Summary of Contents for Water Furnace 300A11 3 Series
Page 1
OPERATION & MAINTENANCE 3 Series 300A11 OMW3-0019W 60HZ...
Page 2
WARNING CAUTION This appliance is not intended for use by persons (including WARNING: Before performing service or maintenance children) with reduced physical, sensory, or mental capabili- operations on the system, turn off main power switches to ties, or lack of experience and knowledge, unless they have the unit.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Nomenclature Brand Brand W – WFI W – WFI IntelliStart & Air Coil Option Model Model 0 – No IntelliStart, Uncoated Coil 3 – 3 Series 3 – 3 Series 1 – IntelliStart, Uncoated Coil 2 –...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE AHRI Data The performance standard AHRI/ASHRAE/ISO 13256-1 became effective January 1, 2000 and replaces ARI Standards 320, 325, and 330. This new standard has three major categories: Water Loop (comparable to ARI 320), Ground Water (ARI 325), and Ground Loop (ARI 330).
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Vertical Dimensional Data 3 SERIES VERTICAL SUBMITTAL DATA 2 ft [61 cm] Primary Service Access 2 ft [61 cm] Alternate RIGHT RETURN Service Access. Right Return Opposite Side LEFT RETURN 1.90 4.8 1.90 4.8 FRONT Electrical...
Page 9
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Horizontal Dimensional Data TOP VIEW 2.00 5.1 Mount (2) hanger brackets as shown to allow access to filter 2 ft [61 cm] 2 ft [61 cm] Primary Service Access Alternate Service Access Right return opposite side SIDE DISCHARGE VIEW END VIEW...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Electrical Data Dual Capacity with ECM motor Blower Total Compressor Rated Voltage Pump Loop Motor Unit Circ Fuse/ Model Voltage Min/Max LRA* HACR 208-230/60/1 187/253 16.0 10.2 62.0 21.7 20.1 22.7 208-230/60/1 187/253 22.7 14.5...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Blower Performance Data 5-Speed ECM Constant Torque Motors each speed selection. As static pressure increases, airflow decreases resulting in less torque on the rotor. The motor The 5-Speed ECM is a ‘Constant Torque’ ECM motor and responds only to changes in torque and adjusts its speed delivers air flow similar to a PSC but operates as efficiently as accordingly.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Antifreeze Corrections Catalog performance can be corrected for antifreeze use. Please use the following table and note the example given. Antifreeze Type Antifreeze % by wt Heating Cooling Pressure Drop EWT - °F [°C] 30 [-1.1] 90 [32.2] 30 [-1.1]...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Correction Factor Tables Air Flow Corrections (Dual Capacity Part Load) Airflow Cooling Heating cfm Per Ton % of Nominal Total Cap Sens Cap Power Heat of Rej Htg Cap Power Heat of Ext of Clg 0.922 0.778...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Water Quality Material Copper 90/10 Cupronickel 316 Stainless Steel Acidity/Alkalinity 7 - 9 7 - 9 7 - 9 Calcium and (Total Hardness) (Total Hardness) (Total Hardness) Scaling Magnesium Carbonate less than 350 ppm less than 350 ppm less than 350 ppm Less than 0.5 ppm (rotten egg...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Operating Parameters Dual Capacity Models First Stage Operation Cooling -- No Hot Water Generation Entering Water Water Flow Suction Discharge Water Temp Air Temp Drop Temp °F gpm/ton Superheat Subcooling Pressure psig Pressure psig Rise °F °F DB...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Pressure Drop Pressure Drop (psi) Model 30°F 50°F 70°F 90°F 110°F full load 12.1 11.4 10.5 part load full load part load full load 12.0 11.3 10.6 14.6 13.7 12.8 12.1 11.2 part load 10.1 14.0...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Operation Logic Data Table Heating Cooling Operation Logic Table STG1 STG2 STG3 EMERG Fan Only STG1 STG2 Fan Only Compressor Reversing Valve Aux Heat Staged Staged Acc Relay 5 Speed ECM Med Low Med High High High...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Control System Aurora ‘Base’ Control at the thermostat. Aurora uses the Modbus communication The Aurora ‘Base’ Control (ABC) protocol to communicate between modules. Each module System is a complete residential contains the logic to control all features that are connected to and commercial comfort system the module.
Page 21
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Control System Aurora ‘Base’ Control by cycling the power. NOTE: Test mode will automatically be exited after 30 minutes. Reset Configuration Mode The control is placed in reset configuration mode by holding the push button switch SW1 for 50 to 60 seconds.
Page 22
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Control System Field Selectable Options via Software open requirement. A continuously open LPS shall not be recognized during the 2 minute startup bypass time. (Selectable via the Aurora AID Tool) Loss of Charge – fault is recognized when the Normally Safety Features Closed Low Pressure Switch, P4-7/8 is open prior to the The following safety features are provided to protect the...
Page 23
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Control System Emergency Heat (W) - The blower will be started on “W” Continuous Blower Operation - The blower output will be energized any time the control has a G input present, speed, 10 seconds later the first stage of electric heat unless the control has an emergency shutdown input will be turned on.
Page 24
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Control System entire length of the appropriate delay to be recognized as a Aurora now expands the Fault/Alarms in to several groups. fault. This fault will be ignored for the initial 2 minutes of the Faults are system critical faults to the heat pump and will compressor run time.
Page 25
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Control System ASB Sensor Board Aurora Interface and Diagnostics (AID) Tool Refrigerant Leak Detection The Aurora control system uses the ASB control board to monitor the refrigerant sensor and determine when a fault condition requiring mitigation has been recognized and is active.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Refrigerant Circuit Guideline Head Suction Compressor Air Temp. Water Temp. Symptom Superheat Subcooling Pressure Pressure Amp Draw Differential Differential Under Charged System High (Possible Leak) Over Charged System High High High Normal High Normal/Low Normal...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Electrical Information 208 Volt Operation General All 208/230 units are factory wired for 230 volt operation. For Be sure the available power is the same voltage and phase 208 volt operation, the red and blue transformer wires must as that shown on the unit serial plate.
Page 28
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Electrical Information Figure 13A: Figure 13B: Wire access Line Voltage 208-230/60/1 control box Figure 13C: Figure 14: Control Box with ASB Board Pump Wiring 208-230/60/1 External Loop Pump(s) 208-230/60/1 1/2 hp Max...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Electrical Information - Flow Centers Fixed Speed Flow Center The pump(s) will be connected to the terminals on PB1 in the unit electrical box as shown in Figure 14. The pumps will automatically be cycled as required by the unit or by a signal from another unit sharing the flow center (See Figures 5 and 6).
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Closed Loop Ground Source Systems Once piping is completed between the unit, pumps and Multiple Units on One Flow Center the ground loop, final purging and charging of the loop When two heat pumps are connected to one loop pumping is required.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Open Loop Ground Water Systems Typical open loop piping is shown below. Always maintain on local codes, i.e. recharge well, storm sewer, drain field, water pressure in the heat exchanger by placing water adjacent stream or pond, etc.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Reference Calculations Heating Calculations: Cooling Calculations: LWT = EWT - LWT = EWT + GPM x 500* GPM x 500* NOTE: * When using water. Legend Abbreviations and Definitions EWT = Entering Water Temperature HWR = Hot Water Return EER = Energy Efficiency Ratio (TC/kW) HWS = Hot Water Supply...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Preventative Maintenance Proper maintenance is very important to obtain optimum Condensate Drain performance and longevity for the heat pump system. It is In areas where airborne bacteria produce a slime in the best to establish a periodic maintenance schedule with the drain pan, it may be necessary to treat chemically to installer so the heat pump system can be checked regularly.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Troubleshooting Aurora Control System Refrigerant Systems NOTE: Refer to the Aurora Base Control Application and To maintain sealed circuit integrity, do not install service Troubleshooting Guide and the Instruction Guide: Aurora gauges unless unit operation appears abnormal. Compare Interface and Diagnostics (AID) Tool for additional information.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Aurora Interface Diagnostic (AID) Tool Aurora Input-Output Diagnostics LED Displays Slow Flash = 1 second on and 1 second off Troubleshooting the Aurora logic board Fast Flash = 100 ms on and 100 ms off can be accomplished using nothing more Flash Code = 100 ms on and 400 ms off with a 2 second pause than a couple of jumper wires and a volt...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Troubleshooting Checklist Equipment will not start or operate • Return air temperature may be below 50°F. Block off air coil temporarily to improve flow of refrigerant through the system. Air • Follow the troubleshooting flow charts to find root cause. below 50°F cannot be tolerated on a continuing basis.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Steps 1) General Check Other items to check when troubleshooting a water flow lockout • If any new device was installed, or any wiring was changed, are superheat, water flow through the coaxial heat exchanger and check the connections to ensure the wiring is correct, and all the antifreeze composition.
Page 39
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Steps cont. 4) Other Faults No Lockout Output – Measure the voltage output between P1-1 and C. The reading should be 24 VDC or a pulsed 24 VDC ECM Motor Will Not Start dependent on the selection of SW2-7.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Flow Charts Use the following flow charts to aid in troubleshooting the control board. Compressor Will Not Start Without AID Tool Compressor will not start Count the number of Is LED3 (green) lit Is LED1 (red) flashes and compare to...
Page 41
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Flow Charts cont. Notes: 1. When measuring 24VAC actual value may be between 18 and 30VAC. Put control into test Check 24VAC Check 24VAC Check for correct Check Compressor mode, and wait 1 between CC and across contactor...
Page 42
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Flow Charts cont. Compressor Will Not Start With AID Tool Compressor will not start Check current fault. Connect the AID Is the control in Correct fault and try to Tool Lockout? restart.
Page 43
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Flow Charts cont. Notes: 1. When measuring 24VAC actual value may be between 18 and 30VAC. Check 24VAC Check 24VAC Check for correct Check Compressor In “System between CC and across contactor voltage on T1 and wiring, winding...
Page 44
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Flow Charts cont. ECM Blower Will Not Start With AID Tool Blower will not start Check for correct voltage Connect AID Tool. Put control in test Is LED3 (green) Lit between orange and Remove P1 and put a mode and wait 1...
Page 45
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Troubleshooting Flow Charts cont. Notes: 1. When measuring 24VAC actual value may be between 18 and 30VAC. Put control into test Check 24VAC Check 24VAC Check for correct Check Compressor mode, and wait 1 between CC and across contactor...
Page 46
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Communicating Thermostat Troubleshooting Guide TPCC32U01*, TPCM32U03A* and TPCM32U04A* (*GSR, GSM, E, YRK) Thermostat not communicating Wire non- Are you using a communicating 8 Is this a variable communicating wire thermostat speed unit? thermostat? to P1 terminal on the ABC board...
Page 47
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Communicating Thermostat Troubleshooting Guide cont. Are all Remove what is applicable not needed or add devices present what is needed. Is Issue resolved on Configure the thermostat Aurora System communicating? screen TPCM32U03A*/TPCM32U04A* Thermostat P7 on ABC Board Green Plug...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Signals To Check for 24VAC between R and C a signal and the contactor is not pulled in, check voltage across the contactor coil. If you have voltage across the contractor coil, replace the contactor.
Page 49
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Signals cont. To Check Operation of the Accessory Relay Put gauges on the unit to monitor high/low pressure. Place a jumper between “R” and “CC” as shown. This will bypass the safety circuit and the compressor will run whether the board is calling for it or not.
Page 50
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Control Board Signals cont. To Check the Condensate Sensor To Check the ECM Blower Motor Enable Signal 24 VAC VOLTS VOLTS OHMS With the AID Tool go to the “Thermostat Inputs” Menu under “Diagnostics”...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Jumping the Control Board Stage 1 Heating Stage 2 Heating With the AID Tool go to the “Thermostat Inputs” Menu under With the AID Tool go to the “Thermostat Inputs” Menu under “Diagnostics”...
Page 52
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Jumping the Control Board cont. Emergency Heat Stage 1 Cooling With the AID Tool go to the “Thermostat Inputs” Menu under With the AID Tool go to the “Thermostat Inputs” Menu under “Diagnostics”...
Page 53
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Jumping the Control Board cont. Reheat Mode With the AID Tool go to the “Thermostat Inputs” Menu under “Diagnostics” and over-ride the “DH” input to ON. If an AID Tool is not available remove the P1 connector to disconnect the thermostat from the board.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Water Side Analysis: Heat of Extraction/Rejection By determining the amount of heat extracted or rejected, the ∆P = 40 psi – 34.2 psi service technician can better judge the performance of the unit and ∆P = 5.8 psi verify whether or not the unit performance is acceptable.
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Superheat/Subcooling Checking Superheat in the Heating Mode Superheat = Suction line temperature minus suction saturation temperature Digital Thermometer Suction COIL Comp Expansion Coax Discharge Valve Hot Water Generator Checking Superheat in the Cooling Mode Superheat = Suction line temperature minus suction saturation temperature Digital...
Page 56
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Superheat/Subcooling cont. Checking Subcooling in the Heating Mode Subcooling = High side saturation temperature minus liquid line temperature Digital Thermometer Suction COIL Comp Expansion Coax Discharge Valve Hot Water Generator Checking Subcooling in the Cooling Mode Subcooling = High side saturation temperature minus liquid line temperature Digital...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Troubleshooting Single Speed/Dual Capacity Startup/Troubleshooting Form 1. Job Information Model # Job Name: Loop: Open / Closed Serial # Install Date: Hot Water Generator: Y / N 2. Flow Rate in gpm SOURCE COAX LOAD COAX (Water-to-Water) HEATING...
Page 58
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Troubleshooting cont. Startup/ roubleshooting Form Dealer: Controls Info: ABC Version: Phone #: Date: Problem: IZ2 24V Version: Model #: T-Stat Version: Installed Sensors: Serial #: COOLING CYCLE ANALYSIS SAT °F °F Unit Amp Draw: Loop: Open Closed...
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Service Parts List Dual Capacity Units Parts List Compressor 208-230/60/1 34P749-01 34P751-01 34P753-01 34P755-01 34P756-01 Run Capacitor 208-230/60/1 16P008D18CK 16P008D21CK 16P008D31CK 16P008D32CK 16P008D34CK Compressor Power Harness 11P781-01 11P781-01 11P781-01 11P781-01 11P781-01 Solenoid Harness 11P782-02 11P782-02 11P782-02...
Page 70
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Decommissioning Before carrying out this procedure, it is essential that the technician is completely familiar with the equipment and all its detail. It is recommended good practice that all refriger- ants are recovered safely. Prior to the task being carried out, an oil and refrigerant sample shall be taken in case analysis is required prior to re-use of recovered refrigerant.
Page 71
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Refrigerant Recovery When removing refrigerant from a system, either for servicing The recovered refrigerant shall be processed according to or decommissioning, it is recommended good practice that all local legislation in the correct recovery cylinder, and the refrigerants are removed safely.
Page 72
DUAL COMPRESSOR PACKAGED HEAT PUMP OPERATION AND MAINTENANCE Charging procedures In addition to conventional charging procedures, the following requirements shall be followed. • Ensure that contamination of different refrigerants does not occur when using charging equipment. • Hoses or lines shall be as short as possible to minimise the amount of refrigerant contained in them.
