- Page 1 SCARIFIER HYSC1600E Instruction Manual WARNING: Read the instructions carefully before use.
-
Page 2: Table Of Contents
Contents Introduction……..……………………………3 Maintenance & Care…..……………..33-36 General Maintenance…………………..33 Storage………….…...………………………3 Safety Information…..…………………..4-13 Cleaning………...………………………..33 Understand Your Machine.…..…………...4 The Blade…………………………………..34 Personal Safety...…….……………………4-5 Replacing Blades……………………..34-35 Inspect Your Machine…………………...5-6 Troubleshooting…….……………………..36 Work Area…….……………………………..6 During Use…….………………………………7 Specifications……………………....37 Batteries…….…………………………………8 Electricity…….………………...……………...9 Double Insulated Devices…..……..9 Recycling And Disposal..………………...38 Vibrations….…………………………..10 Noise…….……………………………..10 Declaration Of Conformity…..…………..39 Residual Risks…………………....10 Intended Use………………………....11 Notes………………………………………..40... -
Page 3: Introduction
THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by Hyundai Power Products and should be kept with the product. Please read and understand these instructions before you use your product. -
Page 4: Safety Information
Safety Information Understand Your Machine • WARNING! You must read these instructions carefully before operating the machine. Make sure that you are familiar with the controls and properly operate the machine. You must learn how to stop the machine quickly. If you do not follow the warnings and instructions, it may result in fire and/or serious injury. -
Page 5: Inspect Your Machine
Safety Information Personal Safety (Continued) • Do not touch parts that might be hot from operation. Allow parts to cool before attempting to maintain, adjust, or service. • Do not overreach. Keep proper footing and balance at all times. This enables better control of the machine in unexpected situations. -
Page 6: Work Area
Safety Information Work Area • You must only work in daylight or with good artificial light in good visibility conditions. Do not work at night, at times of heavy fog, or at any other times when your field of vision might be limited and it would be difficult to gain a clear view of the area. -
Page 7: During Use
Safety Information During Use • Do not operate the machine in confined areas where there may be a risk of crushing the operator between the machine and another object. • Never attempt to make any adjustments, while the machine is running. •... -
Page 8: Batteries
Safety Information Batteries (Where Present) Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. NOTE: the electrolyte may be in a liquid or gel form. -
Page 9: Electricity
Safety Information Electricity (Continued) • Power tools plug must match the outlet. Never modify the plug in any way. DO NOT use any adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. •... -
Page 10: Vibrations
Safety Information Vibrations (Where Applicable) • Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate temperature, causing numbness and heat sensations and may cause nerve damage and circulatory tissue death. -
Page 11: Intended Use
Safety Information Intended Use The HYSC1600E is an electric scarifier from HYUNDAI. The HYSC1600E has a working width of 36cm and is powered by a 1600W HYUNDAI motor. This machine is a garden tool and precisely a pedestrian controlled grass trimmer The machine is manufactured according to the latest safety requirements. -
Page 12: Personal Protective Equipment
Safety Information Personal Protective Equipment Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating or repairing the machine. No protective equipment can ensure 100% protection. When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. -
Page 13: Symbols On The Machine
Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgement. -
Page 14: Unboxing
2. Lay the contents out and check them. If any part is damaged or missing, you must not use the machine. Contact HYUNDAI POWER PRODUCTS immediately. 3. You must keep the packaging material in case the machine needs to be returned or repaired. -
Page 15: In The Box
In The Box *Not To Scale Descriptions on next page www.hyundaipowerproducts.co.uk... -
Page 16: Features
Features Upper Handle You must hold the handlebar with both hands when in use. Main Unit Middle Bar The middle bar connects to the lowers bars. Lower Bars x2 The lowers bars connect to the main unit. Power Cable Relief Hook This holds the cable in place while in use and prevents strain on the cable. - Page 17 Features Descriptions on next page www.hyundaipowerproducts.co.uk...
- Page 18 Features Upper Handle This connects to the middle bar. Main Unit Middle Bar The middle bar connects to the lowers bars. Lower Bars x2 The lowers bars connect to the main unit. Power Cable Relief Hook This holds the cable in place while in use and prevents strain on the cable. Grass Collector Bag 4 x Bolts These secure the bars together.
-
Page 19: Assembly
Assembly Assembly Overview There are 8 steps to the assembly: STEP 1. Attach The Lower Handles STEP 2. Attach The Middle Bar STEP 3. Attach The Upper Handle STEP 4. Attach Cable Clip STEP 5. Assemble The Grass Collector STEP 6. Attach The Grass Collector STEP 7. - Page 20 Assembly STEP 1 : Attach The Lower Handles (Continued) 2. Screw in the lower bar lock (K) until it is tight and secure. Turn clockwise to lock and anti-clockwise to unlock. 3. The scarifier should now look like the image below. www.hyundaipowerproducts.co.uk...
-
Page 21: Attach The Middle Bar
Assembly STEP 2 : Attach The Middle Bar 1. Slide the cable relief hook (E) onto the middle bar (C). 2. Connect the middle bar (C) to the lower bars (D) using the wing nut (H) and bolt (G). www.hyundaipowerproducts.co.uk... -
Page 22: Attach The Upper Handle
Assembly STEP 3 : Attach The Upper Handle 1. Connect the upper bar (A) to the middle bar (C) using the wing nut (H) and bolt (G). Make sure the upper bar is attached the correct way as shown in the image. 2. -
Page 23: Attach Cable Clip
Assembly STEP 4 : Attach Cable Clip 1. Clip the power cord (X) onto the middle bar (C) using the cable clip (J). This will keep the cable secure and tight to the machine. 2. You can also store the hex key (I) in the cable clip (J) as shown in the image. www.hyundaipowerproducts.co.uk... -
Page 24: Assemble Grass Collector
Assembly STEP 5 : Assemble The Grass Collector 1. Place the metal frame (F1) into the collection bag (F). Attach all fasteners (F2) and make sure they are secure. www.hyundaipowerproducts.co.uk... -
Page 25: Attach The Grass Collector
Assembly STEP 6 : Attach The Grass Collector You must attach the grass collector before use. 1. Make sure the grass collector is correctly assembled. 2. Lift up the protective rear cover (O). 3. Make sure that the rear chute is clear and free of debris. 4. -
Page 26: Cable Relief Hook
Assembly STEP 7 : Cable Relief Hook Make sure the machine is disconnected from power before you do this This holds the cable in place while in use and prevents strain on the cable. 1. Make a small loop in the power cable (X). 2. -
Page 27: Working Depth Adjustment
Assembly STEP 8 : Working Depth Adjustment The working depth is adjustable to 5 heights (-12mm, -9mm, -6mm, -3mm and +6mm). Be careful not to use the scarifier at too deep a setting. If there is excessive strain on the motor, it will lose speed and be less efficient. -
Page 28: Operation
Operation Using The Scarifier (Rigid Tines) 1. By scarifying you remove the hardened surface, grass felt and flat-growing weeds and the crusted over grassroots are loosened up. The lawn will start to breathe again and assimilate the nourishing substances, oxygen and water. This also prevents the establishing of bacteria in the lawn during the winter. -
Page 29: Working Direction
Operation Working Direction We recommend to use your machine as outlined below to achieve optimum results and to reduce the risk of cutting the mains cable. WARNING! DO NOT WORK TOWARDS THE CABLE. 1. Place the bulk of the mains cable close to the starting point. 2. -
Page 30: What Is Scarification
Operation What Is Scarification Scarification is the removal of moss, lawn clippings and dead grass blades from the stem of the grass to maintain a healthy growing environment. It is intensive airing of the lawn surface. • Perfect for revitalising and reviving the most tired and spongiest of lawns. •... -
Page 31: Before Starting Work
Operation Before Starting Work 1. Check the condition of the cable, if damaged do not use. 2. Ensure that no objects or branches are trapped into the machine. 3. Ensure the work area is tidy and free of any obstacles. 4. -
Page 32: Stopping
Operation Stopping WARNING : Cutting elements continue to rotate for a moment after the motor is switched off. Do not touch the underside of the machine until the cutter has come to a standstill. WARNING : Always switch off machine before placing it down. 1. -
Page 33: Maintenance & Care
Maintenance & Care General Maintenance WARNING : Turn OFF the machine, allow all moving parts to come to a complete stop, and disconnect the power cord before maintaining the machine. You need to wear proper clothing and protective gloves whenever your hands are at risk. -
Page 34: The Blade
Maintenance & Care The Blade WARNING! Always wear protective gloves when working with the blade. • Check the blade. The blade should always be sharp. At regular intervals, check the tightness of all nuts, bolts and screws. • If the blade hits an obstacle, check for damage and if the machine vibrates badly, stop the machine and take it to a service dealer. - Page 35 Maintenance & Care Replacing Blades (Continued) 2. Lift the cylinder (U) at an angle and pull it out. 3. Slide the second cylinder onto the drive shaft so that the pin (V) fits into the respective part of the drive shaft (W). 4.
-
Page 36: Troubleshooting
Maintenance & Care Troubleshooting NOTE : All corrective actions should be carried out by suitably qualified person/s. Problem Possible Cause Possible Solution Machine will not start. Fuse in mains plug blown Check fuse in mains plug / faulty and replace is necessary. Internal wiring fault. -
Page 37: Specifications
Technical Data Specification Model HYSC1600E Voltage 230-240V Frequency 50Hz Rated Power 1600W Working Width 36cm Working Depth +6mm to -12mm Grass Collector Capacity Protection Class IPX4 Cylinder Operating Speed 3500rpm Sound Pressure Level dB(A) LpA 90.2 Guaranteed Sound Power Level LwA 108 dB(A) Vibrations K=1.5m/s... -
Page 38: Recycling And Disposal
Recycling & Disposal Recycling & Disposal We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or Batteries is passed onto you by us. So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site. -
Page 39: Declaration Of Conformity
Isaac Way, Pembroke Dock, SA72 4RW Country of Origin: China Description: Lawn Scarifier/Aerator SKU Code: HYSC1600E Date of Issue: 01/11/2023 Regulations and Directives of Compliance • 2006/42/EC The Machine Directive • 2014/30/EU Annex ll Electromagnetic Compatibility Directive • 2006/95/EC Low Voltage Directive... -
Page 40: Notes
Notes www.hyundaipowerproducts.co.uk... -
Page 41: Useful Information
Go to YouTube and search ‘Hyundai Power Products’. Warranty Proof of purchase will be required before you make a warranty claim. Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website: www.hyundaipowerproducts.co.uk Manual Updates Our manuals are constantly being reviewed and updated. Should you find an error, omission or something unclear, please contact us for assistance. -
Page 42: Product Record
Product Record Information As soon as you have purchased the machine, we recommend that you fill out the following. If you need to contact an authorised dealer or customer service for information on servicing, you may need to provide the following information. Date Of Purchase:……………………………………………………………………………….. -
Page 43: Contact Us
Contact Us Need Help? Talk To Our Experts Our friendly aftersales team will be more than happy to help you. Phone Call our team on 01646 687 880 Email aftersales@genpower.co.uk Online Live Chat Go to www.hyundaipowerproducts.co.uk Post Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW. Hyundai Support Website Go to hyundaisupport.co.uk www.hyundaipowerproducts.co.uk... - Page 44 For Inquiries, Please Contact: GENPOWER LTD Isaac Way, London Road, Pembroke Dock, UK, SA72 4RW. T: +44 (0) 1646 687 880 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported / Distributed by Genpower Ltd for Licensed by Hyundai Corporation Holdings, Korea the United Kingdom & Ireland...
