4. Technical data and assembly instructions

Cross-band probe with ring magnet
Article no.802912 1211
All our cross band probes are ideal for contact temperature measurement on surfaces.
Their type is developed for the fastest surface temperature measurements and ensures the
shortest response times due to the filigree head design.
The type with the strong ring magnet allows you to connect the probe flexibly, safely and
quickly to different measuring points. The ergonomic handle serves as heat protection and
includes an integrated bend protection.
We offer different cable lengths and materials so that you can optimally adapt the probe to
your installation situation. You will find suitable connectors and connection cables in our
accessories.
General Information
Measuring range
Perm. °C range cable
Perm. °C range probe head
Pull-out force probe head
Accuracy
Response time
Supply and output
Measuring element
Measuring point
Measurement signal
Ambient conditions
Protection class
Humidity and moisture
condensation resistance
Certificates and Standards
Standards
Directive
Certificates
Probe head
Contact geometry
Material probe head
Length probe head (mm)
Ø probe head (mm)
E - Cable material and configuration connection cable
Code Type
E8020 Thermocouple cable
E8220 Thermocouple cable
Thermocouple
E8120
compensating cable
Insulation resistance: ≥ 100 MOhm at min. 100 VDC |
Testo Sensor GmbH
+49 7653 96597-71
Testo-Straße 1 webshop@testo-sensor.de
D-79853 Lenzkirch Please find our whole temperature probe and transmitter portfolio in our webshop at:
-40 °C to +180 °C - The measuring range depends on The cable and
contact body.
see cable
+ 180 °C
≥ 30 N
-40 °C to +333 °C: ±2,5 °C according to DIN IEC 60584 Class 2
t63: < 0,8 s t99: < 3 s
Thermocouple Type K Class 2
Measuring point not isolated
Thermovoltage
none (open measuring head)
according to application-specific qualification
DIN EN 61326-1:2013 | DIN EN IEC 63000:2019-05
RoHS 2011/65/EU | 2014/30/EU
Certificate of suitability (on request)
Cross band (fitting)
Aluminium
37 (with bend protection 53)
20
From To
Color IP
(°C) (°C)
1} 1}
Type K 3} IP67 -30 +105
Type K IP67 -50 +180
3}
Type K IP67 -50 +205
3}
Perm. range °C |
1}
Managing Director: Prof. Burkart Knospe, Martin Arndt, Timo Löffler
Amtsgericht Freiburg HRB 706025 | Umsatzsteuer-ID.: DE274417683
Outside Material
Ø (mm)
material strand
PVC PVC 3,8
Silicone FEP 3,6
FEP FEP 4
Tolerance ± 0,2 mm | Color according to IEC 584 |
2} 3}
Customizable options
E - Material connection cable
F - Length connection cable
G - Connector
Color
2} Q (mm²)
strand
0,22 gn, wt
0,22 gn, wt
0,22 gn, wt
per thermocouple
4}
www.testo-sensor.shop
Ω / m 4}
4,5
4,5
4,5
