Environmental Specifications

Environmental Specifications
The following list shows the environmental operating conditions for the AP5020:
•
Operating: 0°C to 50°C (32°F to 122°F)
•
Storage: 0°C to 70°C (32°F to 158°F)
•
Humidity: 0% to 95% (non-condensing)

Hardware Ports

The AP5020 has several ports and hardware features that connect the AP to your
network or are used to access a feature. Use the information in the following sections to
locate these ports.

Hardware Ports - Front

The following table and graphic show the available ports on the front of the AP.
Table 4: AP5020 Ports and Connections
Item Port
1 2.0 USB type A
port, 5V/500mA
with POE.at or 5V/
1000mA with POE.bt
2 Console port
3 Kensington security
slot
12 Extreme Wireless 802.11be Wi-Fi 7 Indoor AP5020 Access Point
Description
Used with a thumb drive or other external device.
Micro USB console port for a serial connection between your
management system and the access point. Use the port when you
troubleshoot the AP.
The best practice is to use the Extreme Networks micro USB
cable (ACC-WIFI-MICRO-USB). When you connect to the device, the
management station must have a VT100 emulation program, such as
the terminal emulator TeraTerm Pro or Hilgraeve HyperTerminal. Set
your baud rate to 115200.
Note: The console port can only be used with the Extreme Networks
console cable. You will damage the AP if you use another cable.
A security feature that prevents someone from removing the AP. This
is an optional task.
