Important information
Serious risk of injury
When working on the engine, e.g. when adjusting the drive belts and clutch, or when changing oil, it is im-
portant not to start the engine. The engine could be damaged, but more importantly there is a serious risk of
injury.
Secure the starting device or disconnect a battery cable before working on the engine. This is especially im-
portant if the engine has a remote starter or automatic starting.
WARNING!
This warning symbol and text can be found next to those maintenance items where it is particularly impor-
tant to bear in mind the risk of injury.
Operator's manual
DI13 PDE Marine engine
en-GB 3 034 591
Issue 13.0
