TRASSIR TR-D3321WDIR4 User Manual

Specification
Model TR-D3321WDIR4
Image sensor 1/2.8" CMOS 2МP
Resolution FullHD(1920x1080)
Frame rate 50Hz: FullHD@50fps (WDR off)
FullHD@25fps (WDR on)
60Hz: FullHD@60fps (WDR off)
FullHD@30fps (WDR on)
Electronic shutter speed 1/2 ~ 1/1 000 s
Day/Night mode Mechanical ICR
Sensitivity 0.003Lux (F1.3)
IR range up to 40 m
Lens (mm)
Field of view (horiz./vert.) 2.8mm: 109˚±5˚ / 57˚±5˚
3.6mm: 87˚±5˚ / 47˚±5˚
Axes setting Pan: 0˚-360˚
Tilt: 0˚-80˚
Rotation: 0˚-360˚
WDR Real WDR (120dB)
Digital noise reduction
Video compression Н.265+ / Н.265 / H.264
Bitrate up to 8Mbps
Local storage MicroSD up to 256GB
Audio Built-in microphone
Audioinput / Audiooutput
Alarm inputs/outputs
Corridor mode
IVS
RTC
Power supply PoE (802.3af) / 12V DC
PoE Class
Power consumption DC: 4.9W
PoE: 5.4W
Case material
Ø116.10 x 96.51
Dimensions (mm)
Weight Net/Gross (g) 520 / 650
Protection IP67, IK10
Power surge TVS 4000V
suppressor
Working temperature -40°C ... +60°C
Cold start
Technical support
www: helpdesk.trassir.com
mail: helpdesk@trassir.com
2.8 / 3.6
3D DNR
1 / 1
Yes
Yes
No
3
Metal
Data ___________________________ Stamp ___________________________
Here is the confirmation form for warranty assurance
-40°C
TR-D3321WDIR4
Vandal-proof IR Network Dome Camera
IK10
Note: read user manual before using
Website: www.trassir.com
For any inquiry: info@trassir.com
