BOTTOM MOUNT
REFRIGERATOR
MODEL NUMBERS: UGP-328L P S/S
OWNER'S GUIDE
serial number:
JUN21V1
5013515

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Prestige UGP-328L P S/S and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Unique Prestige UGP-328L P S/S

  • Page 1 BOTTOM MOUNT REFRIGERATOR MODEL NUMBERS: UGP-328L P S/S OWNER’S GUIDE serial number: JUN21V1 5013515...
  • Page 2: Table Of Contents

    Be safe using common sense and caution when installing, operating and cleaning this appliance. If you are unsure about any of these instructions or warnings, contact your local product dealer or Unique Appliances for assistance. NEED HELP? Before you call for service, here are a few things you can do to help us serve you better.
  • Page 3: Important Safety Notes

    These warnings are provided in the interest of your safety. Please ensure that you understand them all before installing or using this fridge. Your safety is of paramount importance. If you are unsure about any of these meanings or warnings, contact your local product dealer or Unique Appliances for assistance.
  • Page 4: Grounding Instructions

    IMPORTANT SAFETY NOTES CHILD SAFETY: Do not allow children to play in, on or around the fridge. It is not a toy. THERE IS A DANGER OF SUFFOCATION IF A CHILD BECOMES TRAPPED INSIDE. When the appliance is not in use, secure or remove the doors to prevent children from playing inside the cabinets. DANGER •...
  • Page 5: Installation Instructions

    • This product should be serviced by an authorized technician and only genuine spare parts should be used. • Under no circumstances should you attempt to repair the appliance yourself unless advised by Unique. Repairs carried out by inexperienced persons may cause injury or serious malfunctioning of the appliance. Unauthorized work may void the warranty.
  • Page 6 INSTALLATION INSTRUCTIONS POSITIONING THE APPLIANCE The area in which the fridge is to be installed must be relatively cool, dry, and suitably ventilated. The area must be protected against any inclement weather (rain, snow) and excessive surface dust. To ensure proper function, the appliance must be placed on a flat, firm, and stable surface resting level on all four supports.
  • Page 7: Door Reversal Instructions

    DOOR REVERSAL INSTRUCTIONS TOOLS REQUIRED: Slot head screwdriver, cross head screwdriver IMPORTANT: Please disconnect the power plug from the electrical outlet. Remove the glass shelves, crisper and trays from the unit. Tilt the appliance backwards to an angle of 45°or more and securely support it. Removing the doors –...
  • Page 8: Product Features

    DOOR REVERSAL INSTRUCTIONS Reattaching the doors – Drawing B NOTE: items 14,16 and 17 with be in your enclosed in your manual bag and not fixed on the fridge. 1. Fix the part item 17 Lower hinge-left 2. Fix screws that hold bottom hinge in place 3.
  • Page 9: Operation

    OPERATION STARTING THE FRIDGE After the fridge has been properly connected to a power source, the compressor will automatically turn on and the cabinet will begin cooling. Allow the cabinet to cool for at least 4 hours prior to adding food stuff. OPERATION Tap any key for the first time and the control panel will be activated.
  • Page 10 OPERATION alarm function will be reactivacted if the door is left open for more then 3 minutes and will beep 3 times every 3 minutes until the door is closed. The sound will stop after 10 minutes if the door is not closed.
  • Page 11: Care And Maintenance

    • Proper power supply, circuit breaker, wiring, and connections. • Replacement of LED lights. - Contact Unique’s technical service department for instructions on how to fix the issue. • Service required as a result of alteration, misuse, abuse, flooding, fire, lightning, or other...
  • Page 12: Energy Saving Tips

    • Ensure that proper care and maintenance of the appliance has been performed (cleaning, defrosting, etc...) Noise • Refer to “Normal Operating Sounds” (page 8) Light does not • Contact Unique’s technical service department for instructions on how to fix the issue. work...
  • Page 13: Electrical Diagram

    ELECTRICAL DIAGRAM...
  • Page 14: Parts Diagram

    PARTS DIAGRAM Please visit our website www.uniqueappliances.com to view a PDF version of the schematics which will allow you to zoom in & out...
  • Page 15: Parts List

    UGP-BCD328330-WD09-01A UGP-328L/330L Air Duct Fan UGP-BCD328330-07-03 UGP-328L/330L Freezer Foam Air Duct Insulation UGP-BCD328330-WD03-06A UGP-328L/330L Freezer Temperature Sensor UGP-BCD328330-07-01 UGP-328L/330L Freezer Air Duct Decorative Cover PARTS LIST UGP-BCD328330-07-00 UGP-328L/330L Wine Rack UGP-BCD328330-04-01 UGP-328L/330L Glass Shelf with Trim UGP-BCD328330-05-03 UGP-328L/330L Crisper Cover Glass Shelf with Air Damper NO.
  • Page 16: Warranty

    If the appliance fails to do so because of a defect in material or workmanship within one year from the original date of purchase: Unique will at our option, repair, exchange, or correct by other means Unique consider appropriate, any part(s) Unique finds to be defective except for the surface finish.
  • Page 17: Appliance Information

    APPLIANCE INFORMATION APPLIANCE INFORMATION (manual copy - keep with your records) To make care and servicing of your fridge easy and efficient, please record the following informa- tion for future reference: Model: Serial Number: Purchased From: Date Purchased: NOTES PRODUCT REGISTRATION Please visit our website at https://uniqueappliances.com/product-registration/ to register your product.
  • Page 18 © 2021 Unique Appliances Ltd., 2245 Wyecroft Road, Oakville, Ontario, Canada, L6L 5L7 www.uniqueappliances.com...
