The ETH0 port is autosensing 10/100/1000G BASE-T/TX Mbps, with IEEE 802.3af- or 802.3at-compliant PoE, and requires Cat5 or

better cable.

Micro USB Console Port

Security Slot

Both devices have a security slot for locking the device.

Extreme Networks recommends a variety of Kensington

External Antenna Connectors

The AP305CX has four male RP-SMA connectors for attaching dual-band dipole antennas. You can provide your own

antennas, or you can order them from Extreme Networks (AH-ACC-ANT-AX-KT).

The antenna kit contains four articulated 2.4/5 GHz antennas with a 3/5-dBi gain. These antennas are omnidirectional,

providing fairly equal coverage in all directions in a toroidal (doughnut-shaped) pattern. For greater coverage on a

horizontal plane, it is best to orient the antennas vertically. The articulated antennas hinge and swivel so that you can easily

do this, whether the AP is mounted horizontally or vertically.

The following sections list radio, device, power, and environmental specifications for the AP305C and AP305CX.

Antenna Gain

Antenna Plots

The antenna plots for these devices are available below. The Ethernet port location is noted on each chart.

AP305C

AP305CX

Power Specifications

Power Consumption

Environmental Specifications

The regulatory compliance statements in this section apply to Extreme Networks AP305C and AP305CX devices.

Japan Indoor Use

Japan Equipment VCCI-B Statement

Compliance Statement - Europe

USA, Canada, and Taiwan Radio Frequency Bands

a. USA

802.11b/g/n/ac: 2.4 GHz band: 2400-2483 MHz

802.11a/n/ac/ax: 5 GHz band: 5150-5250, 5725-5850 MHz

BLE: 2402-2480 MHz

b. Canada

802.11b/g/n/ac: 2.4 GHz band: 2400-2483 MHz

802.11a/n/ac/ax: 5 GHz band: 5150-5250, 5725-5850 MHz

locks. For more information, contact your sales representative.
