Mondo
Installation Guide
For Models:
MND54BNK3
MND54ESP3
E192641
net weight of fan: 8.89 lb (4.03 kg)
READ THESE INSTRUCTIONS AND
SAVE THEM FOR FUTURE USE
Table of Contents:
Safety Tips. pg. 1
Unpacking Your Fan. pg. 2
Parts Inventory. pg. 2
Installation Preparation. pg. 3
Hanging Bracket Installation. pg. 3
Fan Assembly. pgs. 4 - 5
Wiring. pg. 6
Canopy Assembly. pg. 7
Blade Assembly. pg. 7
Switch Housing Assembly. pg. 7
Testing Your Fan. pg. 9
Troubleshooting. pg. 10
Parts Replacement. pg. 10
Warranty. pg. 10
PRINTED IN CHINA
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Craftmade Mondo MND54ESP3
Summary of Contents for Craftmade Mondo MND54ESP3
-
Page 1: Table Of Contents
READ THESE INSTRUCTIONS AND SAVE THEM FOR FUTURE USE Mondo Installation Guide For Models: MND54BNK3 Table of Contents: MND54ESP3 Safety Tips. pg. 1 Unpacking Your Fan. pg. 2 Parts Inventory. pg. 2 Installation Preparation. pg. 3 Hanging Bracket Installation. pg. 3 Fan Assembly. -
Page 2: Safety Tips
SAFETY TIPS. WARNING: To reduce the risk of electrical shock, turn off the electricity to the fan at the main fuse box or circuit panel before you begin the fan installation or before servicing the fan or installing accessories. READ ALL INSTRUCTIONS AND SAFETY INFORMATION CAREFULLY BEFORE INSTALLING YOUR FAN AND SAVE THESE INSTRUCTIONS. -
Page 3: Unpacking Your Fan
1. Unpacking Your Fan. Carefully open the packaging. Remove items from Styrofoam inserts. Remove motor housing and place on carpet or Styrofoam to avoid damage to finish. Do not discard fan carton or Styrofoam inserts should this fan need to be returned for repairs. -
Page 4: Installation Preparation
3. Installation Preparation. blade edge To prevent personal injury and damage, ensure 10 feet inches that the hanging location allows the blades a (3.05m) (76cm) clearance of 10 feet (3.05m) from the floor and 30in. (76cm) from any wall or obstruction. 12ft. -
Page 5: Fan Assembly. Pgs
5. Fan Assembly. set screw set screw hole If you wish to extend the hanging length of your stop pin fan, you must remove the hanging ball from the downrod provided to use with an extended downrod (sold separately). [If you wish to use the hanging ball downrod provided, please proceed to instructions following the dotted line below.]... - Page 6 5. Fan Assembly. (cont.) With the hanging bracket secured to the outlet box and able to support the fan, you are now safety cable loop wood ready to hang your fan. Grab the fan firmly with ceiling two hands. Slide downrod through opening in joist hanging bracket and let hanging ball rest on the hanging bracket.
-
Page 7: Wiring
6. Wiring. white supply wire CAUTION: Be sure outlet box is properly grounded or ground that a ground wire (GREEN or Bare) is present. (green or bare) black supply wire Make sure all electrical connections comply with Local Codes or Ordinances and the National Electrical Code. If you are unfamiliar with electrical wiring or if the from ceiling wire... -
Page 8: Canopy Assembly
7. Canopy Assembly. Locate 2 screws on underside of hanging bracket and hanging bracket remove screw closest to the open end of the hanging screw bracket. Partially loosen the other screw. Lift canopy to hanging bracket. Place rounded part of slotted hole in canopy over loosened screw in hanging bracket and canopy push up. -
Page 9: Automated Learning Process./Activating Code
10. Automated Learning Process./Activating Code. wall control remote control IMPORTANT: Remote and wall controls must be III IV SYNCHRONIZED with fan in order to properly function. IMPORTANT: The code switches in remote and wall controls MUST MATCH ON ECE for fan to function 1 2 3 4 properly. -
Page 10: Testing Your Fan
11. Testing Your Fan. Wall Control It is recommended that you test fan before finalizing installation. Locate ON/OFF slider switch on wall control and set to the ON position. Test fan speeds with the different fan speed buttons. If the remote III IV control operates all of the functions of the fan, reverse... -
Page 11: Troubleshooting
2. Check to be sure code switches in remote to arrange for return of fan. Return fan, shipping prepaid, to control transmitter and wall control are set Craftmade/Ellington. We will repair or ship you a properly. replacement fan, and we will pay the return shipping cost.
