Summary of Contents for oticon ConnectClip
- Page 1 Call Absolute Hearing Solutions ConnectClip 614-452-4280 Instructions for use...
- Page 2 This booklet guides you on how to use and maintain your new ConnectClip. Please read the booklet carefully, including the Warning section. This will help you get the most out of your new ConnectClip. If you have additional questions about the use of your ConnectClip, please contact your hearing care professional.
- Page 3 The ConnectClip is intended as a wireless receiver and transmitter of sound between The ConnectClip can be used both as a wireless headset for mobile phones and as a hearing aids and the surrounding environment, including speech and wireless electronic remote microphone/partner microphone.
-
Page 4: Table Of Contents
Starting/stopping sound from remote microphone using your hearing aids Daily use: On/Off Cleaning the ConnectClip Daily use: Charging Using ConnectClip as a remote control for hearing aids Using ConnectClip with mobile phone Using ConnectClip as a remote control for hearing aids Other features and functions... -
Page 5: Package Contents
Call Absolute Hearing Solutions Package contents 614-452-4280 The ConnectClip box consists of the following elements: ConnectClip Lanyard - long Lanyard - regular Pouch Instructions for use ConnectClip This guide Wall charger USB charger cable Protective skin (Instructions for use) (will vary from... -
Page 6: Overview - Main Functions
Call Absolute Hearing Solutions Overview - main functions 614-452-4280 Status Power indicator LED indicator LED Microphones Multi-button Clip (rotating) - On/off - Answer phone for wearing the - Mode selector ConnectClip Volume - Up - Down Front Back Charging socket. Micro USB... -
Page 7: Overview - Connectclip Led Indicators
Call Absolute Hearing Solutions Overview - ConnectClip LED indicators 614-452-4280 Status Description Power Description • Blinking yellow Searching for hearing aids Steady red Battery low • • Steady yellow Idle. Hearing aids connected, Not connected to a phone Steady green... -
Page 8: Getting Started
Call Absolute Hearing Solutions Getting started 614-452-4280 Before you can use the ConnectClip with your hearing aids, both the hearing aids and 2. Pairing ConnectClip and mobile phone the ConnectClip need to be paired/connected. Using the ConnectClip with a mobile phone also requires the ConnectClip to be paired with/connected to your mobile phone. -
Page 9: Pairing Hearing Aids With The Connectclip
Call Absolute Hearing Solutions A. Pairing hearing aids with the ConnectClip 614-452-4280 1. Ensure ConnectClip is powered off (see page 20) 5. ConnectClip will now search for Press and hold Multi-button for approx. 6 seconds your hearing aids. until Power indicator OFF Status indicator BLINKING YELLOW 2. -
Page 10: Pairing Mobile Phone With The Connectclip
Call Absolute Hearing Solutions B. Pairing mobile phone with the ConnectClip 614-452-4280 Place ConnectClip in pairing mode Enable pairing on mobile phone Press and hold the Multi-button AND Turn on Bluetooth. Search for and connect to/pair Volume UP button for about 6 seconds with ConnectClip. -
Page 11: Daily Use: On/Off
Call Absolute Hearing Solutions Daily use: On/Off 614-452-4280 Expected battery life per charge 16 hours: Up to 2 hours music streaming + Typical daily use 2 hours phone + 12 hours standby Press and hold Multi-button for approx. 3 seconds until Power indicator shows STEADY GREEN. Standby (Turned on, no Streaming) Up to 36 hours Music or Remote mic... -
Page 12: Daily Use: Charging
When recharging, the charging indicators should be lit as described in this “Instructions for Use”. If none of the charging indicators are lit, disconnect the device from the charger and consult your hearing care professional. Important notice When recharging the ConnectClip, use the supplied original power supply 5.0V/1A, CE and safety marked. -
Page 13: Using Connectclip With A Mobile Phone
ConnectClip is pointing towards your mouth Connected to mobile phone (A) in a vertical position, and that the ConnectClip is not covered by clothes etc. • Maximum distance between ConnectClip and mobile phone is 32 ft. -
Page 14: Receiving Calls
614-452-4280 Phone connected Answer call When the ConnectClip is turned on and is in range of your Either click the Multi-button shortly (A) -or answer mobile phone it will automatically connect to the mobile phone. the call from your mobile phone. -
Page 15: Making Calls
To make a call you only have to use the mobile Short press Volume Up or Down will unmute hearing aids phone. The call will automatically be connected to the ConnectClip. Once the call is connected the status will change to STEADY GREEN... -
Page 16: Listening To Music
You do not need to operate anything on the phone to start the sound. Volume Down on the ConnectClip to listen to music, but the ConnectClip must be turned on. Status Description • The ConnectClip is turned on - and streaming music from the phone... -
Page 17: Using Connectclip As A Remote Microphone
Status STEADY MAGENTA Status Description • The ConnectClip is turned on. In idle mode i.e. not connected to a phone IMPORTANT • Connected to mobile phone Ensure that the microphone is pointing to the speaker’s mouth and that it is not •... -
Page 18: Starting/Stopping Sound From Remote Microphone
Call Absolute Hearing Solutions Starting/stopping sound from remote microphone Regulating level from remote microphone 614-452-4280 Stop sound from Microphone Volume Up or Volume Down Press and hold Multi-button (A) for approx. 3 The streamed signal can be adjusted seconds to stop the signal from the microphone using the Volume Up/Down buttons. -
Page 19: Starting/Stopping Sound From Remote Microphone Using Your Hearing Aids
IMPORTANT IMPORTANT Use a soft, dry cloth to clean the ConnectClip. It must never be washed or Please refer to your hearing aid’s instructions for details on the functionality of your specific hearing aid solution. -
Page 20: Using Connectclip As A Remote Control For Hearing Aids
Timeout (out of range) when in microphone mode - short press microphones - If the ConnectClip is out of range of the hearing aids - the hearing aids will long press Volume Down return to their initial program after 90 seconds. -
Page 21: Warnings
The ConnectClip must never be exposed to extreme heat e.g. left inside a parked car ConnectClip and its parts should be kept out of reach of children and anyone who might in the sun. The ConnectClip must not be dried in microwave ovens or other ovens. - Page 22 Using the ConnectClip can distract you. Be aware of your surroundings while using Do not attempt to open the ConnectClip, as this may damage the battery and void the ConnectClip. Please refer to national and state traffic laws regarding the use of the warranty.
- Page 23 Cross control Mobile phone compatibility Your ConnectClip should be kept out of reach of children or anyone who might take control Please refer to www.oticon.global/compatibility for a list of mobile phones that have been of the functionality, to ensure your personal safety and avoid incorrect use.
-
Page 24: Technical Information
The ConnectClip complies with international standards concerning radio transmitters, This Class B digital apparatus complies with Canadian ICES-003. electro-magnetic compatibility and human exposure. Due to the limited space available on the ConnectClip, relevant approval markings can be found in this booklet. -
Page 25: International Warranty
• Connect the equipment into an outlet on a circuit different from that to which If you need service the receiver is connected. Take your ConnectClip to your hearing care professional, who may be able to sort out minor • Consult the manufacturer or an experienced radio/TV technician for help. problems and adjustments immediately. - Page 26 Call Absolute Hearing Solutions The manufacturer declares that this ConnectClip (AC1A) is in compliance with the essential 614-452-4280 requirements and other relevant provisions of Directive 2014/53/EU. The declaration of Conformity is available from the manufacturer. SBO Hearing A/S Kongebakken 9 DK-2765 Smørum...
- Page 27 Call Absolute Hearing Solutions 614-452-4280 Description of symbols used in this booklet Indoor use Indicates that the product is qualified for indoor use. Warnings Double insulation Text marked with a warning symbol must be read before using the device. Indicates that product power supply is double insulated. This means a very low risk of single Manufacturer fault failures, i.e.
- Page 28 Call Absolute Hearing Solutions 614-452-4280 0000195098000001...
