INSTALLATION INSTRUCTIONS
WARNING: DO NOT EXCEED PRODUCT RATING OR TOW VEHICLE LAMP LOAD RATING, WHICHEVER IS LOWER
APPLICATIONS
Make
Model
Nissan
Frontier
Nissan
Pathfinder
Nissan
Xterra
Suzuki
Equator
CUSTOM WIRING
CONNECTOR
WIRING LOCATION GUIDE
SUVS, MINI & FULL-SIZED VANS ( S )
Representative vehicle shown below
S5 - Behind driver side rear bumper
S5
NOTICE
All steps must be followed to ensure the wiring connector will
function properly. Once installed, test for proper function by
using a test light or connecting a properly wired trailer.
TOOLS NEEDED
Panel trim removal tool
Flat blade screwdriver
WARNING
Exceeding the product rating can cause loss of warranty,
overheating and potential fire. Do not exceed product rating
or tow vehicle lamp load rating, whichever is lower.
Check vehicle owner's manual or contact
the vehicle manufacturer for more information.
PAGE 1 • 56226-INS-RB
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for curt 56226
Summary of Contents for curt 56226
- Page 1 Exceeding the product rating can cause loss of warranty, overheating and potential fire. Do not exceed product rating or tow vehicle lamp load rating, whichever is lower. Check vehicle owner's manual or contact the vehicle manufacturer for more information. PAGE 1 • 56226-INS-RB...
