  • Page 1 PETROL LAWN SCARIFIER & AERATOR HYSC210 Instruction Manual...
  • Page 2 USING THE MACHINE. Keep for future reference and pass it on if the machine is loaned or sold to another user. This manual has been produced by Hyundai Power Products and should be kept with the product. Please read and understand these instructions before you use your product. Failure to do this may result in personal injury or damage to the product.

  • Page 3: Table Of Contents

    Contents Safety Information.....4-19 Maintenance......39-49 Maintenance Safety........38-40 Understand Your Machine.......4 Checking Your Machine.........41 Personal Safety..........5 Spark Plug.............42 Inspect Your Machine........6 Air Filter............43 Work Area............7 Fuel And Carburetor........44 During Use............8-9 Blade Removal..........45 Engine Safety..........10 Check Blade Tightness........46 Carbon Monoxide...........11 Cleaning............47 Fuel Safety..........12-13 Transportation..........47 Batteries............14 Storage............48...

  • Page 4: Safety Information

    General Safety Safety No list of safety guidelines can be complete. Every environment is different. Always consider safety first, as it applies to your individual working conditions. Use this and other machinery with caution and respect. Failure to do so could result in serious injury, damage to equipment, or poor work results.

  • Page 5: Personal Safety

    General Safety Personal Safety • WARNING! Never allow children or people unfamiliar with these instructions to use the product. Local regulations can restrict the minimum age of the operator. • Keep children, pets, and other people not using the unit away from the work area (at least 15m).

  • Page 6: Inspect Your Machine

    General Safety Inspect Your Machine • Check your machine before starting it. Keep guards in place and in working order. Make sure all nuts, bolts, etc., are securely tightened. • You must check the general condition of the machine before use. •...

  • Page 7: Work Area

    General Safety Work Area • Make sure you thoroughly inspect the entire work area and remove all objects and anything that could be thrown by the machine or could damage the engine or machine (branches, stones, wire, toys, etc). Attempting to clear the work area whilst using the machine will reduce your concentration and creates a trip hazard.

  • Page 8: During Use

    For Safe Operation During Use • Always hold the unit with both hands when operating. Keep a firm grip on the handlebars. Be aware that the machine may unexpectedly bounce upward or jump forward if the machine should strike buried obstacles such as large rocks or roots. •...
  • Page 9 For Safe Operation During Use (Continued) • You must disengage the blade, switch off the engine and unplug the spark plug cable (making sure that all moving parts are stationary): - Before refuelling. - Before adjusting the cutting height. - After striking a foreign object, you must inspect the machine for damage and make repairs before using it again.

  • Page 10: Engine Safety

    Safety Information Engine Safety • This machine is equipped with an internal combustion engine. Do not use on, or near, forest-covered or brush-covered land unless the exhaust system is equipped with a spark arrester meeting applicable local, state, or federal laws. •...

  • Page 11: Carbon Monoxide

    Safety Information Carbon Monoxide DANGER! Engine exhaust fumes contain Carbon Monoxide. This is a poisonous gas and can kill in minutes. NEVER use inside a building or in an area with poor ventilation. NEVER use inside a confined space, such as but not limited to a house, garage, vehicle, boat or tent. ONLY use outside and far away from windows, doors and vents.

  • Page 12: Fuel Safety

    Safety Information Fuel Safety CAUTION! ALL FUELS ARE HIGHLY FLAMMABLE AND PETROL VAPOUR IS EXPLOSIVE. TAKE EXTREME CARE WHEN HANDLING FUEL. KEEP FUEL OUT OF REACH OF CHILDREN. General Safety General Safety • Do not smoke each time fuel is handled. •...
  • Page 13 Safety Information Fueling / De-Fueling • ALWAYS fuel and de-fuel in a well ventilated area outside of buildings. Use a funnel to add fuel, only outdoors. Do not smoke during this and each time fuel is handled. • Add fuel before igniting the engine, never remove the fuel tank cap or add fuel whilst the engine is running or when it is hot.

  • Page 14: Batteries

    Safety Information Batteries (Where Present) Batteries present a risk if they become damaged by the possible leaking of electrolyte. This electrolyte is an acid and can cause serious burn injuries. Care should be taken when working on or near them. NOTE the electrolyte may be in a liquid or gel form. Should you come in to contact with electrolyte you should;...

  • Page 15: Electrical Safety

    Safety Information Electrical Safety (Where Applicable) DANGER! ELECTRICITY CAN KILL - NEVER WORK ON LIVE/ENERGISED EQUIPMENT. • Prior to carrying out any maintenance work you MUST identify electrical isolation methods and isolate all electrical supplies. • Prior to use and with all electrical supplies isolated, you MUST check all electrical cables, plugs and connectors for the following;...

  • Page 16: Vibrations

    Safety Information Vibrations (Where Applicable) • Prolonged use of hand held (operated) machines will cause the user to feel the effects of/from vibrations. These vibrations can lead to white finger (Raynaud’s phenomenon) or carpal tunnel syndrome. This condition reduces the ability of the hand to feel and regulate temperature, causing numbness and heat sensations and may cause nerve damage and circulatory tissue death.

  • Page 17: Personal Protective Equipment

    Safety Information Personal Protective Equipment Appropriate Personal Protective Equipment (PPE), MUST be worn at all times when operating or repairing the machine. No protective equipment can ensure 100% protection. When selecting PPE, make sure it’s CE marked and it suits the user in terms of size, fit, etc. If more than one item of PPE is worn at the same time, make sure they can be used together, e.g.

  • Page 18: Intended Use

    Machine Description And Scope Of Application The HYSC210 is a petrol lawn scarifier from Hyundai, ideally suited for small to medium sized lawns. The HYSC210 has a working width of 400mm and is powered by a 212cc 4-stroke OHV petrol engine.

  • Page 19: Symbols On The Machine

    Safety Information Symbols On The Machine We have provided safety messages in this manual and on the machine. This information alerts you to potential hazards that could hurt you or others. Please read these messages carefully. However, we may not have listed all of the possible hazards, you must also use your own judgment.

  • Page 20: Features

    Features HYSC210 Features aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 21 Features HYSC210 Features Soft Grip Handle Operator Presence Control (OPC) Lever This is a safety feature. The machine will stop if you let go of this lever. Oil Filler / Dipstick Working Depth Height Adjustment Knob Recoil Starter Handle Wheel...

  • Page 22: Unboxing

    Lay the contents out and check them. If any part is damaged or missing, you must not use the machine. Contact HYUNDAI Power Products immediately. You must keep the packaging material in case the machine needs to be returned or repaired.

  • Page 23: Assembly

    Assembly Safety Assembly Safety CAUTION - This guide is meant to serve as a quick reference for operating your HYUNDAI machine. We always advise reading the manual in full before operation. CAUTION - For OUTDOOR use ONLY. Petrol machines produce carbon monoxide – poisonous, colourless and odourless gas that can cause serious injury or death.

  • Page 24: Assemble Handlebars

    Assembly Unboxing & Assembly Video: Go to youtube.com and type in Hyundai HYSC210 assembly. YOU MUST read and understand the instruction manual first. Step 1 : Assemble Handle Bars Attach the lower handle to the mounting bracket on the scarifier deck by sliding the bolt through the lower handle bar and through one of the 2 different handlebar height holes on the mounting bracket.
  • Page 25 Assembly Place the washer over the bolt. See image 5. Secure in place with the hand wheel and tighten securely. See image 6. Image 5 Image 6 Slowly pull the recoil starter handle up to the handle retaining loop. See image 7. Image 7 aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk...

  • Page 26: Attach Grass Collector

    Assembly Step 2 : Attach Grass Collector Lift the rear discharge flap and hook the grass catcher over the back of the scarifier. See image 1. Manoeuvre the grass collector into position ensuring it is hooked firmly in place . See image 2.

  • Page 27: Attaching Grass Collector

    Assembly Step 3 : Cable clips Attach the cable clamp around the cable and fix to the handlebar. See image 1. Image 1 aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 28 Assembly Step 4 : Cable Attachment NOTE - If you are stood behind the machine: OPC Cable: This attaches to the lever in front of the main handlebar and if followed, will attach to the engine. Gently prise the lever from its locating hole in the main handlebar. See image 1. Insert the end of the cable in to the hole in the lever.

  • Page 29: Cable Attachment

    Preparation Before Each Use • Always ensure that the scarifier is in a safe working condition. Inspect the machine, check safety devices and guards and check all nuts, bolts and screws are secure. • Check the oil level. • Fill the fuel tank with unleaded petrol. •...

  • Page 30: Adding Oil

    Preparation Adding Oil Oil Type : SAE 30 or 15w40 Engine Oil Oil Capacity : 600ml NOTE - The machine is delivered without oil in the engine. All machines are tested and inspected so there may be some residual oil left in the machine so please fill with caution. Remove the oil filler cap.

  • Page 31: Adding Fuel

    Preparation Adding Fuel Make sure you read the fuel safety before handling fuel. Fuel Type : Fresh Straight Unleaded Petrol Fuel Capacity : 3.6L NOTE - The machine is delivered without petrol. All machines are tested and inspected so there may be some residual petrol left in the machine so please fill with caution.

  • Page 32: Starting / Stopping

    Starting Procedure YOU MUST read and understand the full safety instruction manual before starting the machine. Cold Start Turn the engine switch to the ON position. See image 1. Move the fuel tap to the ON position. (Bottom lever to the right). See image 2. Image 1 Image 2 Move the choke lever to the START position.
  • Page 33 Starting Procedure Gently pull the recoil starter handle until you feel resistance, then pull swiftly until the engine starts. See image 5. When engine starts, move the choke lever back to the RUN position . See image 6. Image 5 Image 6 Warm Start Repeat the cold start procedure but leave the choke in the ON position.
  • Page 34 Stopping Procedure Stopping Before stopping the machine, you must allow the engine to idle for 20 seconds. You do not need to do this if you need to emergency stop the engine. Release the Operator Presence Control (OPC) lever and the engine will stop. See image 1. Turn the engine switch to the OFF position.

  • Page 35: Operation

    Operation Adjusting Working Depth CAUTION - Do not make any adjustment to the scarifier without stopping the engine first. The scarifier is equipped with a working depth adjustment lever offering multiple working depths. To adjust the working depth, first stop the machine and switch the engine off. Turn the working depth adjustment knob anti-clockwise to lower the blade or clockwise to raise the blade.

  • Page 36: Using The Machine

    Operation What Is Scarification? Scarification is the removal of moss, lawn clippings and dead grass blades from the stem of the grass to maintain a healthy growing environment. It is intensive airing of the lawn surface. • Perfect for revitalising and reviving the most tired and spongiest of lawns. •...

  • Page 37: Troubleshooting

    Troubleshooting NOTE - Where necessary, all corrective actions should be carried out by suitably qualified persons. Problem Possible Cause Possible Corrective Action Engine does not start Throttle choke is not in the Move throttle choke to correct correct position position Fuel tank is empty.

  • Page 38: Technical Data

    Technical Data Specifications Model HYSC210 Engine Type Single Cylinder OHV Engine Size 212cc Nominal Power Engine Speed 2800rpm Fuel Tank Capacity 3.6L Fuel Type Unleaded Petrol Oil Tank Capacity 600ml Oil Type SAE 30 or 15W40 Engine Oil Working Width...

  • Page 39: Maintenance

    Maintenance & Care Maintenance Safety 1. WARNING - Before cleaning or doing maintenance work, you need to disconnect the spark plug cable and read the relevant instructions. You need to wear proper clothing and protective gloves whenever your hands are at risk. 2.
  • Page 40 Maintenance & Care Maintenance Safety (Continued) 15. Engine must be cooled down before storing. 16. To reduce fire hazards, keep the engine, silencer, battery compartment and petrol storage area free of grass, leaves, or excessive grease. You must always empty the grass collector and do not leave containers full of cut grass inside storage areas.

  • Page 41: Checking Your Machine

    Maintenance & Care Routine Maintenance IMPORTANT - Routine and accurate maintenance is essential for maintaining original machine safety and performance levels. Always stop the engine and unplug the spark plug before doing any repairs or maintenance. Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardize the safety of the machine, may cause accidents or personal injuries for which the Manufacturer is under no circumstance liable or responsible.

  • Page 42: Spark Plug

    Maintenance & Care Spark Plug You MUST allow the engine to cool down before carrying out any maintenance. Always replace with the same model spark plug as fitted. Remove the spark plug HT lead cap. Undo the spark plug from the engine and remove. Visually inspect the spark plug for signs of damage, wear or carbon build up.

  • Page 43: Air Filter

    Maintenance & Care Air Filter CAUTION - A dirty air filter will restrict the air flow to the carburettor, which will reduce engine efficiency. When using the machine in very dusty areas you must clean or replace the air filter more often. Never operate the machine without the air filter being fitted it can cause damage to the engine which is not covered by warranty.

  • Page 44: Fuel And Carburetor

    Maintenance & Care Fuel & Carburetor CAUTION - ALL FUELS ARE FLAMMABLE. Always fuel and defuel in a well-ventilated area outside of buildings. Always wear correct PPE and wipe up and spills immediately. The use of old or stale petrol will impair the starting and running of the machine. Make sure that the machine has fresh unleaded petrol and always remove the fuel before storing for long periods of time.

  • Page 45: Blade Removal

    Maintenance & Care Blade Removal CAUTION - Drain the machine of fuel before removing or replacing the blade. ALWAYS fuel and defuel in a well ventilated area outside of buildings. ALWAYS wear correct, suitable and fit for purpose Personal Protective Equipment (PPE), suggested items are but not limited to safety gloves, overalls.

  • Page 46: Check Blade Tightness

    Maintenance & Care Check Belt Tightness Using a 6mm hexagonal key, undo the bolt at the top of the belt guard. Using a Phillips screwdriver, remove the two screws at the bottom of the belt guard. Check belt tension (arrowed). There should be 10-15mm of movement. To tighten belt, loosen the centre pulley bolt and push pulley towards the front of the scarifier to take up slack and re-tighten centre bolt.

  • Page 47: Cleaning

    Maintenance & Care Cleaning CAUTION - DO NOT use a hose pipe or pressure washer to clean the engine. Water can damage the engine or contaminate the fuel system. NOTE Engine must be switched off and plug lead disconnected. • Wipe the machine down with a damp cloth after every use. •...

  • Page 48: Storage

    Maintenance & Care Storage CAUTION - When storing the machine, make sure it has been cleaned as in the section before. NOTE - If storing the scarifier for a period of 30 days or more, you must follow proper storage and winterisation guidelines to avoid any possible issues with your machine.

  • Page 49: Recycling And Disposal

    Maintenance & Care Recycling And Disposal We do not offer a takeback scheme for the recovery of Waste Electrical Electronic Equipment (WEEE) & Batteries. Instead the responsibility to dispose of WEEE and/or Batteries is passed onto you by us. So when it becomes necessary to dispose of your machine you must take it to your local Civic Amenity Site.

  • Page 50: Spare Parts

    Spare Parts Ordering Spare Parts Only use original spare parts: The use of non-original and/or incorrectly fitted parts will jeopardise the safety of the machine, may cause accidents or injuries for which the manufacturer is under no circumstance liable or responsible. Find the part you are looking for in the drawings.
  • Page 51 Spare Parts Drawing B aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 52 Spare Parts Drawing C aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 53 Spare Parts Drawing D Drawing E aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 54 Spare Parts Drawing F Drawing G aftersales@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk 01646 687 880...
  • Page 55 Spare Parts Drawing A Drawing Number Spare Part Name Part Number HYSC210-A01 Brake Lever 1001001 HYSC210-A02 1001002 HYSC210-A03 Limiting Stopper 1290002 HYSC210-A04 Foam Pipe 1290003 HYSC210-A05 TS40 Upper Handle 1001005 HYSC210-A06 Bolt 1290006 HYSC210-A07 Flat Washer 1290007 HYSC210-A08 Knob 1290008...
  • Page 56 Spare Parts Drawing B Drawing Number Spare Part Name Part Number HYSC210-B01 Front Handle Base 1001032 HYSC210-B02 Screw 1001033 HYSC210-B03 Screw 1001034 HYSC210-B04 Decoration Plate 1001035 HYSC210-B05 Upper Cover 1001036 HYSC210-B06 1286073 HYSC210-B07 Knob 1001038 HYSC210-B08 Bolt 1290062 HYSC210-B09 Plate...
  • Page 57 Spare Parts Drawing C Drawing Number Spare Part Name Part Number HYSC210-C01-1 Engine 1001054 HYSC210-C01-2 Flat Key 1001055 HYSC210-C01-3 Bolt 1001056 HYSC210-C02 Bolt 1001057 HYSC210-C03 Bush 1001058 HYSC210-C04 1001059 HYSC210-C05 Belt 1001060 HYSC210-C06 Pulley Wheel 1001061 HYSC210-C07 Flat Washer 1001062...
  • Page 58 Spare Parts Drawing D Drawing Number Spare Part Name Part Number HYSC210-D01 8” Outer Wheel Cover 1001077 HYSC210-D02 1290094 HYSC210-D03 Bush 1290119 HYSC210-D04 8” Wheel 1001080 HYSC210-D05 Spring Washer 1290089 HYSC210-D06 Bolt 1001082 HYSC210-D07 1001083 HYSC210-D08 Rear Axle 1001084 HYSC210-D09...

  • Page 59: Our Product Range

    Our Product Range Generators Mini Dumpers Leisure Inverter, Petrol, Diesel And Built-In 4-Wheel Drive Mini Dumpers And Tracked Motorhome Generators Dumpers Pressure Washers Yard Sweeper Petrol, Diesel And Electric Pressure Washers Self Propelled Yard Sweeper Power Brush Water Pumps Scarifiers Submersible, Clean And Dirty Water And Petrol Lawn Scarifier And Aerator Professional Chemical Water Pumps...

  • Page 60: Useful Information

    Go to www.hyundaisupport.co.uk or search ‘Hyundai Power Products’ in YouTube. Warranty Proof of purchase will be required before you make a warranty claim. Full warranty terms and conditions can be found on the HYUNDAI POWER PRODUCTS website: www.hyundaipowerproducts.co.uk Manual Updates Our manuals are constantly being reviewed and updated.

  • Page 61: Declaration Of Conformity

    101dB(A) 105dB(A) 3400 scarifier Product Details Brand: Hyundai Model: HYSC210 Description: Petrol lawn scarifier Name and address of technical documentation holder and EU distributor: Genpower Ltd, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK. Signed by: Roland Llewellin, Managing Director Date: 10/12/2019 aftersales@hyundaipowerproducts.co.uk...

  • Page 62: Product Information

    Product Information Information As soon as you have purchased the machine, we recommend that you fill out the following. If you need to contact an authorised dealer or customer service for information on servicing, you may need to provide the following information. The model number and serial number can be found on the grey specification sticker on your machine.

  • Page 63: Contact Us

    Need Help? Talk To Our Experts Contact Us Our friendly aftersales team will be more than happy to help you. Phone Call our team on 01646 687880, open Monday-Friday 8.30am-5pm. Email aftersales@hyundaipowerproducts.co.uk Online Live Chat Go to www.hyundaipowerproducts.co.uk Live chat is open Monday-Friday from 8.30am-5pm. Post Genpower Limited, Isaac Way, Pembroke Dock, Pembrokeshire, SA72 4RW, UK.
  • Page 64 Importer: GENPOWER LTD Isaac Way, London Road, Pembroke Dock, UNITED KINGDOM, SA72 4RW T: +44 (0) 1646 687 880 F: +44 (0) 1646 686 198 E: info@hyundaipowerproducts.co.uk www.hyundaipowerproducts.co.uk Imported/Distributed by Genpower Ltd for The United Kingdom & Ireland Licensed by Hyundai Corporation, Korea...
