommend using ETAS cables or any other cables certified by the standards for the application. Adhere to the maximum permissible cable lengths! NOTE Application-specific cables are available from ETAS. Please contact ETAS.
  • Page 43: Power Supply Cable Safety

    ETAS technical support www.etas.com/en/hotlines.php. 7.5.1 1GE: Standard Ethernet Cables Standard RJ45 Ethernet cables can be used. 7.5.2 10GE: SFP+ Direct Attached Copper Cables ETAS recommends using the GETK-P4.0A with following electrical cables at the 10GE Ethernet interface. ETAS GETK-P4.0A | User Guide...
  • Page 44: 40/100Ge: Qsfp28 Direct Attached Copper Cables

    10GbE SFP+ DAC Twinax electrical cable 7.5.3 40/100GE: QSFP28 Direct Attached Copper Cables ETAS recommends using the GETK-P4.0A with following electrical cables at the 40/100GE Ethernet interface. - DAC Cable 2 m, Mellanox MCP1600-C002E30N Rev. A2. Ethernet Cable, 100Gb/s, Connection Cable QSFP28 to QSFP28, AWG30 CBAV423.1 Chain Connection...
  • Page 45: Ordering Information

    - Power cable (F 00K 106 273, CBP510-2) Cable and Adapter NOTE We recommend using ETAS cables or any other cables certified by the standards for the application. Adhere to the maximum permissible cable lengths! NOTE Application-specific cables are available from ETAS. Please contact your ETAS partner or e-mail sales.de@etas.com.
  • Page 46: Contact Information
