- Page 1 Original instructions EN MULTI SURFACES BRUSH HBE600MF ORIGINAL INSTRUCTIONS For correct usage, read these instructions carefully and keep in a safe place for future reference.
-
Page 2: Table Of Contents
Original instructions EN CONTENT 1. SAFETY INSTRUCTIONS 2. INTENDED USE 3. SYMBOLS 4. YOUR PRODUCT 5. TECHNICAL DATA 6. OPERATION 7. CLEANING AND MAINTENANCE 8. TROUBLESHOOTING 9. EC DECLARATION OF CONFORMITY 10. WARRANTY 11. PRODUCT FAILURE 12. EXCLUSIONS WARRANTY... -
Page 3: Safety Instructions
Original instructions EN 1. SAFETY INSTRUCTIONS IMPORTANT! When using the equipment, a few safety precautions must be observed to avoid injuries and damage. Please read the complete operating instructions and safety information with due care. Keep these operating instructions in a safe place so that the information is available at all times. If you give the equipment to any other person, hand over these operating instructions and the safety information as well. - Page 4 Original instructions EN accidents. d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key left attached to a rotating part of the power tool may result in personal injury. e) Do not overreach. Keep proper footing and balance at all times. This enables better control of the power tool in unexpected situations.
-
Page 5: Intended Use
Original instructions EN - Damaged brushes must not be used. - Discoloration due to rust or other signs of chemical or mechanical changes in the material may cause premature failure. - Brushes must be stored on appropriate shelves, containers or packaging so as to be protected against the effects of: High humidity, heat, water or other liquids that can damage the brush;... -
Page 6: Symbols
Original instructions EN 3. SYMBOLS Explanation of the warning signs on the equipment “Warning – To reduce the risk of injury, user must read instruction manual” Do not expose to rain Wear goggles and ear protectors. Beware of objects ricocheting out of the guard. Keep all other persons away from the working area. -
Page 7: Your Product
Original instructions EN 4. YOUR PRODUCT 1. Trigger switch 2. Auxiliary handle 3. Extension tube 4. Lock button 5. Main housing 6. Brush machine 7. Sweeper 8. Push button... -
Page 8: Technical Data
Original instructions EN 5. TECHNICAL DATA Model HBE600MF Rated voltage 230-240V~ Rated frequency 50 Hz Rated input 600W No load speed 1100-1800min Max. brush diameter 100mm/210mm A-weighted sound pressure level L 85dB(A) Uncertainty K A-weighted sound power level 95dB(A) Uncertainty K Vibration value a 1.620m/s... -
Page 9: Operation
Original instructions EN 6. OPERATION Warning: Never turn on the device when adjusting the handle to avoid damage and serious injury. FIG A Insert the brush machine or the sweeper machine into the main housing; rotate it in place according to the figure, to lock it in place. To remove the accessory, push the lock button and rotate the accessory to remove it. - Page 10 Original instructions EN CONNECTION An extension cord must be used to connect the tool to electrical mains. Connect the tool plug to the extension cord. The power can be secured on the handle of the tool. Then, connect the plug of the extension cord to the electrical mains. Important Only use brushes which are in good condition.
-
Page 11: Cleaning And Maintenance
Original instructions EN 7. CLEANING AND MAINTENANCE Always pull out the power plug before starting any cleaning work. 7.1 CLEANING Keep all safety devices, air vents and the motor housing free of dirt and dust as far as possible. Wipe the equipment with a clean cloth or blow it down with compressed air at low pressure. We recommend that you clean the equipment immediately after you use it. -
Page 12: Ec Declaration Of Conformity
32, rue Aristide Bergès - ZI 31270 Cugnaux – France declare that the machine We declaring that the machinery Product name: MULTI SURFACES BRUSH Model: HBE600MF S/N: 20210660052-20210660351 Function: The equipment is designed to remove dusts and weeds between paving stones and slabs, for wooden deck cleaning and stone cleaning. -
Page 13: Warranty
10. WARRANTY WARRANTY The manufacturer guarantees the product against defects in material and workmanship for a period of 2 years from the date of the original purchase. The warranty only applies if the product is for household use. The warranty does not cover breakdowns due to normal wear and tear. The manufacturer agrees to replace parts identified as defective by the designated distributor. -
Page 14: Product Failure
11. PRODUCT FAILURE WHAT TO DO IF MY MACHINE BREAKS DOWN? If you bought your product in a store: a) Empty the fuel tank if your product has one. b) Make sure that your machine is complete with all accessories supplied, and clean! If this is not the case, the repairer will refuse the machine. -
Page 15: Exclusions Warranty
12. WARRANTY EXCLUSIONS THE WARRANTY DOES NOT COVER: • Start-up and setting up of the product. • Damage resulting from normal wear and tear of the product. • Damage resulting from improper use of the product. • Damage resulting from assembly or start-up not in accordance with the user manual. •... - Page 16 Original instructions EN...
