Robertson AP35 Autopilot
Operation of the autopilot
ON/OFF
Standby mode
A single press on the STBY button switches the system ON and the following
status displays are shown:
* Robertson *
* AP35 *
SW V1R1
HW rev. 0
* Robertson *
* J300X *
SW V1R4
P00 M00
Power board revision
SW and HW revisions shown are examples only
After approx. 5 seconds the system is operative and the unit that was turned on
will show the STBY mode Primary Display. Other units in a multistation system
will display "Inactive". Control can be available at any unit by pressing the STBY
button.
A long press (2-3 sec.) on the STBY button switches the system OFF.
In an emergency it is possible on a multistation system to turn OFF the system at
any control unit by pressing down the STBY button for 2-3 seconds.
STBY mode is also the mode that is used when steering the boat manually.
First Press
STBY
OFF
Second Press
STBY
OFF
Autopilot model
Software V(ersion) and R(elease)
Hardvare revision
Junction unit model
Software V(ersion) and R(elease)
S000
Self check
Main board revision
Note!
Primary Display
5 sec.
S265
Current heading
Secondary Display
Rudder angle (PORT 7 degrees)
Simrad Robertson AS
Egersund - Norway
STBY
07
Page 2-3
