Ihr Ansprechpartner / DE | Your Partner: dataTec AG E-Mail: info@datatec.eu >>> www.datatec.eu BumbleBee Series ® High Voltage Differential Probes with Universal BNC Interface up to 500 MHz, up to ± 2000 V 500:1 to 5:1 Hardware Revision B from SN 2000 Instruction Manual...
(including damages for loss of profits, loss of business, loss of use or data, interruption of business and the like), even if PMK has been advised of the possibility of such damages arising from any defect or error in this manual or product.
® BumbleBee Series Instruction Manual IEC Pollution Degrees Definitions and Examples: Overview of measurement categories according to IEC 61010-01 O = No Measurement Category (Other circuits that are not directly connected to mains) Pollution Degree 1 No POLLUTION or only dry, nonconductive POLLUTION. NOTE: The POLLUTION has no influence.
The cable has no wear indicator. If the contrasting color of the wear indicator of the 4mm input cable has become visible, then stop using the probe and contact your local PMK service center. Refer to qualified service personnel.
Review the Ordering Information at the end of this document for more details. The interface box is powered by the required PMK power supply. The referring power supplies all have remote control capabilities and therefore a USB interface and optional additional LAN interface.
Read the Instruction Manual before first use and keep it for future reference. A digital copy of the latest Instruction Manual revision can be downloaded at www.pmk.de. Do not exceed the specifications. Allow the probe to warm up for 20 minutes. This probe comes with 2 years warranty.
Page 8
® BumbleBee Series Instruction Manual Model ± 400 V BumbleBee ± 200 V BumbleBee Article number 880-122-501 (2 m) 880-112-501 (2 m) 880-127-501 (7 m) 880-117-501 (7 m) Attenuation* 100:1, 50:1, 20:1, 10:1 50:1, 25:1, 10:1, 5:1 (< ± 1 % guaranteed) Bandwidth* (-3 dB) Small 100:1, 50:1: 500 MHz 50:1, 25:1: 500 MHz...
® Typical Voltage Derating Note that the maximum input voltage rating of the probe decreases as the frequency of the applied signal increases. Typical Voltage Derating – BumbleBee ® Series No Measurement Category Typical Input Impedance The input impedance of the probe decreases as the frequency of the applied signal increases. Typical Differential Input Impedance –...
® BumbleBee Series Instruction Manual Maximum Input Voltage, Example 2000V Model, 500:1 Range Maximum Input Voltage, Example 200V Model, 5:1 Range Cleaning To clean the exterior of the probe, use a soft cloth moistened with either distillated water or isopropyl alcohol.
3+5 Negative active Offset XL * 4+6 Positive active Offset XL * Set Button * Change the factory presets via the remote control software "PMK Probe Control". LED Lights A - C A Attenuation Indicators (varying with model) B Overvoltage Indicators: Input Channels, Output C Colored Indicator of the Measuring Channel (*) Factory presets change by remote control, e.g.
® User Default The user default settings of the BumbleBee series probe are loaded automatically when the probe is ® powered up. They are saved in real-time, with no need to actively save or recall at any time. Keylock If no key is pressed 10 seconds after opening the menu the keypad will be locked. Press the "Set" button again to release it.
5s and wait until you hear a differing signal. EMC Noise Suppression Kit (optional) For use of PMK’s high-voltage differential probes in environments with high levels of interference, like in double-pulse tester applications for analysis of fast switching power devices, the EMC noise suppression kit 891-102-EMC is recommended.
® Scope of Delivery A PMK power supply is required for all models. See chapter “Ordering Information” to review the selection. Probe BumbleBee series (different model, different color) ® Factory calibration certificate Instruction manual 890-520-000 Power Supply Cable (0.5 m), 30VAC / 60V DC (1.5m cable available as option)
Step 2: Select Additional Accessories Note, that any additional accessory degrades the probe’s performance. Always observe the lowest Maximum Input Voltage. Do not use any other accessories than recommended by PMK. 891-102-EMC Noise Suppression Kit, recommended for use in environments with high levels of interference (EMI), (3x ferrites &...
Page 17
® 4mm-BNC-F 4mm safety banana socket to BNC socket adapter, for high-frequency voltage measurements, 750V DC + AC pk, 1500V peak pulse D010031 50Ω BNC feed-through for 1MΩ input oscilloscopes. >500MHz 890-880-112 5x Pair of Rail Clip Connectors 4 mm (black, red), 600V CATIII 890-880-115 Pair of Clamps, Hook (black &...
Page 18
– spare part, for use with PMK’s SKID positioning system for PCBs and probes 890-880-104 Twin holder M6 – spare part, for use with PMK’s SKID positioning system for PCBs and probes Step 5: Select Accredited Calibration...
