Mondo

Installation Guide

For Model:

MND80*

*BNK and SBFB finish is Indoor Use ONLY

WARNING:

DC Motor will not

operate until blades

are installed

3170356

APPROVED FOR USE

IN DAMP LOCATIONS*

net weight of fan: 21.12 lb (9.58 kg)

READ THESE INSTRUCTIONS AND

SAVE THEM FOR FUTURE USE

Need help?

Do you have a question about the Mondo MND80 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Craftmade Mondo MND80 Series

Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Mondo Installation Guide Table of Contents: For Model: Safety Tips. pg. 3 MND80* Unpacking Your Fan. pg. 4 Parts Inventory. pg. 4 Installation Preparation. pg. 5 *BNK and SBFB finish is Indoor Use ONLY Hanging Bracket Installation.
Page 2 Activating Your New Smart Fan; Downloading the Bond Home App • Using your smart device, navigate to the application store (Apple App store or Google Play), download the free Bond Home app and create account. • Ensure the fan and receiver are receiving power from the house supply using the remote control to turn the fan and light ON and OFF.
Page 3: Safety Tips
Light kit is dimmable to 10% with the remote control included. Distributed by: Craftmade, 3901 S 20 Avenue, DFW Airport, TX, 75261; 800-486-4892 NOTE: The important safety precautions and instructions appearing in the manual are not meant to cover all possible conditions and situations that may occur.
Page 4: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs.
Page 5: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure that inches 7 feet the hanging location allows the blades a clearance (2.13m) (76cm) of 7 feet (2.13m) from the floor and 30in. (76cm) from any wall or obstruction. This fan is suitable for room sizes up to 400 square 12ft.
Page 6: Fan Assembly. Pgs
stop pin 5. Fan Assembly. set screw Remove hanging ball from downrod provided by loosening set screw on hanging ball. Lower hanging hanging ball ball and remove stop pin and then slide hanging ball off of the downrod. [Refer to diagram 1.] Loosen yoke set screws and nuts at top of motor diagram 1 housing.
Page 7 5. Fan Assembly. (cont.) With the hanging bracket secured to the safety cable loop wood outlet box and able to support the fan, you are ceiling joist now ready to hang your fan. Grab the fan firmly with two hands. Slide downrod through wood screw opening in hanging bracket and let hanging and washer...
Page 8: Wiring
6. Wiring. white supply wire WARNING: Turn off circuit breakers to current ground (green fixture from breaker panel and be sure switch is black supply wire or bare) turned to the OFF position. ground (green/bare) ground CAUTION: Be sure outlet box is properly (green white grounded and that a ground wire (GREEN or Bare)
Page 9: Blade Assembly
8. Blade Assembly. WARNING: To reduce the risk of serious bodily injury, DO NOT use power tools to motor housing assemble the blades. If screws are overtightened, blades may crack and break. Locate 24 blade attachment screws/lock blade washers in hardware pack. Slide blade through one of the narrow, rectangular openings on motor housing, aligning holes in blade with blade arm...
Page 10 9. Light Kit Assembly. (cont.) If you wish to USE the light kit, align grooves on shade with nodules on inside of LED light kit and motor housing push up gently on shade. Turn shade to the RIGHT (clockwise) until shade locks into place. Pull down VERY GENTLY on shade to make sure that shade is secure.
Page 11: Automated Learning Process
10. Automated Learning Process./Activating Code. (cont.) IMPORTANT: Store the remote control away from excess heat or humidity. To prevent damage to remote control, remove the battery if remote control will not be used for long periods. NOTE: Remove battery with low or no charge and dispose of properly. CAUTION: “DO NOT DISPOSE OF BATTERIES IN FIRE, BATTERIES MAY EXPLODE OR LEAK.
Page 12: Activating Your Ceiling Fan Smart Features
12. Activating Your Ceiling Fan Smart Features. (Optional) To enjoy all your ceiling fan smart features (such as Breeze speed setting, Schedules, Voice Activation, and more), you must connect it to your Wi-Fi network. Please follow these steps: 1. Download the Bond Home App, available on the Google Play Store and Apple App Store, or use the QR code to download the app.
Page 13: Testing Your Fan
13. Testing Your Fan. It is recommended that you test fan before finalizing installation. Restore power from circuit box and light switch (if applicable). Test the light ON/OFF function by pressing the button; test the dimmer function by pressing the button and holding it down for up to 5 seconds.
Page 14: Troubleshooting
WARNING: Failure to disconnect power supply prior CRAFTMADE LIMITED LIFETIME WARRANTY: to troubleshooting any wiring issues may result in CRAFTMADE warrants this fan for use as intended under serious injury. the following provision: CRAFTMADE will replace any fan which has faulty performance due to a defect in material Problem: Fan fails to operate.
