TESTO 802912 1211 User Manual page 9

User Manual - Technical data and assembly instructions
Matching accessories: Thermocouple cables
Details of accessories can be found on our website.
Thermocouple cables
Please select your desired cable first.
Order
Type
code
809300 2 Thermocouple cable
809310 2 Thermocouple cable
Insulation resistance: ≥ 100 MOhm at min. 100 VDC |
Now please select the length and add the code to the article no. of the cable.
Length (m) 1
Code 010
Please append these digits to the part number of your desired cable.
Matching accessories: Connector
Connector
Picture Code
809140 2000
809100 2000
809150 2000
809110 2000
Other connectors available on request
Testo Sensor GmbH
+49 7653 96597-71
Testo-Straße 1 webshop@testo-sensor.de
D-79853 Lenzkirch Please find our whole temperature probe and transmitter portfolio in our webshop at:
From To
Color IP
(°C) 1} (°C)
Type K IP67 -30 +105
3}
Type K IP67 -50 +180
3}
per. °C range | Tolerance ± 0.2 mm |
1} 2}
2 5
020 050
Feature Technical drawing
Mini-TC
connector Type
K gn
Mini-TC coupling
Type K gn
TC connector
Type K gn
TC coupling Type
K gn
