- Page 1 ® ® PL-X OPERATOR’S SAFETY MANUAL COMPACT FIXED OUTRIGGER STRADDLE Platform height Platform height Platform height Platform height up to 12 ft (3.66 m) up to 20 ft (6.10 m) up to 20 ft (6.10 m) up to 24 ft (7.32 m) 4028318...
-
Page 2: Safety Alert Symbols + Safety Signal Words
The purpose of this manual is to provide safe and proper THIS PRODUCT MUST COMPLY WITH ALL SAFETY-RELATED BULLETINS. CONTACT operating procedures for anyone utilizing this machine. Because we at ReechCraft, Inc. are REECHCRAFT, INC. OR THE LOCAL AUTHORIZED REECHCRAFT REPRESENTATIVE FOR... -
Page 3: Table Of Contents
5-year Machine Inspection + Track Replacement ..........57 3.0 Introduction ......................26 6.2 Preventive Maintenance + Inspection Schedule ........... 58 3.1 Machine Description ....................26 Inspection + Maintenace Codes ................58 3.2 Drill Motor ........................ 28 PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... - Page 4 3.10 Maneuvering When Tilted Back with Outrigger Base Tilt-back Option Only ..36 Manual Descent Crank Operation .................39 Emergency Retraction System ................40 Label Locations (1 of 3) ...................43 Machine Specifications (1 of 4) ................50 Mast/Track Alignment .....................62 PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160...
-
Page 5: Section 1 - Safety Precautions
• Do not operate any machine on which the safety labels or manufacturer plates the Operator’s Safety Manual of the machine. are missing or illegible. Contact ReechCraft for replacement label options. See Section 6.4 for replacement instructions. • Only competent personnel may operate the machine. -
Page 6: Operation
• Never operate a machine that is not working properly. If a malfunction occurs, stop operating the machine and contact ReechCraft. • An anchor point is provided for fall restraint systems. • Unless in an emergency, do not allow personnel to tamper with or operate the Electrocution Hazards machine from the ground with personnel on the platform. -
Page 7: Tipping Hazards
Note: The platform will not release from its docked position unless each outrigger is in its proper position and bearing weight. PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... -
Page 8: Crushing + Collision Hazards
• Be sure to lock two or more of the casters before leaving the machine unattended. • Use caution when transporting the machine on a slope. • Machine is intended for indoor use only. Do not use outside. PowerLift by ReechCraft , Inc. ®... -
Page 9: Preparation, Inspection, + Maintenance
2.2 Preparation, Inspection, + Maintenance Table 2.0 outlines the periodic machine inspection and maintenance recommended by ReechCraft. Consult local regulations for further requirements. The frequency of inspections and required maintenance must be increased if the machine is exposed to Pre-start Inspection harsh conditions, increased use, or if the machine is used in a severe manner. -
Page 10: Walk-Around Inspection Components
If Level using an outrigger base, make sure the bubble level is clean and functioning Outrigger and that all four outrigger pins are Retaining functioning properly. (See Figure 2.1) PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... - Page 11 Figure 2.5 - Platform Mounting + Retaining Pins Platform 0.2 in. Entry Gate (5 mm) Retaining Pin Opening Mounting Bracket Figure 2.4 - Location of Manual Descent Crank Input Hex Shaft Platform Retaining Pin Manual Descent Crank PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160...
-
Page 12: Inspection Points For Straddle Base Option
• Locking Caster Wheels - Be sure all wheels are bolted and have brakes. • Access Step - Be sure all pins are present and connected through the basket. Leg Adjustment Pins Outrigger Swivel Lock Pins Ladder Locking Caster Wheels PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... -
Page 13: Function Check
(See Figure 2.6) (XM Only) • Leg Adjustment Cams - If using the straddle base, be sure the cams draw the legs tight to the outrigger truss. (See Figure 2.6) PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... -
Page 14: Section 3 - Machine Operation
20. Tilt-Back Handle (Not pictured) 8. Platform Entry Gate 21. Ladder The ReechCraft PowerLift is a drill-powered mobile elevating work platform (MEWP) for 9. Platform Retaining Pin 22. Adjustable Leg indoor use. The removable platform is mounted to an elevating climbing unit that adds 10. -
Page 15: Drill Motor
3.2 Drill Motor 3.3 Machine Operation ReechCraft recommends a cordless drill of at least 18-volt capacity. When the platform reaches the bottom of its travel, the overload clutch creates a ratcheting or buzzing noise, indicating that the machine has reached the fully lowered Ensure the drill motor’s optional “hammer”... -
Page 16: Machine Setup
For straddle base option: • Release the cam levers and assemble the legs vertically from top down. Because the ReechCraft PowerLift is a modular operator-assembled machine, the platform, outriggers, and mast sections can be removed to reduce weight for easier transport. -
Page 17: Elevating/Lowering
The manual descent crank (see Figure 4.0) is provided to allow the machine operator to lower the platform in the event that the drill motor loses power or contains insufficient power to lower the platform. Note: For emergency operation please see Section 4 on emergency procedures. PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... -
Page 18: Separating Mast Sections
• Be sure to maintain a firm grasp of the handle at all times during transport. • Familiarize yourself with the terrain and identify and avoid any overhead or ground hazards before tilting back and transporting. PowerLift by ReechCraft , Inc. ®... -
Page 19: Parking + Storage
Place a buffer between the device and any part of the machine. TECHNIQUES: BEND AT THE KNEES ONLY, NEVER TWIST YOUR BACK WHEN HOLDING OR CARRYING A LOAD, AND/OR GET HELP . ONLY CARRY ONE COMPONENT AT A TIME. PowerLift by ReechCraft , Inc. ®... -
Page 20: Section 4 - Emergency Procedures
• Remove the manual descent crank from the mounting clip inside the platform. • Engage the drive shaft with the manual descent crank. • Wind counterclockwise until the platform lowers fully. (See Figure 4.0) PowerLift by ReechCraft , Inc. ®... -
Page 21: Operator Unable To Control The Machine
In USA: 1-888-600-6160 Outside USA: 1-701-280-5900 Failure to notify the manufacturer of an incident involving a ReechCraft PowerLift product 2. Attach the winch to the base mast within 48 hours of such an occurrence may void any warranty consideration on that and unwind the strap. -
Page 22: Section 5 - General Specifications
Outrigger 4028294 level the base. Level the Base. The outrigger base must be leveled according to the Outrigger 4028312 bubble level before raising the platform. PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... - Page 23 Model Information. Identifies the manufacturer, manufacturer’s address, model, and serial number of the machine. It is located on primary 4028287 detachable parts (bases, masts, platform). Labels are not shown in Fig 5.0b. PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160...
- Page 24 4028293 stabilizer indicator. Emergency Lowering Instructions 4028307 Caution Not a Step 4028295 BRANDING LABELS DESCRIPTION LABEL Left Platform Brand 4028289 Right Platform Brand 4028291 Front Platform Brand 4028290 PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160...
-
Page 25: Machine Specifications
116.4 (2957) 164.4 (4176) 212.4 (5395) 261.6 (6645) 309.6 (7864) 217.2 (5517) 314.4 (7986) 304.8 (7742) 360 (9140) *Based on platform height plus 6 ft (1.8 m). Based on maximum possible machine weight. † PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... - Page 26 GENERAL SPECIFICATIONS GENERAL SPECIFICATIONS Figure 5.1a - Machine Specifications (Compact Base) Figure 5.1b - Machine Specifications (Fixed Base) PowerLift by ReechCraft ® , Inc. reechcraft.com 1-888-600-6160...
- Page 27 GENERAL SPECIFICATIONS GENERAL SPECIFICATIONS Figure 5.1d - Machine Specifications (Straddle Base) Figure 5.1c - Machine Specifications (Outrigger Base) PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160...
-
Page 28: Section 6 - Service + Maintenance
RESULT IN MACHINE DAMAGE, PERSONAL INJURY, OR DEATH. Due to our commitment to continuous improvement, ReechCraft reserves the right to • Remove all rings, watches, and jewelry when performing any maintenance. make specification changes without prior notification. Contact ReechCraft for updated information. -
Page 29: Machine Preparation, Inspection, + Maintenance
It is important to establish a comprehensive inspection and preventative maintenance frequency of use requires. program. Table 2.0 outlines the periodic machine inspection and maintenance recommended by ReechCraft. Consult your local, regional, or national regulations for Reference Table 6.0 for the preventative maintenance and inspection schedule. further requirements. -
Page 30: Preventive Maintenance + Inspection Schedule
3,4,7 Rough Terrain Wheels 3,4,7 3,4,7 Drill 7,11 7,11 7,11 Drive Shaft Brake 1,3,7,8 1,3,7,8 1,3,7,8 Manual in Storage Container Labels Installed and Secure No Unauthorized Modifications Fasteners and Pins Function Test PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... -
Page 31: Servicing + Maintenance Guidelines
WHEN AN ABNORMAL CONDITION IS NOTED AND PROCEDURES CONTAINED WITHIN Replacement labels can be requested from ReechCraft customer service at 1-888-600-6160 THIS MANUAL DO NOT SPECIFICALLY RELATE TO THE NOTED IRREGULARITY, USE OF or customer.service@reechcraft.com. -
Page 32: Mast Track Wear
This means that problems for which the probable cause and remedy may be immediately obvious are not listed in this section. 0.2 in. (5 mm) Wear Bent/Misshapen 0.03 in. (0.75 mm) Loose Connector PowerLift by ReechCraft , Inc. ® reechcraft.com 1-888-600-6160... -
Page 33: Troubleshooting Guide
ReechCraft product (the “end user”) and is a “manufacturer’s” warranty provided directly in the locked position when using the to relieve pressure. Ensure all leveling jacks by ReechCraft to the end user, effective on the end user’s original date of purchase. For outrigger base. are stable and bearing equal weight. - Page 34 (f) that has been improperly maintained THEORIES OF NEGLIGENCE, RECKLESSNESS, STRICT LIABILITY, OR DEFECTIVE or maintained, altered, modified, or repaired by someone other than ReechCraft or a PRODUCT LIABILITY), OR ANY LEGAL THEORY, EVEN IF ADVISED OF THE POSSIBILITY ReechCraft authorized service center;...
- Page 35 ® ® ReechCraft , Inc. ® 845 34th St N Fargo, ND 58102 1-888-600-6160 reechcraft.com/powerlift...
