Page 1: Pico-Itx Boards
PICO-G350B Pico-ITX Boards www.gigaipc.com... -
Page 2: Copyright Notice
While reasonable efforts have been made in the preparation of this document to assure its accuracy, GIGAIPC assumes no liabilities resulting from errors or omissions in this document, or from the use of the information contained herein. -
Page 3: Acknowledgement
IBM, PC/AT, PS/2, and VGA are trademarks of International Business Machines Corporation. • Arm® and Cortex® are registered trademarks of Arm Limited (or its subsidiaries) Android™ is a trademark of Google LLC. • All other product names or trademarks are properties of their respective owners. www.gigaipc.com... -
Page 4: Packing List
Packing List Before setting up your product, please make sure the following items have been shipped: Item Quantity PICO-G350B MB If any of these items are missing or damaged, please contact your distributor or sales representative immediately. www.gigaipc.com... -
Page 5: About This Document
(if any), its specifications, dimensions, jumper/ connector settings/definitions, and driver installation instructions (if any), to facilitate users in setting up their product. Users may refer to the GIGAIPC.com for the latest version of this document. www.gigaipc.com... -
Page 6: Safety Precautions
Make sure the device is installed near a power outlet and is easily accessible. 10. Keep this device away from humidity. 11. Place the device on a solid surface during installation to prevent falls 12. Do not cover the openings on the device to ensure optimal heat dissipation. www.gigaipc.com... - Page 7 18. D O N O T L E AV E T H I S D E V I C E I N A N U N C O N T R O L L E D ENVIRONMENT WITH TEMPERATURES BEYOND THE DEVICE’S PERMITTED STORAGE TEMPERATURES (SEE CHAPTER 1) TO PREVENT DAMAGE. www.gigaipc.com...
-
Page 8: Fcc Statement
Il y a un risque d’explosion si la batterie est remplacée de façon incorrecte. Ne la remplacer qu’avec le même modèle ou équivalent recommandé par le constructeur. Recycler les batteries usées en accord avec les instructions du fabricant et les directives gouvernementales de recyclage. www.gigaipc.com... -
Page 9: China Rohs Requirements (Cn)
China RoHS Requirements (CN) 产品中有毒有害物质或元素名称及含量 GIGAIPC Main Board/ Daughter Board/ Backplane 有毒有害物质或元素 部件名称 铅 汞 镉 六价铬 多溴联苯 多溴二苯醚 (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) 印刷电路板 及其电 ○ ○ ○ ○ ○ ○ 子组件 外部信号 连接器 ○ ○ ○ ○... -
Page 10: China Rohs Requirement (En)
China RoHS Requirement (EN) Poisonous or Hazardous Substances or Elements in Products GIGAIPC Main Board/ Daughter Board/ Backplane Poisonous or Hazardous Substances or Elements Component Hexavalent Polybrominated Polybrominated Lead Mercury Cadmium Chromium Biphenyls Diphenyl Ethers (Pb) (Hg) (Cd) (Cr(VI)) (PBB) (PBDE) PCB &... -
Page 11: Table Of Contents
SYS_PANEL (Front panel header) ........24 2.2.6 GPIO_CNT (General Purpose input/output header) ..25 2.2.7 UART (UART connector) ..........26 2.2.8 M2E (M.2 Slot, 2230 E-key, Secure digital input/output interface (SDIO)) ............27 2.2.9 FUSB (USB 2.0 headers)..........28 www.gigaipc.com... - Page 12 2.2.11 FP_AUDIO (Front Audio connector) ......30 2.2.12 SPKR (Speaker out connector) ........31 2.2.13 MIPI (Mobile Industry Processor Interface) ....32 2.2.14 LVDS (LVDS connector) ..........33 2.2.15 BKL_CN (Backlight Control connector) ......34 2.2.16 SD (Micro SD slot) ............35 www.gigaipc.com...
-
Page 13: Chapter 1 - Product Specifications
Chapter 1 Chapter 1 - Product Specifications www.gigaipc.com... - Page 14 74.61 65.6 3.20 www.gigaipc.com...
-
Page 15: Specifications
Specifications PICO-G350B Motherboard PICO-ITX Form Factor 100W x 72Dmm MT8365 Arm® Quad-Core Cortex®-A53 up to 2.0GHz Memory LPDDR4X 4GB (on board) Ethernet Integrated 100M Ethernet Integrated Graphics Processor – Mali-G52: 1 x HDMI port, supporting a maximum resolution of 1280x720... - Page 16 PICO-G350B Motherboard Operating temperature: 0°C to 60°C Operating Operating humidity: 0-90% (non-condensing) Properties Non-operating temperature: -40°C to 85°C Non-operating humidity: 0%-95% (non-condensing) www.gigaipc.com...
-
Page 17: Chapter 2 - Hardware Information
Chapter 2 Chapter 2 – Hardware Information www.gigaipc.com... -
Page 18: Jumpers And Connectors
Jumpers and Connectors www.gigaipc.com... - Page 19 M.2 Slot, 2230 E-key, Secure digital input/ output interface (SDIO) FUSB USB 2.0 headers Micro USB 2.0 connector FP_AUDIO Front Audio connector SPKR Speaker out connector MIPI Mobile Industry Processor Interface LVDS LVDS Connector BKL_CN Backlight Control connector Micro SD slot www.gigaipc.com...
-
Page 20: Dc_In (Dc In Connector)
2.2.1 DC_IN (DC IN connector) DC IN Connector Connector PN Vendor 2DC-0005B200 SINGATRON www.gigaipc.com... -
Page 21: Hdmi (Hdmi Connector)
2.2.2 HDMI (HDMI connector) HDMI Connector Connector PN Vendor 1165-2CG04-24P TCONN Definition Definition HDMI_D2p HDMI_CLKn HDMI_D2n HDMI_D1p HDMI_SCL HDMI_D1n HDMI_SDA HDMI_D0p HDMI_D0n HDMI_HPD HDMI_CLKp www.gigaipc.com... -
Page 22: Rusb (Usb 2.0 Connector)
2.2.3 RUSB (USB 2.0 connector) USB 2.0 Connector Connector PN Vendor UB11121-8FDH-4F FOXCONN Pin No. Definition www.gigaipc.com... -
Page 23: Lan (Lan Connector)
2.2.4 LAN (LAN connector) LAN Connector State Description Orange On 1Gbps data rate Green On 100Mbps data rate 10Mbps data rate Link / Connection/ Speed LED Activity LED Connector PN Vendor Pin No. Definition RT7-144A8U4F MD0p MD0n MD1p MD1n www.gigaipc.com... -
Page 24: Sys_Panel (Front Panel Header)
2.2.5 SYS_PANEL (Front panel header) Pin 1 System Panel Header Connector PN Vendor PH08N53BAZ000 HORNGTONG Connector type 2x4pin header, pitch 2.0mm Pin No. Definition Power key System reset Volume up Volume down www.gigaipc.com... -
Page 25: Gpio_Cnt (General Purpose Input/Output Header)
GPIO_CNT (General Purpose input/output header) Pin 1 GPIO Connector Pin No. Definition GPIO_output 7 Connector PN Vendor 220-97-05GB01 PINREX Pin No. Definition Connector type GPIO_output 0 2x5pin header, pitch 2.0mm GPIO_output 4 GPIO_output 1 GPIO_output 2 GPIO_output 5 GPIO_output 3 GPIO_output 6 www.gigaipc.com... -
Page 26: Uart (Uart Connector)
2.2.7 UART (UART connector) Pin 1 UART Connector Connector PN Vendor PH08N53BAZ000 HORNGTONG Connector type 2x4pin header, pitch 2.0mm Pin No. Definition +3.3V +3.3V TXD0 TXD1 RXD0 RXD1 www.gigaipc.com... -
Page 27: M2E
M.2 E Key Connector SDIO_ Command I2S_DI SDIO_D3 I2S_D0 SDIO_D2 I2S_Bitclock I2S_LRCK Pin No. Definition Pin No. Definition Clock request I2S_PERST WiFi_INT 1.8V 1.8V SDIO_DS Connector PN Vendor Pin No. Definition Pin No. Definition APCI0095-P002A LOTES 80152-8521 BELLWETHER SDIO_D1 2E0BC21-S85BE-7H FOXCONN SDIO_D0 www.gigaipc.com... -
Page 28: Fusb (Usb 2.0 Headers)
2.2.9 FUSB (USB 2.0 headers) Pin 1 USB 2.0 Header Connector PN Vendor 220-97-05GB19 PINREX PH10N53BAZ009 HORNGTONG Connector type 2x5pin header, pitch 2.0mm Pin No. Definition No Connect No Pin www.gigaipc.com... -
Page 29: Usb (Micro Usb 2.0 Connector)
2.2.10 USB (Micro USB 2.0 connector) Micro USB Connector Connector PN Vendor MUE40-5G7200 ACON Pin No. Definition www.gigaipc.com... -
Page 30: Fp_Audio (Front Audio Connector)
2.2.11 FP_AUDIO (Front Audio connector) Pin 1 Front Audio Connector Connector PN Vendor 725-81-10TW00 PINREX Connector type 2x5pin header, pitch 2.0mm Pin No. Definition HP_Right AGND HP_MIC AGND HP_Reference HP_Reference HP_Jacksense Detect HP_Left www.gigaipc.com... -
Page 31: Spkr (Speaker Out Connector)
2.2.12 SPKR (Speaker out connector) Pin 1 Audio Amplifie Connector Connector PN Vendor A2001WV-S-04PD01 JOINT-TECH Connector type 1x4pin header, pitch 2.0mm Pin No. Definition Speaker Out L+ Speaker Out L- Speaker Out R+ Speaker Out R- www.gigaipc.com... -
Page 32: Mipi (Mobile Industry Processor Interface)
2.2.13 MIPI (Mobile Industry Processor Interface) Pin 1 MIPI Connector Connector PN Vendor 50503-01501-001 ACES Connector type 1x15pin header, pitch 1.0mm Pin No. Definition Pin No. Definition CLKn CLKp +3.3V +3.3V www.gigaipc.com... -
Page 33: Lvds (Lvds Connector)
But below model no need to add. A0~A3 is odd channel 0~3, A4~A7 is ev en channel. Note: *The LVDS output connector of the unit is only intended to be connected to an UL/IEC/EN approval equipment with fire CLK1+ enclosure. www.gigaipc.com... -
Page 34: Bkl_Cn (Backlight Control Connector)
2.2.15 BKL_CN (Backlight Control connector) Pin 1 Backlight Control Connector Connector PN Vendor 721-81-05TW00 PINREX A2001WV-05P146 JOINT-TECH Connector type 1x5pin header, pitch 2.0mm Pin No. Definition 5V (12V optional) PWM (3.3V) Backlight enable (3.3V) www.gigaipc.com... -
Page 35: Sd (Micro Sd Slot)
2.2.16 SD (Micro SD slot) www.gigaipc.com...
