  • Page 1 325L / 12 cu. ft. SOLAR POWERED BOTTOM MOUNT REFRIGERATOR FROST FREE MODEL NUMBER: UGP-325L W, UGP-325L B OWNER’S GUIDE serial number: NOV23V1...
  • Page 2: Table Of Contents

    Congratulations! You have purchased one of the most efficient refrigeration products available on the market today. The Unique 325L solar powered DC fridge is designed to provide years of efficient, trouble-free operation. The design is optimized for energy savings with an efficient DC compressor and efficient insulation.
  • Page 3: Important Safety Notes

    PROP 65 WARNING CALIFORNIA PROPOSITION 65 WARNING CAUTION Cancer and Reproductive Harm - www.P65Warnings.ca.gov. IMPORTANT SAFETY NOTES • This fridge is designed to operate on 12 or 24 volts DC ONLY. DO NOT CONNECT THIS FRIDGE TO AN AC (alternating current) POWER SOURCE DIRECTLY - YOU CAN PURCHASE AN AC/DC CONVERTOR IF NEEDED (sold seperately.) •...
  • Page 4 IMPORTANT SAFETY NOTES CAUTION • Consult repair manual or owner’s guide before attempting to service this product. All safety precautions must be followed. Service the fridge/freezer only if you are a trained or authorized refrigeration technician. • Follow handling instructions carefully. DISPOSING OF THE APPLIANCE Dispose of your fridge properly, in accordance with federal or local regulations, at an authorized disposal site.
  • Page 5: Set-Up Dimensions

    SET-UP DIMENSIONS The refrigerator is designed for freestanding installation. Ensure the following: • Doors have space to open freely, and that there is adequate ventilation on all sides. • A minimum spacing of 3 inches (75 mm) to the top and the two sides is highly recommended.
  • Page 6: Product Features

    PRODUCT FEATURES FEATURES: 1. Control panel 2. LED light 3. Light switch 4. Glass shelf 5. Crisper 6. Plastic drawer 7. Door rack 8. Power cord 9. DC adapter (*sold seperately) 10. Ice tray 12. Egg tray TECHNICAL PARAMETERS PART QUANTITY DESCRIPTION SUPPLIED...
  • Page 7: Initial Set-Up

    It is not advised to connect an appliance that has been damaged, especially if there is damage to the electrical supply cable or refrigerant circuit. In the event of damage please contact your local product dealer or Unique Appliances for assistance. UNPACKING AND CLEANING Remove all packaging and securing tapes from the appliance.
  • Page 8: Dc Power Connection

    DC POWER CONNECTION THIS FRIDGE MUST NEVER BE CONNECTED DIRECTLY TO ANY AC (alternating current) POWER SOURCE! THE FRIDGE MUST ONLY BE CONNECTED TO A 12V OR 24V DC POWER SOURCE, SUCH AS A SOLAR BATTERY SYSTEM OR CHARGE CONTROLLER. THE FRIDGE WILL AUTOMATICALLY OPERATE ON EITHER 12V OR 24V DC.
  • Page 9 DC POWER CONNECTION (continued) IN-LINE FUSE A 30A in-line fuse is provided with this fridge in order to protect the wiring. For 12V operation, use a 30A fuse. A standard automobile fuse is recommended and the fuse should be wired to the positive (“+”) side of the system close to the positive battery terminal.
  • Page 10: Electrical Diagram

    ELECTRICAL DIAGRAM 1. Fuse 30A 9. Display Panel 2. Driver Board 10. Fridge LED Light 3. Compressor Grounding 11. Lamp Light 4. Fuse 10A 12. No Frost Sensor 5. Frosting Heater 13. Freezer Sensor 6. Fan 14. Fridge Sensor 7. Damper 15.
  • Page 11: Operation

    OPERATION Your Unique fridge, like any battery-powered refrigerating appliance, requires diff erent care than appliances plugged into an electric utility. Prudent operation is the key to extended service. STARTING THE FRIDGE After the fridge has been properly connected to the 12 or 24 VDC power source, the compressor will automatically turn on and the cabinet will begin cooling.
  • Page 12 OPERATION (continued) When the alarm LED is lit, a 3-minute beep will sound and the display will show an error code. The refrigerator has a low-voltage shut-off function intended to protect your battery from exces- sive drain. • When power supply is 12V DC, the refrigerator will shut off if the voltage drops below 9.7V. UV alarm will resume normal status when voltage reaches 11.6V.
  • Page 13 OPERATION (continued) OPENING AND CLOSING THE DOOR The doors are fi tted with uniform sealing strips to prevent warm air and moisture from entering the fridge and freezer compartments. Be sure that the doors and door seals are free from obstructions and form a complete seal around the rim of the fridge/freezer cabinets.
  • Page 14 • Damage to the interior or exterior finish or components after delivery. • Proper power supply, circuit breaker, wiring, and connections. • Replacement of LED lights. - Contact Unique’s technical service department for instructions on how to fix the issue.
  • Page 15 TROUBLESHOOTING Before contacting a service technician, your local product dealer or Unique Appliances, please check the following points. If you contact a technician to repair a fault listed below, or to repair a fault caused by misuse, abuse, or faulty installation, a charge will be made even if the appliance is under warranty.
  • Page 16 Noise • Make sure that the fridge is not touching anything; ensure the fridge has been installed with proper clearances. • Contact Unique’s technical service department for instructions on how to fix the Light does not issue. work • There is an anti-condensate tube on the front frame which will vent heat during Heat refrigerator operation - this is normal.
  • Page 17: Warranty

    If the appliance fails to do so because of a defect in material or workmanship within one year from the original date of purchase: Unique will at our option, repair, exchange, or correct by other means Unique consider appropriate, any part(s) Unique finds to be defective except for the surface finish.
  • Page 18: Contact Us

    APPLIANCE INFORMATION (Manual copy - Keep with your records) To make care and servicing of your fridge easy and efficient, please record the following information for future reference: Model: Serial Number: Purchased From: Date Purchased: NOTES PRODUCT REGISTRATION Please visit our website at https://uniqueappliances.com/product-registration/ to register your product.
  • Page 19 © 2023 Unique Appliances Ltd., 2245 Wyecroft Road, Oakville, Ontario, Canada, L6L 5L7 www.UniqueAppliances.com...
