DISABLING THE THRUST REVERSERS ON THE TCA
QUADRANT AIRBUS EDITION THROTTLE QUADRANT
The TCA Quadrant Airbus Edition throttle quadrant features functional t hrust revers ers ,
replicating those found on Airbus commercial aviation throttles. You can disable the thrust
reverser mechanism, for piloting better suited to civil avi a tion.
Commercial airliner mode:
1. At the stop, lift up the thrust reverser mechanism.
2. Moving past the stop lets you use the thrust reverser.
1
2
General and civil aviation mode:
1. Lift up the thrust reverser mechanism.
2. Turn the selector to position 0 to disable the thrust reverser mechanism.
3. The thrust lever can now move through the entire axis.
3
1
2
7/18
