- Page 1 Power Eagle Self–Contained Carpet Extractor Model No.: Operator and Parts Manual 608543 609234 – SI NOBLES 12875 RANSOM STREET HOLLAND MI 49424 U.S.A. 608548 CUSTOMER SERVICE: 1-800-365-6625 FAX: 1–800–678–4240 Rev. 01 (01-00) Home Find... Go To..
-
Page 2: Table Of Contents
E1999 Tennant Company Printed in U.S.A. subsidiaries. Nobles is a registered United States trademark of Tennant Company. Power Eagle is a United States trademark of Tennant Company. This machine will provide excellent service. However, the best results will be obtained at minimum costs if: The machine is operated with reasonable care. -
Page 3: Safety Precautions
OPERATION 4. Before leaving or servicing machine: SAFETY PRECAUTIONS – Turn off machine. – Unplug cord from wall outlet. This machine is intended for commercial use. It is 5. When servicing machine: designed to clean carpet and upholstery in an indoor –... -
Page 4: Machine Setup And Operation
OPERATION 5. Connect extension cord to machine’s pigtail cord and attach belt clip to your belt. Plug cord into a MACHINE SETUP AND OPERATION grounded wall outlet (Figure 3). GROUNDED OUTLET FOR SAFETY: Do not operate machine unless (3 HOLE) operator manual is read and understood. -
Page 5: Maintenance
OPERATION ATTENTION: The solution hose contains pressurized cleaning solution which can spray when hose is disconnected. Relieve pressure before disconnecting hose by squeezing hand tool trigger for five seconds after turning off master switch. 6. After relieving pressure in hose, disconnect solution and vacuum hoses. -
Page 6: Storing Machine
OPERATION MONTHLY MAINTENANCE STORING MACHINE 1. Flush pump system with an acetic acid solution to dissolve normal alkaline chemical buildup. 1. Before storing machine, be certain to flush tanks a. Premix .5L (16 oz) of an acetic acid solution and drain machine of all water. with 7.5L (2 gal) of hot water 60_ C (140_F ) 2. -
Page 7: Trouble Shooting
OPERATION TROUBLE SHOOTING PROBLEM CAUSE SOLUTION Machine does not operate. Faulty switches or wiring. Contact Service Center. Faulty power cord. Contact Service Center. Building circuit breaker tripped. Reset breaker. Solution pump does not operate. Overheated pump. Determine cause and wait 20 minutes for pump to cool. -
Page 8: Specifications
OPERATION SPECIFICATIONS Model Power Eaglet 716 LENGTH 991 mm (39 in) WIDTH 406 mm (16 in) HEIGHT 864 mm (34 in) WEIGHT 39 Kg (86lb) SOLUTION TANK CAPACITY 31L (7 gal) RECOVERY TANK CAPACITY 31L (7 gal) CLEANING PATH WIDTH 406 mm (16 in) MAXIMUM CLEANING RATE 186 m... -
Page 9: Electrical Diagram
ELECTRICAL DIAGRAMS 120V PUSH BUTTON SWITCH MASTER SWITCH CONDUIT POWER CORD SOLENOID CORD 18/3 VACUUM (Chassis to MOTOR Brush Housing) SOLUTION PUMP GRN/YLW BRUSH MOTOR Power Eaglet 716 (07–99) Home Find... Go To.. -
Page 10: Parts List
PARTS LIST TANK GROUP Power Eaglet 716 (07–99) Home Find... Go To.. - Page 11 HOSE, VAC. 1 1/2” X 19–1/8 W/ CUFFS DECAL LIST (not shown) PART # DESCRIPTION QTY. 608471 DECAL, POWER EAGLE 716 608185 DECAL, NOBLES LOGO 120399 DECAL, DO NOT ALLOW FOAM 120617 DECAL, HEIGHT ADJUSTMENT 602505 DECAL, INSTRUCTION 120906 DECAL, IMPORTANT – DRAIN 120619 DECAL, WARNING –...
- Page 12 PARTS LIST CHASSIS GROUP Power Eaglet 716 (07–99) Home Find... Go To..
- Page 13 PARTS LIST CHASSIS GROUP PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 140553 SCREW, HEX CAP 1/4–20 X 1/2 180103 PUMP, SHURFLO 100 PSI, 120 VOLT 140052 WASHER, EXT LOCK TOOTH 230508 SHIELD, PUMP 140891 SCREW, 10–24 X 5/8 160570 HOSE, 3/8”...
- Page 14 PARTS LIST BRUSH GROUP Power Eaglet 716 (07–99) Home Find... Go To..
- Page 15 PARTS LIST BRUSH GROUP PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 700212 BRUSH ASM, 16” COMPLETE 130471 MOTOR, BRUSH DRIVE 120 VOLT 140887 SCREW, 10–24 X 3/8 140233 SCREW, HEX CAP 3/8–16 X 1–3/4 100734.BK PLATE, BRUSH, 16” 140036 WASHER, FLAT 3/8 100006 GASKET, BASE PLATE...
-
Page 16: Options
OPTIONS 127mm (5 in) HAND TOOL PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 200505 TOOL, HAND (COMPLETE) CAP, VALVE 200431.BK TOOL, HAND 150606 NIPPLE, HEX 1/4 150913 COUPLER, QUICK 150403 ELBOW, ST 1/4 45° 150615 NIPPLE, CLOSE 200992 BODY, SPRAY 1/4F 200905 TRIGGER, HAND TOOL 200996... - Page 17 OPTIONS UPHOLSTERY TOOL PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 200540 TOOL, UPHOL. (COMPLETE) 200844 HOSE, VACUUM 200845 COVER 200837 HOSE, SOLUTION 200843 GASKET 200848 FITTING 190631 KIT, VALVE ASM. 200842 FILTER 210226 VALVE, LP 200841 SCREEN, FILTER 200991 NOZZLE 150606 FITTING, 1/4MX1/4M...
- Page 18 OPTIONS 330mm (13 in) FLOOR TOOL 12 13 PART # DESCRIPTION QTY. PART # DESCRIPTION QTY. 600048 FLOOR TOOL (COMPLETE) 150913 COUPLER, QUICK 200403.BK TOOL, FLOOR 160170 HOSE, SOLUTION, LP 200939 SHOES, S/S 150606 NIPPLE, HEX 1/4” ∇3 200927 ASM., GRIP, ADJ. 140058 WASHER ∇18...
